- Page 1 Owner's Manual Control Centraliced KCC-64 WEB KCC-64 WEB 2019 Original instructions Thank you very much for purchasing our product. Before using your unit, please read this manual carefully and keep it for future reference.
- Page 2 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of the wired controller please read this manual carefully before using the unit. ● For convenience of future reference, keep this manual after reading it.
-
Page 3: Table Of Contents
Table of Contents I. Safety precautions .................1 II. Installation and Operation of the Data Converter .........3 III. Function Description ................10 IV. APP Function Description ..............12 V. Web Client Operation .................37 VI. Remote Web Client Operation ............38... -
Page 4: Safety Precautions
I. Safety precautions The following contents are stated on the product and the operation manual, including usage, precautions against personal harm and property loss, and the methods of using the product correctly and safely. After fully understanding the following contents (identifiers and icons), read the text body and observe the following rules. g Identifier description Identifier Meaning... - Page 5 g Icon description lcon Meaning It indicates forbidding. The forbidden subject-matter is indicated in the icon or by images or characters aside. It indicates compulsory implementation. The compulsory subject-matter is indicated in the icon or by images or characters aside. Warning Please entrust the distributor or professionals to install the unit.
-
Page 6: Installation And Operation Of The Data Converter
II. Installation and Operation of the Data Converter 1. System structure diagram The system mainly includes the central air conditioning system, data converter, router, App, cloud server, and Web client. The user can monitor the air conditioning system via App or Web client. - Page 7 LAN cable to connect multiple KCC-64 WEB gateways, associate KCC-64 WEB gateways with one router. For the configuration, see section 3.1. Note: The new KCC-64 WEB is compatible with the V5X, V4+S, V4+R and Mini VRF outdoor units For more information, please contact the technical support engineer...
- Page 8 2. Hardware instruction Fig.3.1 Structure dimension drawing...
- Page 9 Status indicator light input Voltage:DC5V Connect to the Ethernet communication RESET terminal 485 terminal Power supply terminal Fig.3.2...
- Page 10 3. Instructions 1. Unpack the packing box to see if the accessories are all in readiness. Data converter is shown as the following figure: Name Qty. Outline Data Converter Owner’s manual Power adaptor Wiring 3-terminal and 1 bags of fixed screws...
- Page 11 2. Take the data converter out and power it on to see if the device is normal ( POWER indicator lights up) POWER indicator lights up Fig.3.3 3. Data converter installation precautions a. Don’t install it in the place where flammable gas leaks easily.Once flammable gas leakage occurs and stagnate around the device, it may result in fire.
- Page 12 Operating Colour Description indicator status When the indicator flashes, it indicates Green Flash that an air conditioner is connected. When it flashes, it indicates that the data Green Flash converter is accessing the Ethernet. POWER Steady on Power supply of the system is normal. Figure 3 LED indicators...
-
Page 13: Function Description
5. Getting an IP Address page of the data converter. By default, the IP address of the data III. Function Description converter is achieved by DHCP and allocated by the access router. Only when App and The data convert supports Web, HTTP, TCP, data converter are configured on one LAN, and IP. - Page 14 ① ② ③ ④ Web function list ① "AC Control": air conditioner control ② "Booking Control": scheduled operations ③ "Operation logs": operation logs ④ "User group": group management APP download IOS: Go to APP Store seach "M-control" or type http://www.aircontrolbase.com/login.html to download the app Android: type http://www.aircontrolbase.com/login.html to download the app...
-
Page 15: App Function Description
IV. APP Function Description 1. Registration Function 1-1 Registration Code Before registering an account, the user must enter the registration code, as shown in the following figure. Open App client on the smart phone. Enter the registration code, such as Kaysun, which is the first step. Then, click "OK". A login interface with the specified logo is displayed. See the following figure:(Note:Registration function only APP client) - Page 16 1-2 Account Registration A registered account is used to manage devices and set management permissions. The registered account can also be used to log in to the App and Web clients. Procedure: ① Click "Register". ② Enter a valid email ③...
- Page 17 2. Virtual function The virtual experience function is used for showing the main interface, AC control, booking control and so on. Operation only available for choosing the unit of the temperature and setting the AC, the other menu and function are invalid in this function.
- Page 18 3. App Configuration Refer to the guide to connecting the KCC-64 WEB and port XYE of the outdoor unit. Connect the KCC-64 WEB to the router. After login via App, the main interface prompts the user to configure the KCC-64 WEB, as shown in the following figure: prompts displays the...
- Page 19 C. The wireless router must access the Internet. ① Select a configuration manner. ② The App will search for the KCC-64 WEB devices on its LAN and displays the IP address of each KCC-64 WEB gateway. As shown in the figure above, ② displays multiple KCC- 64 WEB devices found. Only one KCC-64 WEB device can be selected for configuration. Select one, and the system counts down. After configuration succeeds, it goes to the main...
- Page 20 KCC-64 WEB device and record its IP address. The following figure shows how to configure multiple KCC-64 WEB gateways: ① Click "KCC-64 WEB Management". ② Click "+" at the upper right corner. The KCC- 64 WEB configuration interface is displayed. ③ Select a configuration manner. The subsequent steps are the same as those for configuring the KCC-64 WEB via a network cable.
- Page 21 3-2 Scanning a QR Code 1) After registration, the new user directly goes to the device configuration interface. 2) Click "Scan QR code". It goes to the QR code scanning interface. Scan the QR code shared with other users to complete configuration. Note: When the KCC-64 WEB is configured for the first time, the user must configure it via a network cable.
- Page 22 4. Editing an Area 4-1 Adding and Deleting an Area Adding an area: Click "+", as circled in the figure above. On the displayed interface, click "Add Area". Enter the name of the new area in the text box. Click "Save".
- Page 23 Deleting an area: On the selected area, slip left. Click "Delete" to delete the area. Click "Edit" to edit the area name.
- Page 24 4-2 Adding a Device to an Area After an area is added, it goes back to the area display interface. Click the area to which a device is added. Click "Add Device". Select the device to be added. Click "OK".
- Page 25 4-3 Editing a Device in an Area Click the icon indicated by ① at the upper right corner, as shown in the figure above. Click "Device management". The device management interface is displayed. Click "Add Device" indicated by ② to add a device or "Remove Device" to delete a device.
- Page 26 Device state Screening statistics device states Distinguishing device states by using Area list different colours Statistics of device states: This area displays the number of air conditioners in each state. Distinguishing device states by using different colours: This area displays the air conditioners in different states by using different colours, as shown in the following figures:...
- Page 27 HEAT COOL Screening device states: This area displays the air conditioners in the selected state. 3-4 Area Control Main Interface Area control-Mode Area control-Items Area list to be locked Area list: It displays area name, the number of running air conditioners in the area, and the total number of the air conditioners in the area.
- Page 28 Area control: On the area control interface, ambient temperature is not displayed. The user can set temperature between 17°C and 30°C (62°F and 86°F) and select a fan speed (low, medium, high, and auto). Locking: The user can lock mode, cooling temperature, heating temperature, fan speed, and remote control.
- Page 29 ⑤ Locking: The user can lock mode, cooling temperature, heating temperature, fan speed, and remote control. ⑥ Power on or off. ⑦ Set temperature between 17°C and 30°C (62°F and 86°F). Note: If an air conditioner fails, the main interface displays the fault and the user cannot operate the interface.
- Page 30 ③ It is an interface for renaming a device. Note: The new KCC-64 WEB is compatible with the V5X, V4+S, V4+R and Mini VRF outdoor units and all kinds of indoor units except for the HRV and the Fresh Air Processing...
- Page 31 6. Scheduled Control Function Displayed in a list Displayed in a chart Click the icon indicated by ① . The scheduled operation interface is displayed. Scheduled operations can be displayed in a chart or in a list.
- Page 32 After parameters are set, click at the upper right corner to save the settings. 7 User Group Management 7-1 Inviting and Removing a User Select a KCC-64 WEB device from the list, and then click "Group Management". The following interface is displayed:...
- Page 33 ① "Invite User": If a QR code is displayed, a user can scan it to join the user group. The QR code is valid within 30 minutes. Up to 10 users can join one user group. ② "Remove User": Click it to remove a user from a user group.
- Page 34 7-2 Permission Management The figure above shows all the permissions of the members in a user group: "Invite/ Remove users", "Change device information", "Device control", "Area control", "Lock function", and "View operations log".
- Page 35 8. Operation Logs Click "Operation logs" on the left. The "Operation logs" interface is displayed, as shown in the following figure: ① "Device Operation Record" ② "Device Log" ③ "Login Record"...
- Page 36 8-1 Device Logs Device logs include status logs and malfunction logs: ① "Status Log": It displays gateway name, time, and status. ② "Malfunction Log": It displays device number, malfunction occurrence time, and error code.
- Page 37 8-2 Device Operation Records The "Device Operation Record" displays operation records of each device, including mode, operation time, user name, and execution status.
- Page 38 8-3 Login Records Login records are classified into App login records and Web login records: ① "APP": It displays login user name and login time via the App client. ② "Web": It displays login user name and login time via the Web client.
- Page 39 9. Account Management Click "Account Management". The account management interface is displayed, as shown in the following figure: ① Click the user name. The "Rename" dialog box is displayed. Enter a new name, and then click "Save". ② Click "Change Password". On the "Change Password" interface, enter the old and new passwords.
-
Page 40: Web Client Operation
KCC-64 WEB gateway is displayed. On a PC located in the same network segment of the KCC-64 WEB gateway, type the IP address of the KCC-64 WEB gateway into the browser's address bar. The embedded Web page of the KCC-64 WEB gateway is displayed: Click "Config."... -
Page 41: Remote Web Client Operation
VI. Remote Web Client Operation 1. Log in Browser support: IE 10 or above, Firefox, Chrome, Safari Operating systems: Windows7 or above, Mac OS Type http://www.aircontrolbase.com/login.html into the browser′s address bar. The login interface is displayed. Enter the registered email address in the "User name" text box and password in the "Password"... - Page 43 2. Function areas ① It is a function list. It lists "Device Control", "Booking Control", "Operation logs", and "User group". ② It is a KCC-64 WEB list. It displays a list of KCC-64 WEB gateways configured via the App client. Up to 10 gateways are supported. ③ It is an area display pane. It displays areas and the air conditioners in an area. ④...
- Page 44 3. Area Management 3-1 Area Control Function Click the area name ⑩ , the right area will display the control interface ① "Mode": sets mode. ② "Speed": sets fan speed. ③ "Swing": determines whether to enable swing mode. ④ "Lock": sets the item to be locked. ⑤...
- Page 45 3-2 Single Control Function of Air Conditioners The function list is the same as that of area control. Refer to the area control function. In single control mode, the user can select the air conditioner model, indicated by ① . The area on the left displays air conditioners, indicated by ②...
- Page 46 3-4 AC statistics and filter function AC states statistics Display: calculate the number of AC with different states in one KCC-64 WEB. The available states include: cooling, heating, fan only, off, lock and error. The auto mode is included in the cooling mode. AC states filer display: display the filtered AC in a state, which is from AC systems and different area For example: click ① Fan to filter the AC in fan mode from different area.
- Page 47 4-1 Main Interface The main interface displays scheduled operation type, device, scheduled time, mode, temperature, fan speed, week, and repeated or not. Click "Delete" to delete a scheduled operation. Click "Edit" to edit a scheduled operation. Click "Add" to add a scheduled operation.
- Page 48 1. "Timer start": On this tab page, set scheduled time, device, mode, temperature, fan speed, and week, and determine whether to repeat this scheduled operation. 2. "Timer shutdown": On this tab page, set scheduled time, device, week, and determine whether to repeat this scheduled operation. 5.
- Page 49 5-1 Operation Records The items displayed on the "Operation Record" tab page are the same as those displayed on the App client, including mode, time, user name, and execution results. 5-2 Status Logs The "Status Log" tab page displays online statuses of air conditioners.
- Page 50 5-3 Malfunction Logs The "Malfunction Log" tab page displays malfunction information and error codes. 5-4 Login Records Both "App Login Record" and "Web Login Record" tab pages list login information.
- Page 51 6. User Group Management ① Click it to display user group management. ② Click it to rename a group. ③ Click it to share a QR code. ④ It lists users. ⑤ Click it to set permissions. ⑥ It is a device management area.
- Page 52 6-2 Renaming a User Group Click "Rename" to rename the selected user group. 6-3 Inviting a User Click "QrCode" to generate a QR code of the user group. Up to 10 users are supported.
- Page 53 6-4 Deleting a User Group Click "Ungroup" to delete the selected user group. 7. setting Click ④ to enter into the setting interface ① modify unit of temperature: Celsius, Fahrenheit ② set supported languages: English, French and Spanish ③ modify of the login password...
