IR Swift+ Soundfield Quick Guide
+
The IR Swift is a wireless infra-red soundfield system which benefits
both students and tutor ‒ a few minutes of your time will help you
understand how and why the system works so well.
Try the system out with a colleague before using it in class. When setting the volume,
if you can hear your own voice clearly from the IR Swift
classroom then the volume is too loud! Make sure you experience the system by
listening to somebody else. Listening for yourself is the best way to understand why
the IR Swift+ system does not need to be set very loud to achieve an enhanced and
relaxing listening experience.
A soundfield system...
benefits the tutor
offering greatly reduced vocal
fatigue, improved class
discipline and attentiveness.
Less repetition is required and
there is a generally less
stressed teaching day.
+
Siting the IR Swift
+
The IR Swift unit is usually best positioned at the opposite end of the classroom to
the tutor, above seated head height. Although the IR Swift
dispersion speaker unit, when in use the system actually has two ʻspeakersʼ ‒ one is
+
the IR Swift and the other is yourself i.e. a sound source at both ends of the room.
When set up properly, a soundfield system will actually reduce the overall noise level
in a classroom and because there is no need to ʻtalk loudlyʼ it gives a clearer more
natural sound to your voice.
IR Swift+ remote volume adjust
The IR Swift+ has a remote volume adjust feature for use with a Swift
+
unit from across the
benefits the student
offering improved speech clarity and verbal
recognition for all class members including
those with permanent or temporary
hearing loss. Academic performance has
been shown to improve with the
introduction of a soundfield system.
+
is a single hyper-wide
transmitter.
TX
System components
IR Swif
The lecturer needs to use an IR transmitter to pick up their voice.
Swift transmitter
TX Our recommended choice is the Swift
is exceptionally light and easy to wear and has excellent sound pick up.
The handheld transmitter is ideal for group discussion or guest use.
A useful feature of the Swift
soundfield volume level to respond to changes in classroom activity.
The IR Swift
in use simultaneously.
Handheld
microphone
transmitter
IR Classmate Pendant
microphone transmitter
+
As the IR Swift operates from an external power supply, the
+
IR Swift automatically enters a low power standby state
when not in use. However, on environmental grounds, it is
still best to switch it off at the power socket when not in use.
+
Please refer to the IR Swift user guide for help with
connecting external equipment such as whiteboards, TV etc.
+
t transmitter ‒ 5 alternatives
pendant transmitter, because it
TX
is that you can remotely adjust the
TX
+
wall unit has two channels and can have two transmitters
Belt worn transmitter
Belt worn transmitter
with collarworn
with lavalier
microphone
microphone
The speaker
amplifier
There are six
controls on the
+
IR Swift amplifier.
Once set, these
controls are
normally left alone
and should rarely
need adjusting.
Aux in is for connecting an 'iPod, MP3 player,
laptop, PC etc. 3.5mm lead also included.
Connevans
Treble
Bass
Aux in
volume
Mic B
volume
Mic A
volume
Aux Out
adjust
Aux Out
socket
Aux In
socket
B45SWIFTQG2 V1.0
