Lanner V6S User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Vehicle Computing
V6S
User Manual
Version: 1.0
Date of Release: 2019-10-08
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the V6S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lanner V6S

Summary of Contents for Lanner V6S

  • Page 1 Vehicle Computing User Manual Version: 1.0 Date of Release: 2019-10-08...
  • Page 2 V6S User Manual The icons are used in the manual to serve as an indication of interest topics or important messages. Below is a description of these icons: Note: This mark indicates that there is a note of interest and is something that you should pay special attention to while using the product.
  • Page 3 This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
  • Page 4 V6S User Manual Suivez ces consignes pour assurer la sécurité générale : Laissez la zone du châssis propre et sans poussière pendant et après l’installation. Ne portez pas de vêtements amples ou de bijoux qui pourraient être pris dans le châssis. Attachez votre cravate ou écharpe et remontez vos manches.
  • Page 5 Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment to acceptable operating temperatures without adequate circulation. Be sure that the room in which you choose to operate your system has adequate air circulation. Ensure that the chassis cover is secure. The chassis design allows cooling air to circulate effectively. An open chassis permits air leaks, which may interrupt and redirect the flow of cooling air from internal components.
  • Page 6 The installation of this product must be performed by trained specialists; otherwise, a non-specialist might create the risk of the system’s falling to the ground or other damages. Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for supporting the system or use of inappropriate installation components.
  • Page 7 Loosen the screw of the earthing point. Connect the grounding cable to the ground. The protection device for the power source must provide 30 A current. This protection device must be connected to the power source before power. The cable hould 16 AWG Desserrez la vis du terminal de mise à...
  • Page 8 V6S User Manual Package Content ......................... 10 Ordering Information ......................... 11 System Specifications ......................... 11 Front Panel ..........................13 Rear Panel ..........................14 Block Diagram ..........................15 Internal Jumpers & Connectors ....................17 Installing the Disk Drive ......................22 Installing 4G Module ........................24 Installing SIM Cards ........................
  • Page 9 Connecting the Devices ......................76 Power States Cycle ........................77 Using the Ignition System Manager (ISM) .................. 78 Warranty Policy .......................... 79 RMA Service ..........................79 RMA Service Request Form ......................80...
  • Page 10 Designed for mobile surveillance, the new V6S series offers 1 x GbE RJ45 ports plus 10 x RJ-45 PoE ports for IP camera connection, and two removable 2.5” HDD/SSD drive bays for the storage of recorded footages.
  • Page 11 Chapter 1: Product Overview SKU No. Description Intel® Core i7-7600U in-vehicle Mobile NVR with 10x Intel GbE PoE and External 180w V6S-A DC power adapter for+9V~36Vdc input with Ignition Intel® Core™ i7-7600U 2.8GHz CPU onboard Up to 2.8 GHz Frequency...
  • Page 12 V6S User Manual -20~60°C / -4~140°F (without battery backup) Operating Temperature Environment 20~70°C / -4~158°F Storage Temperature 5%~95% @ 40°C / 104°F (Storage Level) Relative Humidity 273.8 x 219 x 92.2 mm (without mounting) 308 x 219 x 120.8 mm (with mounting) Dimension (W x H x D) 223 x 143.8 x 43.5 mm (LVP-936BAT01)
  • Page 13 Chapter 1: Product Overview HDD 2 HDD 1 Description HDD1 Status System Power PoE Status System Status LED Status Indicator Ignition Status GPO Status HDD2 Status USB 3.0 Port 2x USB 3.0 Type A USB 2.0 Port 2x USB 2.0 Type A GbE Port 1x RJ45 port with LED indicators For 2x SIM card...
  • Page 14 V6S User Manual PoE1 PoE3 PoE9 PoE5 PoE7 PoE2 PoE4 PoE10 PoE6 PoE8 Grounding Point: For safety measures to help prevent people from accidentally coming in contact with electrical hazards. Description 1x 3-pin terminal block for DC 9~36V external power source, GND and...
  • Page 15 Chapter 2: Motherboard Information The block diagram indicates how data flows among components on the motherboard. Please refer to the following figure for your motherboard’s layout design.
  • Page 16 V6S User Manual...
  • Page 17 Chapter 2: Motherboard Information mSATA: Pin No Description Pin No Description +3.3V +1.5V SATA_RXp +3.3V SATA_RXn +1.5V SATA_TXn MSATA1 SATA_TXp +3.3V +3.3V +1.5V +3.3V...
  • Page 18 V6S User Manual mPCIE1 for wifi: Supports Wi-Fi PCIe interface adapter Pin No Description Pin No Description +3.3V +1.5V CLKREQ# REFCLK- REFCLK+ PERST# PERn0 +3.3V PERp0 +1.5V PETn0 MPCIE1 PETp0 USB_D- USB_D+ +3.3V +3.3V LED_WWAN# LED_WLAN# +1.5V +3.3V...
  • Page 19 Chapter 2: Motherboard Information mPCIE2 for 4G/LTE Supports both 3G/4G and USB interface adapter Pin No Description Pin No Description +3.3V +1.5V CLKREQ# UIM_PWR UIM_DATA UIM_CLK UIM_RESET UIM_VPP PERST# USB3_RX- +3.3V USB3_RX+ +1.5V USB3_TX- mPCIE2 USB3_TX+ USB_D- USB_D+ +3.3V JKL;’ +3.3V LED_WWAN# LED_WLAN#...
  • Page 20 V6S User Manual SATAPWR1 Pin No Description HDD_LED1 HDD_LED2 COMS1: Clear CMOS Use the jumper setting to clear CMOS Description JCMOS1 Normal (Default) Clear CMOS JSPI1:SPI Interface(debug only) Pin No Description Pin No Description SPI_HOLD SPI_CS# SPI_VCC SPI_MISO SPI_CLK SPI_MOSI...
  • Page 21 Chapter 2: Motherboard Information JUSB1:USB2.0 Interface Pin No Description Pin No Description USB5- USB6- USB5+ USB6+ J11:MCU State(Program Only) Description Normal (Default) Program...
  • Page 22 V6S User Manual To reduce the risk of personal injury, electric shock, or damage to the unit, please remove all power connections to completely shut down the device. Also, please wear ESD protection gloves when conducting the steps in this chapter.
  • Page 23 Chapter 3: Hardware Setup 4. Lock the tray with the provided tray lock key. Lock...
  • Page 24 V6S User Manual This system comes with an external M.2 slot, supporting dual SIM design. The following will discuss the installation of 4G module and SIM cards. 1. Loosen the two screws that secure the tray and draw out the tray by its grip.
  • Page 25 Chapter 3: Hardware Setup The externally accessible SIM card readers on edge allow you to easily install or remove SIM cards with its push-in-bounce-out feature. 1. Loosen the screw that secures the cover onto the system. 2. Push the SIM cards into the socket. Make sure the angled corner of the card is positioned correctly as shown in this picture.
  • Page 26 V6S User Manual To enter the BIOS setup utility, simply follow the steps below: 1. Boot up the system. 2. Pressing the <Tab> or <Del> key immediately allows you to enter the Setup utility, then you will be directed to the BIOS main screen.
  • Page 27 Chapter 4: BIOS Setup Setup main page displays a description of BIOS information and project version information. You can also set up the System Time and System Date here. (The screenshots presented in the section are for reference only) Item Description BIOS Vendor: American Megatrends Core Version: AMI Kernel version, CRB code base, X64...
  • Page 28 V6S User Manual Select the Advanced menu item from the BIOS setup screen to enter the “Advanced” setup screen. Users can select any of the items in the left frame of the screen.
  • Page 29 Chapter 4: BIOS Setup...
  • Page 30 V6S User Manual Feature Options Description Software SW Guard Enabled Enable/Disable Software Guard Extensions (SGX). Extensions (SGX) Disabled CPU Flex Ratio Disabled Enable/Disable CPU Flex Ratio Programming. Override Enabled CPU Flex Ratio This value must be between Max Efficiency Ratio (LFM) Settings and Maximum non-turbo ratio set by Hardware (HFM).
  • Page 31 Chapter 4: BIOS Setup Disabled BIST Enable/Disable BIST (Built-In Self Test) on reset. Enabled HALT Loop AP threads Idle MWAIT Loop AP threads Idle Manner for waiting for the signal to run. Manner RUN Loop AP threads HALT Loop AP threads Handoff to OS Manner from the end of POST. Handoff Manner MWAIT Loop Disabled...
  • Page 32 V6S User Manual...
  • Page 33 Chapter 4: BIOS Setup CPU – Power Management Control Feature Options Description Non-Turbo Boot performance Performance Select the performance state that the BIOS will set mode Max Battery starting from reset vector. Turbo Performance Intel(R) Disabled Allows more than two frequency ranges to be supported. SpeedStep(tm) Enabled Enable/Disable Race To Halt feature.
  • Page 34 V6S User Manual...
  • Page 35 Chapter 4: BIOS Setup Firmware Update Configuration Feature Options Description Me FW Image Disabled Enable/Disable Me FW Image Re-Flash function. Re-Flash Enabled...
  • Page 36 V6S User Manual...
  • Page 37 Chapter 4: BIOS Setup Serial Port 1 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=3F8h; IRQ = 4; RS232 COM1 MODE RS485 COM RS-422/485 Support. RS422 COM1 Disabled COM RS-422/485 Receiver Termination. Termination Enabled...
  • Page 38 V6S User Manual Serial Port 2 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=2F8h; IRQ = 3; RS232 COM2 MODE RS485 COM RS-422/485 Support. RS422 COM2 Disabled COM RS-422/485 Receiver Termination.
  • Page 39 Chapter 4: BIOS Setup Serial Port 3 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=3E8h; IRQ = 5;...
  • Page 40 V6S User Manual Serial Port 4 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=2E8h; IRQ = 11;...
  • Page 41 Chapter 4: BIOS Setup Serial Port 5 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=2F0h; IRQ = 7;...
  • Page 42 V6S User Manual Serial Port 6 Configuration Feature Options Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled Device Settings IO=2E0h; IRQ =10 ;...
  • Page 43 Chapter 4: BIOS Setup...
  • Page 44 V6S User Manual Feature Options Description SIM-2 SIM Selector1 Select Which SIM card would use. SIM-1 SIM-3 SIM Selector2 Select Which SIM card would use. SIM-4...
  • Page 45 Chapter 4: BIOS Setup Feature Options Description COM1 Disabled Console Console Redirection Enable or Disable. Enabled Redirection...
  • Page 46 V6S User Manual Console Redirection Settings Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, function keys, VT100+ etc. Terminal Type VT-UTF8 VT-UTF8:Uses UTF8 encoding to map Unicode chars ANSI onto 1 or more bytes ANSI: Extended ASCII char set...
  • Page 47 Chapter 4: BIOS Setup Hardware RTS/CTS VT-UTF8 Combo Disabled Enables VT-UTF8 Combination Support Key Support Enabled ANSI/VT100 terminals Disabled With this mode enabled, only text will be sent. This is to Recorder Mode Enabled capture Terminal data. Disabled Resolution 100x31 Enables or disables extended terminal resolution Enabled VT100...
  • Page 48 V6S User Manual Legacy Console Redirection Settings Feature Options Description Redirection COM COM1 Select a COM port to display redirection of Legacy OS Port and Legacy OPROM Messages. 80x24 On Legacy OS, the Number of Rows and Columns Resolution 80x25 supported redirection.
  • Page 49 Chapter 4: BIOS Setup...
  • Page 50 V6S User Manual Feature Options Description Globally Enables or Disables 64bit capable Devices to be Above 4G Disabled Decoded in Above 4G Address Space (Only if System Decoding Enabled Supports 64 bit PCI Decoding).
  • Page 51 Chapter 4: BIOS Setup Feature Options Description Disabled Network Stack Enables or disables UEFI Network Stack Enabled...
  • Page 52 V6S User Manual Feature Options Description Disabled CSM Support Enables or disables CSM Support Enabled Do Not Launch Network UEFI Controls the execution of UEFI and Legacy PXE OpROM Legacy Do Not Launch Controls the execution of UEFI and Legacy Storage...
  • Page 53 Chapter 4: BIOS Setup...
  • Page 54 V6S User Manual Feature Options Description Enables Legacy USB support. Enabled Auto option disables legacy support if no USB devices Legacy USB Disabled are connected; Support Auto Disabled option will keep USB devices available only for EFI applications. USB Mass Storage Disabled Enables or disables USB Mass Storage Driver Support.
  • Page 55 Chapter 4: BIOS Setup Select the Chipset menu item from the BIOS setup screen to enter the Platform Setup screen. Users can select any of the items in the left frame of the screen.
  • Page 56 V6S User Manual Feature Options Description Disabled VT-d VT-d capability Enabled Enable/Disable above 4GB Memory Mapped IO BIOS Above 4GB MMIO Enabled assignment. This is enabled automatically when Aperture BIOS assignment Disabled Size is set to 2048MB. Enabled X2APIC Opt Out...
  • Page 57 Chapter 4: BIOS Setup Memory Configuration...
  • Page 58 V6S User Manual Feature Options Description Auto Maximum 1067 Memory Maximum Memory Frequency Selections in Mhz. Frequency 3733 Dynamic Maximum Value of TOLUD. The dynamic assignment 1 GB Max TOLUD would adjust TOLUD automatically based on largest MMIO length of installed graphic controller...
  • Page 59 Chapter 4: BIOS Setup Feature Options Description Quiet Serial IRQ Mode Configure Serial IRQ Mode. Continuous...
  • Page 60 V6S User Manual PCI Express Configuration...
  • Page 61 Chapter 4: BIOS Setup PCI Express Root Port 1 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 1 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM AUTO - BIOS auto configure DISABLE - Disables ASPM Disabled...
  • Page 62 V6S User Manual PCI Express Root Port 2 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 2 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM...
  • Page 63 Chapter 4: BIOS Setup PCI Express Root Port 3 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 3 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM AUTO - BIOS auto configure DISABLE - Disables ASPM Disabled...
  • Page 64 V6S User Manual PCI Express Root Port 4 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 4 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM...
  • Page 65 Chapter 4: BIOS Setup PCI Express Root Port 9 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 9 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM AUTO - BIOS auto configure DISABLE - Disables ASPM Disabled...
  • Page 66 V6S User Manual PCI Express Root Port 10 Feature Options Description PCI Express Root Disabled Control the PCI Express Root Port. Port 10 Enabled Auto L0sL1 Set the ASPM Level: Force L0s - Force all links to L0s State ASPM...
  • Page 67 Chapter 4: BIOS Setup SATA And RST Configuration...
  • Page 68 V6S User Manual Feature Options Description Enabled SATA Controller(s) Enable/Disable SATA Device. Disabled SATA Mode AHCI Determines how SATA controller(s) operate. Selection Intel RST Disabled Port 0/1/2 Enable or Disable SATA Port Enabled Disabled Hot Plug Designates this port as Hot Pluggable.
  • Page 69 Chapter 4: BIOS Setup Security Configuration Feature Options Description Disabled Enable will lock bytes 38h-3Fh in the lower/upper RTC Lock Enabled 128-byte bank of RTC RAM Enable/Disable the PCH BIOS Lock Enable feature. Disabled BIOS Lock Required to be enabled to ensure SMM protection Enabled of flash.
  • Page 70 V6S User Manual Select the Security menu item from the BIOS setup screen to enter the Security Setup screen. Users can select any of the items in the left frame of the screen. Feature Description If ONLY the Administrator's password is set, it only limits Administrator Password access to Setup and is only asked for when entering Setup.
  • Page 71 Chapter 4: BIOS Setup Feature Option Description Secure Boot is activated when Platform Key(PK) is Disabled Secure Boot enrolled, System mode is User/Deployed, and CSM Enabled function is disabled. Customizable Secure Boot mode: In Custom mode, Secure Boot Standard Secure Boot Policy variables can be configured by a Customization Custom physically present user without full authentication.
  • Page 72 V6S User Manual Key Management Feature Options Description Factory Key Disabled Provision factory default keys on next re-boot only Provision Enabled when System in Setup Mode. Force System to User Mode. Configure NVRAM to Restore Factory None contain OEM-defined factory default Secure Boot keys keys.
  • Page 73 Chapter 4: BIOS Setup Select the Boot menu item from the BIOS setup screen to enter the Boot Setup screen. Users can select any of the items in the left frame of the screen. Feature Options Description The number of seconds to wait for the setup Setup Prompt Timeout activation key.
  • Page 74 V6S User Manual Select the Save and Exit menu item from the BIOS setup screen to enter the Save and Exit Setup screen. Users can select any of the items in the left frame of the screen. ■ Discard Changes and Exit Select this option to quit Setup without saving any modifications to the system configuration.
  • Page 75 Appendix A: LED Indicator Explanations The status explanations of LED indicators on the Front Panel are as follows: System Power Solid Green The system is powered on The system is powered off Ignition Status Solid Green The system is powered on Ignition control Ignition control is disabled HDD1 /HDD2 Status Blinking Amber...
  • Page 76 V6S User Manual The system comes with a controller to ensure that the device is well-shielded against premature failure at the boot or shutdown phase. When installing: 1. Make sure both your vehicle and the system are turned off. 2. Follow the wiring definition and illustration below to connect the vehicle battery and ignition (ACC) to the in-vehicle system through the 4-pin terminal block connector marked as “DC Input 9-36V”, and...
  • Page 77 Appendix B: Ignition Control Setup The diagram below describes the cycle of the system’s power states controlled by the Ignition System Manager (ISM) when the appropriate timer control parameters are set. (by ISM tool) System OS Running Ignition board supplies power to the main board (by ISM tool) Note: When the system’s shutdown timer starts counting down 180sec, using ignition or External PWR_BTN...
  • Page 78 V6S User Manual The Ignition System Manager (ISM) is a software tool that can monitor the system’s voltage level and configure the vehicle’s Power Ignition related features. To start, Make sure both your vehicle and the system are turned off.
  • Page 79 Appendix C: Terms and Conditions 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period; whereas the manufacturer will bear the after service freight charges for goods returned to the user.
  • Page 80 V6S User Manual When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
