Summary of Contents for ALERTUS TTS Speaker
- Page 1 TTS Speaker Installation/Guide This guide provides typical installation instructions. Please bear in mind that building codes vary and the technician installing the TTS Speaker units is responsible for compliance with any relevant codes. Version number: 000001...
-
Page 2: Specifications
TTS Speaker Installation/Guide This guide provides typical installation instructions. Please bear in mind that building codes vary and the technician installing the TTS Speaker units is responsible for compliance with any relevant codes. Specifications ● Dimensions: 7" H x 10.3" W x 3.8" D, wall mounted. - Page 3 Connecting Communications from Alert Beacon The TTS Speaker connects to the RS-232 serial port of an Alert Beacon using a DB9 to RJ-45 cable, pictured at below. Connect the RJ-45 end of the cable to socket '2' as shown on the connection diagram below. Connect the...
-
Page 4: Adjusting The Volume
But, for custom parts you must call them (you can't place an order online). Adjusting the Volume The volume of the TTS Speaker is controlled by a knob located behind the mesh grill on the front of the unit. To adjust the volume: ●... - Page 5 Appendix: Dimensional Drawings...
