T804 WIFI SYSTEM INSTRUCTIONS
Your new T804 WiFi Transmitter System
The T804 WiFi System (part number TC80461011) transmits High Defini-
tion Video to any Smart Device. Our App uses the Smart Devices' capabili-
ties to share Video and Snapshots and to produce on-site reports
Direct-to-customer Reporting
Video and Snapshots automatically saved to the Cloud
Compatible with IOS, Android and Windows devices
Video and Snapshots can be shared using many methods
Automatically connects to the Smart Device when in the field
Troglotech T804 WiFi System INSTRUCTIONS Page 1
Troglotech Ltd
Unit 1, 3 Penns Road
Petersfield
Hampshire
GU32 2EW
Phone +44(0)1730 711240
Phone +44(0)1730 711240
Fax
+44 (0)1730 711240
Email info@troglotech.com
Web www.troglotech.com
Advertisement
Table of Contents
Related Manuals for Troglotech T804 WiFi System
Summary of Contents for Troglotech T804 WiFi System
- Page 1 Video and Snapshots automatically saved to the Cloud Compatible with IOS, Android and Windows devices Video and Snapshots can be shared using many methods Automatically connects to the Smart Device when in the field Troglotech T804 WiFi System INSTRUCTIONS Page 1...
- Page 2 Fit the end of the cable to the EXT VIDEO socket on the Display Unit and clip the cable as shown above - ensure there are no tight bends of the cable as the Display Unit is put in the upright position. Switch the T804 ON Troglotech T804 WiFi System INSTRUCTIONS Page 2...
- Page 3 INITIAL SETUP - INSTALL APP The links to the smart-device App can be found on our website (Troglotech.com) on the ‘Camera heads and accessories’ page. The picture above left is a screenshot of the webpage and shows two icons, the left icon is for Android and the right icon is for Apple (IOS) devices.
- Page 4 INITIAL SETUP - REGISTER TROGLOTECH WIFI On the smart-device click on Settings-Connections-Wi-Fi. Wait for the WiFi list to refresh and then click on ‘Troglotech’ The password is ‘12345678’, enter this and then click ‘CONNECT’. Select ‘KEEP WI-FI CONNECTION and then close the settings windows.
- Page 5 INITAIL SETUP - TEST SYSTEM Once you are connected to the Troglotech WiFi System open the CAM802 App. The picture to the right shows the CAM802 App running and de- scribes the function of the main buttons. Pressing SNAPSHOT will take a picture of the live video from the T804 and it will be stored on the smart-device.
- Page 6 T804 WIFI - USING THE SYSTEM IN THE FIELD When operating the system in the field your smart-device should automatically connect to the Troglotech WiFi System a few seconds after the T804 is switched ON. Check the connection in Settings/ Connections/WiFi to ensure this is the case.
- Page 7 With Google Photos installed, all video and snapshots will be automatically uploaded to Google’s Cloud. The files will be available on any device that has Google Photos installed (such as a PC, Laptop or other smart-device). Troglotech T804 WiFi System INSTRUCTIONS Page 7...
- Page 8 However, when mobile data is available then any video or snapshot that is taken by the Troglotech system can be shared directly with the customer and the office. It is not recommended to record full surveys on a smart-device as saving large video files takes a lot of resources.
