Summary of Contents for RKR BMX
- Page 2 ... and for choosing RKR BMX, you have chosen wisely! RKR is very different from other mini bike brands on the market; It was designed by riders, for riders and is the product of many years experience in the BMX industry. This means it’s tough, VERY tough and it works.
- Page 3 Once all packaging has tents. It should look something like been removed, lay out the main the picture below. RKR assembly and loose components and have a visual check for any significant shipping damage. Please note: There may be minor scratches as a result of the courier’s heavy handedness, this is a fact of mail order that sadly cannot be avoided.
- Page 4 You should now have the main RKR To make life easier, we are going BMX assembly, some bars with pre to install the pedals first. Thread installed grips, a pair of pedals (one the left pedal (stickered ‘L’) into the stickered ‘L’, the other stickered ‘R’)
- Page 5 With the left pedal installed you can Now, carefully remove the stem now stand the bike up using the faceplate bolts (X4) with a 6mm pedal as a bike stand. This makes Allen key (their location is indicated the job a lot easier. Now install the in the above image).
- Page 6 Once the faceplate starts to bite Check the front wheel alignment on the bars, spin them up into your and adjust as necessary (your stem desired position and finally clamp rear pinch bolts should still be loose down the faceplate nice and tight. at this stage.
- Page 7 (stem pinch bolts MUST be loose during this operation then re-tightened to check for headset play). Irok+ and RKR 3+ pre-load bolts differ from each other. You will be able to clearly see the hex for the Irok+ pre-load bolt after removing the dust cap.
- Page 8 If you have purchased an Irok+ Irok+ models come fitted with a Coaster or a RKR 3+/Reggie then freewheel from factory. your bike has come fitted with a free coaster. We suggest, for the 9t drive rear wheels are available first few rides while you get used from our website.
- Page 9 RKR 3+ models use a 3 piece crank and true. Tight spots in your chain system with a sealed mid bottom will indicate incorrect centering of bracket (BB).
- Page 10 Irok+ models use a freewheel and thus the chain should NOT be as tight as it would be on a normal BMX with a ‘driver’. This will significantly slow down your rear wheels free spin. Please see photo, the chain should be...
- Page 11 Finally you are ready to test ride If you need to repair a puncture at your RKR BMX! Before you do so, any stage, please note that you will make sure your tyres are pumped need to split the rim to get the tyre up to the desired pressure.
- Page 12 Installation Instructions for Additional Road Kit: Items included in your road kit (where supplied) : • Chain Guard with fixings • Front clear reflector • Rear red reflector • 4x pedal reflectors • 4x rim reflector stickers Install the chain guard using the fixings provided. There are two clamps which need to be fixed onto the downtube and chain stay.
- Page 13 Fix front reflector on the crossbar Fix the rear reflector onto the seat of the handlebars, and tighten until stay as shown in a suitable position. secure. Rotate the pedal gently with your foot in your chosen riding posi- tion and check it does not hit the reflector.
- Page 14 Fix the 4 pedal reflectors to the Apply the 4 reflective rim tape front a rear side of the pedals. stickers to each wheel on either Press the reflector in firmly until it side. clicks.
- Page 15 Your road kit is now fully installed and your Rocker is ready to ride.
- Page 16 Thanks for reading this manual, now get riding/ learning some new tricks on your RKR! Please tag us in any pics or video clips you may post on instagram, we are always interested to see what you have been up too and what you...
