Summary of Contents for Freedom Motors REAR-ENTRY CONVERSION
- Page 3 Freedom Motors reserves the right to make changes in design and specifications, and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.
-
Page 4: Table Of Contents
TABLE CONTENT INTRODUCTION ......................1 SAFETY PRECAUTIONS ..................2 REMOTE KEYLESS ENTRY TRANSMITTER ..........3 CONTROL SWITCHES ..................4 OPERATION INSTRUCTIONS ................5 SEATING SECURMENT ..................6 MANUAL OPERATION ..................7 BENCH SECUREMENT ..................8 BENCH SECUREMENT ..................9 TRANSFER SEAT OPERATIONS ..............10 EZ LOCK OPERATIONS ..................11 EZ LOCK OPERATIONS ..................12 SCHEDULED MAINTENANCE ................. -
Page 5: Introduction
INTRODUCTION CONGRATULATION ON PURCHASING YOUR NEW REAR ENTRY KNEELVAN CONVERSION VAN WITH FREEDOM MOTORS. Please take the time to read these publications carefully. Following the instructions and recommendations in this manual will help assure safe and enjoyable operation of your vehicle. When it comes to service, remember that your authorized dealer knows your vehicle best, has factory-trained technicians and cares about your satisfaction. -
Page 6: Safety Precautions
Freedom Motors directly at 1.888.625.6335 • Read your owner’s manual before operating the vehicle. In addition to reading the manual, please make sure your Freedom Motors salesperson explains and demonstrates the vans features before operating. • Before operating the ramp make sure the vans transmission is in park •... -
Page 7: Remote Keyless Entry Transmitter
REMOTE KEYLESS ENTRY Keyless Entry Transmitter Open Function Pressing and holding button 1 will open the rear door and deploy the ramp. Releasing the button will halt the ramp opening and can be moved manually if desired. Close Function Pressing and holding button 2 will retract the ramp and close the rear door. -
Page 8: Control Switches
CONTROL SWITCHES Ramp Deploy / Retract Switch The drivers ramp deploy / retract switch WARNING is located on the dashboard on the left DO NOT retract the ramp if a person or object side of the steering is on the ramp. This could cause ramp system wheel. -
Page 9: Operation Instructions
OPERATION INSTRUCTIONS WARNING Before operating the power door and power ramp, make sure the passenger back area of the vehicle is clear and unobstructed. Allow approximately 8 feet for the ramp to deploy beyond the back of the vehicle plus and additional 4 feet for the wheelchair occupant to maneuver. -
Page 10: Seating Securment
SEATING SECUREMENT Instructions For Use: 1. Place wheelchair in the vehicle facing forward and in a suitable position. 2. Preselect a position on the wheelchair to attach the hook and a position on the floor to attach the floor latch end of the strap 3. -
Page 11: Manual Operation
MANUAL OPERATION Operate Door Manually With the ramp in the fully stowed position, the back door may be opened or closed manually at any time. If automatic conversion ceases to operate you can manually deploy / retract the ramp. 1. Place the vehicle transmission in park 2. -
Page 12: Bench Securement
BENCH SECUREMENT Rear Bench Operation Note: This section only applies if your Kneelvan has been equipped with a third-row two-passenger fold down bench. Preparing the bench for use: 1: Release the Anti-Rattle lever located at bottom of the bench. 2: Release the Fold Down lever and carefully allow the bench to fold over until it locks into place. 3: Release the Back Rest lever and fold the back rest up until it locks into place. -
Page 13: Bench Securement
BENCH SECUREMENT Rear Bench Operation... -
Page 14: Transfer Seat Operations
Operating your transfer seat TRANSFER SEAT OPERATION Note: this section only applies if your Kneelvan has been equipped with a driver-side or passenger-side Power Transfer Seat. To use your Kneelvan’s Power transfer Seat: Make sure your chair or scooter is locked down and secured before attempting to transfer seats. Ensure that the transfer seat has been slid completely forward using the OEM control (usually a bar or lever under the seat, or power controls) before operation. -
Page 15: Ez Lock Operations
Thank you choosing the EZ Lock W heelchair Docking System ; Am erica’s #1 choice for quality and dependability. Before attem pting EZ LOCK OPERATION to use your EZ Lock W heelchair Docking System , be sure to fam iliarize yourself with the equipm ent and ensure that you thoroughly understand the proper m ethod of docking system operation. -
Page 16: Ez Lock Operations
CUT THE VEHICLES IG NITIO N SW ITCH O FF AND PRESS THE RELEASE SW ITCH O N THE CO NTRO L PANEL. The locking levers in the docking base will disengage and hold open for five seconds allowing you to exit the system . THE DO CKING SYSTEM W ILL NO T RELEASE THE W HEELCHAIR W ITH THE VEHICLE’S IG NITIO N O N;... -
Page 17: Scheduled Maintenance
SCHEDULED MAINTENANCE Scheduled Maintenance Plan Power Door System • Check proper door operation. Adjust door and/or limit switch as necessary Ramp System • Inspect ramp mechanism for loose fittings, alignment and abnormal wear • Clean and lubricate ramp drive mechanisms •... -
Page 18: Maintenance Log
MAINTENANCE LOG Record maintenance information in the table below Date: Date: Description: Description:... -
Page 19: Maintenance Log
MAINTENANCE LOG Date: Date: Description: Description:... -
Page 20: Warranty
WARRANTY FREEDOM MOTORS USA, INCORPORATED CONVERSION COMPONENT LIMITED WARRANTY Freedom Motors USA, Incorporated (“FMI”) provides a comprehensive Conversion Component Limited Warranty (“Warranty”). This Warranty is designed to work with any applicable Original Equipment Manufacturer (“OEM”) factory warranty. WHAT IS COVERED? This Warranty gives you specific legal rights. - Page 21 - Wheelchair accessible commercial and handicap accessible taxi conversions are warranted for 12 months or 12,000 miles, whichever occurs first; - Pre-owned Freedom Motors conversions sold by Freedom Motors are warranted for 12 months or 12,000 miles, whichever occurs first;...
- Page 22 WARRANTY Damage Caused by Use and/or the Environment The Warranty does not cover surface rust, deterioration and damage to paint, trim, upholstery, and other appearance items of the conversion components that result from use and/or exposure to the elements. You, as the owner, are responsible for these items. Some examples are: -Dings and dents -Cuts, burns, punctures or tears -Road salt...
- Page 23 WARRANTY Fmi is not responsible for any time or income that you lose, any inconvenience you might be caused, the loss of your transportation or use of your vehicle, the cost of rental vehicles, fuel, telephone, travel, meals, or lodging, the loss of personal or commercial property, the loss of revenue, or for any other incidental or consequential damages you may have.
- Page 25 Freedom Motors USA Inc. 740 Watkins Rd. Battle Creek, MI 49015 Phone 1.800.625.6335 Fax 269.660.5825...
