Summary of Contents for iKAMPER WIND DEFLECTOR
- Page 1 WIND DEFLECTOR ASSEMBLY...
- Page 2 Instructions Included parts:...
- Page 3 Remove the protective vinyl covering from panel [A]. STEP 2 Take rubber strap [B] and wrap it around panel [A]. The harder rubber side should be facing the front of panel [A] with the iKamper logo, with the softer rubber side facing the back. STEP 3...
- Page 4 STEP 4 Take metal piece [C] and place the short side over bolt [F]. Then screw on head nut [H], and repeat for the other two bolts. STEP 5 Slide 3 long bolts [G] into the side of rail [D].
- Page 5 STEP 6 Place rail [D] over the 3 metal pieces [C], insert the 3 bolts [G], and screw on the 3 head nuts [H]. The thicker end of rail [D] should be facing panel [A]. STEP 7 Screw square nuts [J] on to bolts [K], and insert them in the holes on top of rail [D].
- Page 6 STEP 8 - Remove the two plastic pieces covering the front of rails under the Skycamp. - Insert the square nuts [J] into the rails, choose the appropriate position, and tightly screw on the head nuts. - Put the cover pieces back in place in front of the rails. STEP 9 Place the 2 plastic pieces [E] on the sides of rail [D].
- Page 7 STEP 10 Adjust the height and position of the Wind Deflector by unscrewing the head nuts [I] and tightening them once the Wind Deflector is in the right position. For more instructions and explanation videos, please visit www.ikamper.com/instructions www.ikamper.com...
