- Page 1 Outdoor-rated RGBW LED batten and 15 x 1 pixel mappable matrix...
-
Page 2: Warnings And Installation Precautions
WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with . -
Page 3: Table Of Contents
TABLE OF CONTENTS Safety General instructions Warnings and installation precautions General information 1 Introduction 1.2 Maintenance Cleaning the unit Trouble shooting 1. 3 Operating elements and connections 2 Installation 2. 1 Mounting 2.2 Dimensions 3 Functions and settings 3. 1 Operation 3. -
Page 4: Introduction
INTRODUCTION The FUSIONBAR QXV is an outdoor-rated Quad-color (4-in-one) RGBW one-meter LED batten that delivers vibrant linear color washes and an individually controllable 15 x 1 pixel matrix. FEATURES - Deep, saturated, perfectly-mixed colors for wall grazing and linear washes - Rugged diecast body and production-grade construction - Color and white presets available via onboard menu or DMX - Silent operation with advanced fanless thermal management... -
Page 5: Maintenance
- 1.2 - MAINTENANCE MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • All screws used for installing the device and any of its parts should be tightly fastened and should not be corroded. -
Page 6: Operating Elements And Connections
1.3 OPERATING ELEMENTS AND CONNECTIONS Gore valve Safety cable anchor DMX In Quick-Lock Omega Clamp Power In Mounts Mounting DMX Out bracket Power Out OLED display and Tilt Menu navigation locking knob Rear view 1. TILT LOCKING KNOB 6. SAFETY CABLE ANCHOR 2. - Page 7 2.2 DIMENSIONS diameter 13...
-
Page 8: Installation
- 2 - INSTALLATION 2.1 MOUNTING FUSIONBAR QXV may be surface-mounted to an even and be able to support a weight of 10 times of the unit’s weight. When carrying out any installation, always comply scrupulously with all the regulations (particularly re- •... -
Page 9: Functions And Settings
- 3 - FUNCTIONS AND SETTINGS 3.1 OPERATION Connect the supplied main cable to a socket (100-240V~/50-60Hz). Then the unit is ready for operation and can be operated via a DMX controller or it independently performs its show program in succession. 3.2 BASIC Access control panel functions using the four panel buttons located adjacent to the OLED display. -
Page 10: Menu Structure
3.3 MENU STRUCTURE Main Menu Submenu Submenu Default settings DMX Address <001 ~ 512> 4 Ch 6 Ch DMX Channel 10 CH 10 Ch 60 Ch 65 Ch Fixed Color Static RGBW <0-255> Green <0-255> Manual Color Mixer RGBW=255 Blue <0-255>... - Page 11 Outdoor-rated RGBW LED batten and 15 x 1 pixel mappable matrix...
- Page 12 WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with .
-
Page 13: Master/Slave Mode
TABLE OF CONTENTS Safety General instructions Warnings and installation precautions General information 1 Introduction 1.2 Maintenance Cleaning the unit Trouble shooting 1. 3 Operating elements and connections 2 Installation 2. 1 Mounting 2.2 Dimensions 3 Functions and settings 3. 1 Operation 3. -
Page 14: Introduction
INTRODUCTION The FUSIONBAR QXV is an outdoor-rated Quad-color (4-in-one) RGBW one-meter LED batten that delivers vibrant linear color washes and an individually controllable 15 x 1 pixel matrix. FEATURES - Deep, saturated, perfectly-mixed colors for wall grazing and linear washes - Rugged diecast body and production-grade construction - Color and white presets available via onboard menu or DMX - Silent operation with advanced fanless thermal management... -
Page 15: Maintenance
- 1.2 - MAINTENANCE MAINTENANCE AND CLEANING THE UNIT • Make sure the area below the installation place is free from unwanted persons during setup. • All screws used for installing the device and any of its parts should be tightly fastened and should not be corroded. -
Page 16: Operating Elements And Connections
1.3 OPERATING ELEMENTS AND CONNECTIONS Gore valve Safety cable anchor DMX In Quick-Lock Omega Clamp Power In Mounts Mounting DMX Out bracket Power Out OLED display and Tilt Menu navigation locking knob Rear view 1. TILT LOCKING KNOB 6. SAFETY CABLE ANCHOR 2. -
Page 17: Dimensions
2.2 DIMENSIONS diameter 13... - Page 18 - 2 - INSTALLATION 2.1 MOUNTING FUSIONBAR QXV may be surface-mounted to an even and be able to support a weight of 10 times of the unit’s weight. When carrying out any installation, always comply scrupulously with all the regulations (particularly re- •...
-
Page 19: Functions And Settings
- 3 - FUNCTIONS AND SETTINGS 3.1 OPERATION Connect the supplied main cable to a socket (100-240V~/50-60Hz). Then the unit is ready for operation and can be operated via a DMX controller or it independently performs its show program in succession. 3.2 BASIC Access control panel functions using the four panel buttons located adjacent to the OLED display. -
Page 20: Menu Structure
3.3 MENU STRUCTURE Main Menu Submenu Submenu Default settings DMX Address <001 ~ 512> 4 Ch 6 Ch DMX Channel 10 CH 10 Ch 60 Ch 65 Ch Fixed Color Static RGBW <0-255> Green <0-255> Manual Color Mixer RGBW=255 Blue <0-255>...
