Summary of Contents for Linsar LS58UHDSM20
- Page 1 58" Ultra HD Smart TV MODEL: LS58UHDSM20 User Manual...
-
Page 2: Welcome
Please take special note of any important safety and usage information presented with the symbol. All products brought to you by Linsar are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by a comprehensive... -
Page 3: Table Of Contents
Contents Welcome On-Screen Set Up Screencast App Portals Contents Networking TV Guide Connecting to a Wireless Network 17 Unpack and Prepare Connecting to a Wired Network PVR Recording What's in the box TV Setting Menus Recording Live TV Important Tips Scheduled recording Picture Attaching the stand... -
Page 4: Unpack And Prepare
Unpack and Prepare See the flap of the box for how to handle the TV What's in the box without damaging it! Before installing your new TV, check you have everything needed. In the box you will find: A. UHD Smart TV B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the stand • This TV is heavy! We recommend asking someone to help you lift it. • Unplug the TV from the power outlet before installing or removing the stand. • DO NOT place the TV standing upright without its stand attached;... -
Page 7: Wall-Mounting The Tv
Wall-mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required: 200mm • VESA Mounting Bracket • 4 x M6*8mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your antenna Free-to-air TV in HD (High Definition) High Definition (HD) channels... -
Page 9: Controls And Connections
Controls and Connections Get to know your TV On/Standby indicator and Remote sensor Buttons on the TV (ON/OFF): Switch the TV to On or Standby. 4. VOL + / VOL - : Increase or decrease the volume level, or move left or right. 2. -
Page 10: Ports On The Tv
Ports on the TV HDMI Use a high All-digital connection between the TV and any HDMI device. speed HDMI Supports 4K UHD. Requires an HDMI cable (not included). cable for best picture and sound quality. Plug in a USB stick/drive to PVR record and pause live TV. Play media files stored on your USB storage device (supported file codecs and extensions may vary). - Page 11 Headphone Connect to your headphones, amplifier, soundbar or audio Jack device, using an AUX cable (not included). Digtal Audio Connect an external digital audio device. Use an Optical cable (not included) to connect the unit with an amplifier, soundbar Out (Optical) or other audio decoding device for digital audio signal output.
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+ / -) inside the compartment. Make sure AAA size the batteries are correctly aligned and properly batteries pushed into place. included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the TV. The remote will not operate if its path is blocked. The remote has a range of up to about 5 metres from Remote Hints and Tips the TV at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 14: Remote Control
Remote Control AUDIO INFO QMENU MENU EXIT GUIDE LIST SOURCE (MUTE): Mute or restore ON: Switch the TV to On or sound. Standby. AUDIO : Select an audio NUMBER BUTTONS: Key in a language (if available). TV channel number. RED/ INFO: Display program GREEN/YELLOW/BLUE: information. - Page 15 AUDIO INFO QMENU MENU EXIT MENU EXIT GUIDE LIST SOURCE LIST: Display or exit GUIDE LIST the channel list. GUIDE: Launch the TV Guide. SOURCE : Go to the next or : Turn the volume up or previous channel. down. : Teletext (not available in Australia).
-
Page 16: On-Screen Set Up
On-Screen Set Up Make sure equipment is properly connected (as shown on pages 10-11) before connecting the TV to power. Make sure the TV is plugged in at the power socket and switched on. Press the (ON) button to turn on the TV. On/Standby light is RED in standby mode. -
Page 17: Networking
Networking You can set up your TV so that it can access the Internet If the TV isn't through your home network using a wired or wireless connecting to the connection. internet check the troubleshooting section for more info! Connecting to a Wireless Network MENU button on the remote to select •... -
Page 18: Connecting To A Wired Network
Connecting to a Wired Network • Connect an ethernet cable to the LAN port on the back of the TV. • Press the MENU button on your remote to select Option > Network Configuration. • Change the Connection Type setting to 'LAN'. The TV will automatically pick up the network setting from the modem and connect to the network. -
Page 19: Tv Setting Menus
TV Setting Menus Once you have AUDIO INFO programmed any settings, QMENU the unit will retain them MENU EXIT GUIDE LIST in its memory until you SOURCE Menu Navigation Buttons change them, even after turning the TV off. Press the MENU button to display the TV settings Menus Index menu. - Page 20 Time • View End User License Function • Noise Reduction • Off Time • Subtitle • MPEG Noise Reduction • On Time • HBBTV • Aspect Ratio • Sleep Timer Lock • PVR File System • Auto Sleep • Lock System •...
-
Page 21: Picture
Picture To adjust the Picture Mode brightness, change the Picture Mode to Dynamic : Enhanced brightness with lower contrast, colour depth and edges. User and modify the Brightness setting. Home : Default picture settings for viewing in a home environment. Bright Room : Enhanced picture brightness for bright home environments Personal... -
Page 22: Sound
Sound Option Description Sound Mode Standard Music Movie Sports Personal Equaliser Adjust selected audio frequencies. This is only adjustable in "User" mode Balance Adjust the audio output between the left and right speakers. Adjust the increase or decrease of audio when you change channels, video sources or content. -
Page 23: Function
Function Option Description Noise Reduces screen noise/static. Reduction MPEG Noise Reduces MPEG (video) noise to improve picture quality. Reduction Adjust the video size. The available video size may be different for different input source. Aspect ratio PVR File See the next page for more details. System HDMI_CEC See page 25 for more details. -
Page 24: Pvr Settings
PVR Settings To make changes to PVR (Personal Video Recording), ensure your USB drive is inserted into the TV. Check the troublehsooting section if you're having problems setting up your USB device. Option Description Select Disk Select a disk used for PVR. Select the memory size for the Time Shift function. - Page 25 HDMI CEC Setup This feature allows for your TV and your connected HDMI device to be controlled by one remote control. It also means you can turn them both on or off simultaneously. Press the SOURCE button on the unit or remote control to select the HDMI input source. Option Description Enable Link...
-
Page 26: Time
Time Option Description Off Time Schedule when the TV will automatically turn Off. On Time Schedule when the TV will automatically turn On. Select the desired Auto Sleep (Standby) duration. Sleep Timer Options: Auto Sleep Turn On/Off to set the TV to sleep after 10 minutes of no signal. Auto Sync If enabled, this will automatically set the time based on DTV. -
Page 27: Option
Option Option Description OSD Language Select the system language OSD Time Select the duration of the On Screen Display. Reset Reset your TV back to factory defaults. Network Configuration Settings for your network configuration. Software Update Update the TV software via USB. Internet Update Check Check online for TV software updates. -
Page 28: Lock
Lock 0000 Factory Password: Enter the factory password '0000' using the number buttons 4711 Master Password: on the remote and select 'OK' on-screen. If you changed your password but forgot it, you can still use the master password. Option Description Lock System Turn system lock on/off. -
Page 29: Channel
Channel Option Description Automatically tunes all available free-to-air TV channels. Adjust settings (default Auto Search settings are set for Australia), select 'Search' and press OK. Program Edit See the next page for more information. DTV Manual Manually select the broadcast channel frequency and tune digital TV channels. Search ATV Manual Manually select and tune analog TV channels. - Page 30 Program Edit Press MENU then select Channel > Program Edit then use the buttons to highlight a channel. Option Description Delete Press RED to delete the highlighted channel. Block Press GREEN to block a channel. Skip Press BLUE to skip the highlighted channel. Press YELLOW add a channel to the favourites list.
-
Page 31: Qmenu
QMenu The QMenu gives you access to selected menu settings without the hassles of navigating through the full menu. Press on your remote to access this. Option Description Audio Languages Select the audio language Select the picture best suited to the content you are viewing. Picture Mode Dynamic Home... -
Page 32: High Dynamic Range (Hdr)
High Dynamic Range (HDR) About the HDR feature High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are perceived in real life by the human eye. By using this feature, the TV can reproduce greater dynamic range of luminosity by capturing and then combining several different exposures. -
Page 33: Smart Tv
Smart TV Smart TV Applications • Netflix • Screencast Before you start using apps, your TV must be • YouTube • NetRange app portal connected to the internet. • Twitter • Foxxum app portal The speed of your internet connection determines •... -
Page 34: Screencast
Screencast App Portals The Screencast feature enables you to echo the NetRange, Foxxum and Zeasn app portals gives display from a compatible Android device like a you access to number of other content and service smartphone or tablet on the TV screen by connecting providers. -
Page 35: Tv Guide
TV Guide (Free to air TV) To access the TV guide, press the Guide button on the remote. TV Guide Functions AUDIO INFO To activate the TV Channels use QMENU MENU EXIT buttons to select a GUIDE LIST SOURCE Function Remote Button channel in the left column, then press OK to confirm. -
Page 36: Pvr Recording
PVR Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 37: Recording Live Tv
Before you can record with this TV Recording, scheduled recording and pause (including time-shift recording), you live TV functions only work in DTV mode must insert your USB storage device (free-to-air). into the USB port. SOURCE Recording Live TV Component HDMI 1H DMI 2 HDMI 3... -
Page 38: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause Temporarily pause the live TV signal, then resume live TV functions only work in DTV mode playback at your convenience. (free-to-air). SOURCE Before you can record with this TV (including time-shift recording), you Component AUDIO HDMI 1H... -
Page 39: Usb Mode
USB Mode You can only play Photos in the Photo category, Music in the Music category and so on. Make sure you select the correct category for the file you wish to play. Set up Function Remote Button Insert your USB into a USB port on the TV. Choose a Source or File Press the SOURCE button to select 'Media' mode. - Page 40 Playback Functions Music Function Remote Button Playback of different media types have different controls. Navigate to a folder or file Photo Select tracks to play Function Remote Button Navigate to a folder or file Play the selected track Fast forward or rewing the track Select photos Skip or restart the current track Display the selected photos...
- Page 41 Video Function Remote Button Only supported file types will be Navigate to a folder or file displayed. See the specifications table for supported file types. Play your video Pause the video Resume playback Stop playback Fast forward or rewing the track Skip or restart the current track Return to file list RECORDING AND USB MODE | 41...
-
Page 42: Troubleshooting
Troubleshooting If you have problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution Check the power outlet is turned on. If using a multi-outlet, check if it is working properly. To check whether a power strip is working properly, No power plug the TV’s power plug directly to a wall outlet and observe its operation. - Page 43 Problem Solution Ensure that the equipment is connected properly. Ensure that the input setting for the TV is correct. Ensure audio settings on the external device are set correctly. Ensure the volume is not muted. If it is, press the MUTE button to restore the sound. Sound issues If earphones are connected, unplug them.
- Page 44 Problems relating to your USB media storage device Problem Solution First, refer to the instructions describing how to use USB devices with this TV. If the problem still occurs, your USB device may not be compatible. This TV has been tested with the majority of Flash memory-based devices and hard disks (media players My TV does not with HDD) on the market;...
-
Page 45: Specifications
Specifications Active screen size (diagonal) 146 cm Resolution 3840 x 2160 Refresh rate 60Hz Aspect ratio 16:9 MJPEG, 3GP , AVI, DAT, HDR, H265, H264, MKV, MOV, MP4, Video MPEG-2, MPEG-4, VP8, VOB, TP , TS, MPG, WMV, MPEG. Multimedia playback Music AAC, M4A, OGG, MP3, WAV. -
Page 46: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic National Television and Computer Recycling wrapping can be a suffocation hazard for babies and young children, please ensure all packaging Scheme materials are out of reach and are safely disposed... - Page 47 Notes...
