Heinzmann HELENOS V DC 2040DP.2-01 Manual

Digital electronic speed governors basic systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright 2006 by Heinzmann GmbH & Co. KG. All rights reserved.
This publication may not be reproduced by any means whatsoever or passed on to any third parties
7011
HEINZMANN
Digital Electronic Speed Governors
Basic Systems
HELENOS V
DC 2005DP.2-01
DC 2040DP.2-01
Heinzmann GmbH & Co. KG
Engine & Turbine Controls
Am Haselbach 1
D-79677 Schönau (Schwarzwald)
Germany
Phone
+49 7673 8208-0
Fax
+49 7673 8208-188
E-mail
info@heinzmann.com
www.heinzmann.com
V.A.T. No.:
DE145551926
Druckschrift DG 97 014-e / 04-06
