QubicaAMF XLi EDGE Series Service & Parts Manual

Pinspotter with the optical durabin and the edge perfomance lift
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pinspotter
with the
Optical Durabin
and the
Service & Parts Manual
These original instructions for the XLi EDGE Pinspotter were
written in English.
QubicaAMF Worldwide
8100 AMF Dr.
Mechanicsville, VA 23111
Domestic 866-460-QAMF (7263) / International (804) 569-1000
Fax (804) 559-8650
EDGE
XLi
Pinspotter Service & Parts Manual - P/N 400-088-120-02 Rev. A
EDGE
XLi
Pinspotter Manual Set - P/N 610-088-500-02 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLi EDGE Series and is the answer not in the manual?

Questions and answers

Tenpin
May 21, 2025

Bumbers LED lights issue
