- Page 1 DIGITAL HDTV CARA V AN/RV ANTENNA USER MANUAL KATV ANT5VOMNI Made in china...
-
Page 2: What's In The Box
This product has been specially designed for outback condi ons. With its light weight design and durable material choice this will con nue to do the job intended out in the harsh condi ons of the outback. Thats KickAss. Firstly please read through the following instruc on before use. -
Page 3: Product Specifications
PRODUCT SPECIFICATIONS Frequency range FM 88-108Mhz; VHF 170-230Mhz, UHF 470-862Mhz VSWR Impedance Gain 30 dBi Connector F Male or customized Power supply USB port (5V/500mA) Cable Length Polariza on Horizontal Power Source 240v power adapter... -
Page 4: Antenna Installation
ANTENNA INSTALLATION Step 1: Install the antenna base to the roof of your caravan or camper trailer. ① Insert the screw into the base. ② Pass the plas c washer through the screw. ① Antenna pedestal screw inserted into roof of Caravan or Camper Trailer. - Page 5 Step 2: Install the antenna to the antenna base. ① Find the loca ng slot of the bracket. ② Aim at the loca ng Loca ng slot Loca ng slot slots of the bracket and base, then press the antenna. ①...
- Page 6 HOW TO CONNECT THE ANTENNA TO TV Connect to a 5V USB charging port (HDTV/Adapter) Power supply Connect to a 5V USB charging port (HDTV/Set Top Box/Adapter) Set Top Box Power supply...
- Page 7 (1) Connect the F male of antenna to the F female of the power supply. (2) Connect the F male of the power box to the ANT/IN connector on Set Top Box or TV (Built-in tuner). (3) Power the antenna by plugging the antenna power box’s USB connector into an open USB port on the TV or the set Top Box or into a wall outlet with one power adapter (not included).
- Page 8 KickAss Tips for Best Recep on 1. Please make sure your TV has a HDTV Tuner, if not, we suggest you buy a Set Top Box. 2. Not all digital signals are high defini on. Ensure your digital receiver is a HD receiver, otherwise no HD channels can be viewed.
- Page 9 THANK YOU FOR CHOOSING KickAss® is committed to providing you with the most up to date product information. As printed material is harder to update we have created an online user guide portal including videos, user guides and product tips so you can view or download the latest product information at any time.
- Page 10 Warranty does not cover products that have not been used in accordance with the KickAss® user guide or are outside the warranty terms and conditions. QUESTIONS AND COMMENTS Please visit us at kickass.com.au or...
- Page 11 NOTES...
