INSTALLATION / OWNER’S MANUAL REMOTE CONTROL Patio, Outdoor & Harsh Environment Infrared Heaters FCC ID: PUC YCT-107 FCC ID: PUC YCT-107 IC: 4163A-YCT107 IC: 4163A-CMR-1000 This device complies with part 15 of the FCC Rules. This device complies with part 15 of the FCC Rules. Operation is...
Page 3
REMOTE CONTROL Patio, Outdoor & Harsh Environment Infrared Heaters Table of Contents Features and Specifications ………………………………………… 3 Operation of Remote Controls: Overview …………………………. Programming / Setup of Receivers & Hand Set Transmitters ……… 4 House Code Set-up …………………………………………... 4 Unit Code Set-up …………………………………………….. 4 Graphic: Setup of Receivers &...
Kits: JP-1234-RK: 2300/IO-210 & JP-1234-TK: Tube Heaters FEATURES: ‘House Code’ setting allows unique system “address” - avoids interference with neighboring systems Works with Hand Set Transmitter YCT-107 Easily installed in heater CONNECTION: (Wiring Diagrams Pages 8 and 11) ...
Page 5
OVERVIEW The remote control hand set is used to turn patio heaters ON and OFF from a distance of up to 25 feet. Heaters must have a 24V Direct Spark Ignition system designed for automatic control. One Transmitter Hand Set can control up to 16 individual heaters (receivers) or 16 zones of heaters. An ‘On-Off’...
Page 6
SETTING UNIT CODES AND HOUSE CODES Transmitter Front (16 Positions) Unit Codes On/Off Switch: selects Channels 1 Group I selects Channels 5 Group II Group III selects Channels 9 10 11 12 Group IV selects Channels 13 14 15 16 Select a unique unit code for each receiver or zone of receivers.
Page 7
Sample Patio Set-up : Dining patio with 3 zones. Each zone has 2 opposing heaters that provide best comfort when operating simultaneously as a pair. The entire patio area will be controlled by one Hand Set Transmitter. ZONE ZONE ZONE Set all ‘House Codes’...
Page 8
RECEIVER KIT INSTALLATION - JP-1234-RK patioSchwank 2300 / IO-210 Series Read the Programming / Setup section (pages 4 & 5) prior to installation of the receiver into a heater. Complete the “Patio Floor Plan sketch and Settings Table” on the last page of this manual to assist you in the installation &...
Page 9
Wiring Diagram: 2300 / IO-210 series Patio Heaters. Remote Control Kit: JP-1234-RK NOTE: Recommended: Installation of an External Manual Over-ride Switch to allow temporary opera- tion of the heater(s) if the Hand Set Transmitter is misplaced or malfunctions. The switch must be in the ‘Off” position for operation of the remote control system. Remote Control Manual IM060930 RD: SEPT 2006...
Page 10
RECEIVER KIT INSTALLATION - JP-1234-TK SPW / IWP Tube Heater Series (Model STW / IW is shown below—follow the same instructions for SPW / IWP) Read the Programming / Setup section (pages 4 & 5) prior to installing the receiver into a heater. ...
Page 11
SPW / IWP Tube Heater Series RECEIVER INSTALLATION (Continued) FIGURE 4 6. Insert the wires provided into the Receiver unit as per Wiring Diagram (next page). 7. Remove (snip off) any female spade connectors from wires from the receiver 8. Connect wires to the terminal block on the com- ponent plate as indicated in the Wiring Diagram (next page) 9.
Page 12
Wiring Diagram: SPW / IWP Tube Heater series Patio Heaters Remote Control Kit: JP-1234-TK NOTE: Recommended: Installation of an External Manual Over-ride Switch to allow temporary opera- tion of the heater(s) if the Hand Set Transmitter is misplaced or malfunctions. The switch must be in the ‘Off”...
