Summary of Contents for Moore Industries DPS 240
- Page 1 May 2016 240 Milliamp 221-703-00 E DIN-style Power Supply...
- Page 2 Table of Contents Introduction Description Calibration Installation Troubleshooting Moore Industries’ STAR Center has a wide variety of quality instrumentation in stock and ready to ship. DELIVERY • Signal Transmitters • Temperature Transmitters • P/I and I/P Converters • Isolators and Converters •...
- Page 3 This rail can then be mounted on a wall, in a model number reflects the way the unit was config- rack, or in a NEMA enclosure. Each DPS 240 is ca- ured when it originally left the factory. It is all that is pable of powering twelve 4-20 mA loops.
- Page 4 DPS / 24VDC / 240 MA / 117AC / -FA / [DIN] Unit Type OutPut Voltage Current Power Options(s) Housing Table 1. DPS 240 Equipment Specifications Characteristics Specifications 117, 220, or 240 Vac (factory-configured according to customer requirement) Input Power 48 to 62 Hz Input Frequency...
- Page 5 There is a red LED indicator on the front panel of the the DPS 240. DPS 240, which lights when the unit is producing dc output. The indicator, labeled “OUTPUT ON”, goes out if a short circuit, overload, or any other unaccep- table condition occurs during operation.
- Page 6 24Vdc units, or 175 ohms for 42 Vdc units. ADJUSTABLE AC POWER SOURCE VOLTMETER MILLIAMMETER – – GND AC ACC GND AC ACC + DC OUT – DC OUT LOAD POWER SUPPLY VOLTAGE ADJUST CURRENT LIMIT OUTPUT ON Figure 1. DPS 240 Calibration Setup Page 4...
- Page 7 Care (99.5% of appropriate nominal output level ). should also be taken to locate the DPS 240 in an area 6. Reset load so that current output is 240 mA.
- Page 8 5/16 to 3/8 inches of the insulation from the end Electrical Connections of the wire. Figure 3 shows the front panel of the DPS 240 in de- To connect the DPS 240, loosen the clamping screw tail, and depicts its electrical connection in a typical of the appropriate terminal, and insert the uninsulated application.
- Page 9 If a problem develops with the performance of the Any units found to be performing below specifica- DPS 240, use the front panel test jacks to verify the tions should be immediately returned to the factory proper output voltage. The probes should be 2.03 mm for service.
- Page 10 NOTES...
- Page 11 4. Ship the equipment to the Moore Industries location nearest you. The returned equipment will be inspected and tested at the factory. A Moore Industries representative will contact the person designated on your documentation if more information is needed. The repaired equipment, or its replacement, will be returned to you in accordance with the shipping instructions furnished in your documentation.
