JTL ZXA10 F660 Maintenance Management Manual

Optical network terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ZXA10 F660
Optical Network Terminal
Maintenance Management Manual
V1.0
Tel
:
a
:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXA10 F660 and is the answer not in the manual?

Questions and answers

Summary of Contents for JTL ZXA10 F660

  • Page 1 ZXA10 F660 Optical Network Terminal Maintenance Management Manual V1.0...
  • Page 2 LEGAL INFORMATION Copyright © 2010 ZTE CORPORATION. The contents of this document are protected by copyright laws and international treaties. Any reproduction or distribution of this document or any portion of this document, in any form by any means, without the prior written consent of CORPORATION is prohibited.

  • Page 3: Table Of Contents

    Contents Chapter 1 Overview ..................1-1 1.1 Safety Precautions ..................... 1-1 1.2 Packing List ....................... 1-2 1.3 Features and Specifications ................1-3 1.4 Product Appearance................... 1-4 1.5 System Requirements ..................1-6 1.6 System Application Environment ................. 1-7 Chapter 2 Configuration Preparation ............2-1 2.1 Preliminary Setup....................
  • Page 4 4.4.2 Configuring Static Routing ..............4-18 Chapter 5 Security Configuration ............. 5-1 5.1 Configuring Firewall.................... 5-1 5.2 Configuring IP Filter.................... 5-2 5.3 Configuring URL Filter ..................5-5 5.4 Configuring DMZ Host ..................5-7 5.5 Configuring Port Forwarding ................5-8 Chapter 6 Service Configuration............... 6-1 6.1 SIP VoIP Service Configuration ................
  • Page 5 7.1.2 Importing TR-069 Certificate ..............7-3 7.2 User Management....................7-4 7.3 Device Management................... 7-5 7.3.1 System Management................7-5 7.3.2 Software Upgrade ..................7-6 7.3.3 Configuration Management ............... 7-8 7.4 Log Management ....................7-9 7.5 Ping Diagnosis ....................7-10 Appendix A FAQ ..................A -1 A .1 FAQ ........................

  • Page 7: Chapter 1 Overview

    Contact the service provider for maintenance if the device is faulty. Note The users should read the usage cautions above carefully and will be responsible for any incident resulted from the violation of the cautions above. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 8: Packing List

    Do not dispose the device or battery improperly. Observe the local regulations about the equipment disposal or treatment. 1.2 Packing List After opening the ZXA10 F660 packing box, make sure that it contains the following components, as listed in Table...

  • Page 9: Features And Specifications

    Image RJ-45 network cable RJ-11 telephone cable One ZXA10 F660 (V1.0) Optical Network Terminal User Manual is delivered with the product. If any of the components are incorrect, lost, or damaged, contact the product agency. If you want to change the product, keep the packing box and components.

  • Page 10: Product Appearance

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual The ZXA10 F660 provides the security, QoS, and network management functions, such as multi-level authentication based on devices, users, and services. It supports data channel encryption, implementation of QoS requirements matching the local devices and network according to services with different requirements, and network management based in various management modes.
  • Page 11 The device is powered ON normally. The device is not powered ON. Back Panel Figure 2 shows the back panel of the ZXA10 F660. Figure 2 Back Panel Table 3 lists the interfaces and buttons on the back panel. SJ-20110517135211-002...

  • Page 12: System Requirements

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Table 3 Interfaces and Buttons on the Back Panel Interface/Button Description LAN1–LAN4 RJ-45 LAN interface, connecting to the local network through the RJ-45 network cable POTS1–POTS2 RJ-11 telephone interface, connecting to the telephone through the RJ-11...

  • Page 13: System Application Environment

    Figure 4 shows the ZXA10 F660 application environment. Figure 4 System Application Environment As an indoor device, the ZXA10 F660 can be put on the desk with the base or hung on the wall without the base. Figure 5 shows the ZXA10 F660 on a wall.
  • Page 14 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 5 Wall-Mount SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 15: Chapter 2 Configuration Preparation

    Consult the ISP if some data from the ISP is needed. 2.2 Configuring TCP/IP ShortDescription Perform this procedure to configure TCP/IP of a computer connected to the ZXA10 F660. Context This instance takes Windows XP as an example. The default network settings for the ZXA10 F660 are as follows: IP address: 192.168.1.1...
  • Page 16 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. Choose Start> Settings> Network Connections to open the Network Connections window. 2. Double-click Local Area Connection to open the Local Area Connection Status dialog box, as shown in Figure Figure 6 Local Area Connection Status 3.
  • Page 17 Select Use the following IP address and specify the IP address, Subnet mask, and Default gateway. For example, you can set the IP address to 192.168.1.7, Subnet mask to 255.255.255.0, and Default gateway to 192.168.1.1, as shown in Figure SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 18 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 8 Specifying the IP address in the Internet Protocol (TCP/IP) Properties Note The IP address shall be in the same network segment as LAN port address of the device, which means the IP address you type in should be “192.168.1.x” (x can be any value from 2 to 254).
  • Page 19 If the communication between your PC and the device fails, ensure the following items: The Ethernet cable between the device and your PC has been connected properly. The driver of your network adapter has been installed properly. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 20: Logging In To The Device

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual The TCP/IP setting has been configured correctly on your PC. If the ZXA10 F660 IP address is 192.168.1.1, the IP address of the computer must be from 192.168.1.2 to 192.168.1.254. The subnet mask must be 255.255.255.0 and the default gateway must be 192.168.1.1.

  • Page 21: Chapter 3 Device Status

    Figure 12 Device Information Table 4 lists the parameters for the device information. Table 4 Device Information Parameters Parameter Description Model Device type Serial Number Device serial number Hardware Version Hardware version number Software Version Software version number SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 22: Network Connection Information

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Parameter Description Boot Loader Version Boot version number PON Serial Number PON serial number Password Password used by the ONU registration on the 3.2 Network Connection Information On the Status tab, select Network Interface. By default, the WAN Connection sub-node is selected.

  • Page 23: User Interface Information

    WLAN switch information, packet receiving and sending information, and authentication information, as shown in Figure Click Refresh to view the latest information. Figure 14 WLAN Interface Information Table 6 lists the parameters for the WLAN interface information. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 24: Ethernet Interface Information

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Table 6 Parameters for the WLAN Interface Information Parameter Description Enable Wireless RF Whether to enable the wireless RF Channel Channel SSID1 Enable Whether to enable the wireless network SSID1 SSID1 Name...

  • Page 25: Voip Status Information

    Ethernet error frames 3.3.3 VoIP Status Information On the Status tab, select User Interface. Select VoIP Status. The right pane displays the VoIP status information, as shown in Figure Click Refresh to view the latest information. SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 26 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 16 VoIP Status Information Table 8 lists the parameters for the VoIP status information. Table 8 Parameters for the VoIP Status Information Parameter Description SIP Account Username Telephone number SIP Register Status...
  • Page 27 The user has logged in to the Web interface of the device. Context To configure the WAN connection, perform the following steps: Steps 1. On the Web interface of the device, click the Network tab. By default, WAN Connection is selected, as shown in Figure SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 28 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 17 WAN Connection 2. The connection type can be PPPoE, Static, or DHCP. a. Configure the PPPoE mode. Select PPPoE for Type, as shown in Figure Figure 18 PPPoE Mode Configuration Table 9 lists the parameters for the PPPoE mode configuration.

  • Page 29: Chapter 4 Network Configuration

    Idle time before the dial-up auto disconnection, available only in On Demand mode b. Configure the static mode. Select Static for Type, as shown in Figure Figure 19 Static Mode Configuration Table 10 lists the parameters for the static mode configuration. SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 30 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Table 10 Static Mode Configuration Parameter Description Type Connection mode Connection Name Static connection name, automatically generated by the system Enable NAT Whether to enable the NAT function Service List Service modes supported by the system:...

  • Page 31: Wlan Configuration

    4.2.1 Configuring Basic WLAN Parameters ShortDescription Perform this procedure to configure the basic WLAN parameters. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the basic WLAN parameters, perform the following steps: SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 32 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. On the Network tab, select WLAN on the left pane. By default, the Basic sub-node is selected, as shown in Figure Figure 21 Basic WLAN Configuration 2. Configure the basic WLAN parameters, as listed in...

  • Page 33: Configuring Multi-Ssid Parameters

    2. Configure the multi-SSID parameters as shown in Table Table 13 Multi-SSID Parameters Parameter Description Choose SSID Choose the SSID that needs to be configured. Hide SSID Disable or enable SSID broadcast. Enable SSID Enable the SSID. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 34: Configuring Security Properties

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Parameter Description SSID Name SSID name. It cannot exceed 32 characters and is case sensitive. It is used to control the WLAN access. The SSID name must match all the SSIDs of the related access nodes; otherwise, the device cannot be accessed.
  • Page 35 WEP encryption value Range: 5–bit ASCII code or 10–bit hexadecimal number WEP Key2 WEP encryption value Range: 5–bit ASCII code or 10–bit hexadecimal number WEP Key3 WEP encryption value Range: 5–bit ASCII code or 10–bit hexadecimal number SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 36 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Parameter Description WEP Key4 WEP encryption value Range: 5–bit ASCII code or 10–bit hexadecimal number b. In Authentication Type, select Shared Key. By default, WEP Encryption is enabled. The Shared Key configuration information is displayed, as shown in...
  • Page 37 WPA Group Key Update Interval Update interval of the WPA group key WPA Encryption Algorithm WPA encryption algorithm Note The configuration method for the WPA2-PSK authentication mode is the same as that for the WPA-PSK authentication mode. 4-11 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 38: Viewing Associated Devices

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result The security properties are configured. 4.2.4 Viewing Associated Devices ShortDescription Perform this procedure to view the associated devices.

  • Page 39: Address Management Configuration

    1. On the Network tab, select Address Management. By default, DHCP Server is selected, as shown in Figure Figure 28 DHCP Server 2. On the DHCP Server tab, configure the parameters, as listed in Table 4-13 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 40: Configuring Dhcp Binding

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Table 17 Parameters for DHCP Server Configuration Parameter Description LAN IP Address IP address of the LAN group (interface subnet) Subnet Mask Subnet mask of the LAN group Enable DHCP Server To enable or disable the DHCP server...

  • Page 41: Configuring Specific Address Range

    ShortDescription Perform this procedure to configure the specific address range. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the special address range, perform the following steps: 4-15 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 42: Route Management Configuration

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. On the Network tab, select Address Management, and then select Specific Address Range, as shown in Figure Figure 30 Specific Address Range 2. Click Modify to modify the parameters, as shown in...

  • Page 43: Configuring Default Gateway

    Note This interface is available when configured on WAN Connection. 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result The default gateway is configured. 4-17 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 44: Configuring Static Routing

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 4.4.2 Configuring Static Routing ShortDescription Perform this procedure to configure the static routing. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the static routing, perform the following steps: Steps 1.
  • Page 45 4. Click Add to finish the configuration, as shown in Figure 35. Click Modify to modify the configuration. Click Delete to delete the configuration. Figure 35 Static Routing Configuration Completed – End of Steps – Result The static routing is configured. 4-19 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 46 4-20 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 47: Chapter 5 Security Configuration

    The user has logged in to the Web interface of the device. Context To configure the firewall, perform the following steps: Steps 1. On the Web interface, click the Security tab. By default, Firewall is selected, as shown in Figure Figure 36 Firewall Configuration SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 48: Configuring Ip Filter

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 2. Set the firewall parameters, as listed in Table Table 19 Firewall Parameters Parameter Description Enable Anti-Hacking Protection To enable or disable anti-hacking protection Firewall Level Firewall level High: Allow legal WAN-side access but prohibit WAN-side ping.
  • Page 49 End Source Port Ending source port number Start Destination Port Starting destination port number End Destination Port Ending destination port number Ingress Ingress interface Egress Egress interface Mode Discard Permit Mode, including discard and permit SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 50 ZXA10 F660 Optical Network Terminal Maintenance Management Manual 2. On the IP Filter tab, set the filter parameters, as shown in Figure Figure 38 IP Filter Configuration 3. Click Add to finish the configuration, as shown in Figure 39. Click Modify to modify the configuration.

  • Page 51: Configuring Url Filter

    The user has logged in to the Web interface of the device. Context To configure the URL filter, perform the following steps: Steps 1. On the Security tab, select URL Filter, as shown in Figure SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 52 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 40 URL Filter Table 21 lists the parameters for URL filter configuration. Table 21 Parameters for URL Filter Configuration Parameter Description Enable To enable the URL filter function Mode Mode, including discard and permit...

  • Page 53: Configuring Dmz Host

    The user has logged in to the Web interface of the device. Context To configure the DMZ host, perform the following steps: Steps 1. On the Security tab, select DMZ Host, as shown in Figure Figure 43 DMZ Host SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 54: Configuring Port Forwarding

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 2. Configure the DMZ host parameters, as shown in Figure Figure 44 DMZ Host Configuration Table 22 lists the parameters for DMZ host configuration. Table 22 Parameters for DMZ Host Configuration Parameter...
  • Page 55 1. On the Security tab, select Port Forwarding, as shown in Figure Figure 45 Port Forwarding 2. Configure the port forwarding parameters, as shown in Figure Figure 46 Port Forwarding Configuration Table 23 lists the parameters for port forwarding configuration. SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 56 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Table 23 Parameters for Port Forwarding Configuration Parameter Description Enable To enable the port forwarding function Name Host name Protocol Protocol name, including TCP, UDP, as well as TCP and UDP protocols...
  • Page 57 Chapter 5 Security Configuration Figure 47 Port Forwarding Configuration Completed – End of Steps – Result Port forwarding is configured. 5-11 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 58 5-12 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 59: Chapter 6 Service Configuration

    6.1.1 Configuring VoIP WAN Connection ShortDescription Perform this procedure to configure the VoIP WAN connection. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the VoIP WAN connection, perform the following steps: SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 60: Configuring Sip

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. On the Web interface, click the Application tab. Select VoIP. By default, WAN Connection is selected, as shown in Figure Figure 48 WAN Connection 2. Select a connection interface from WAN Connection.
  • Page 61 Port number of the secondary proxy server Register Expires Registration expiration time Unit: second 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result SIP is configured. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 62: Configuring Sip Accounts

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 6.1.3 Configuring SIP Accounts ShortDescription Perform this procedure to configure SIP accounts. Pre-requisites The user has logged in to the Web interface of the device. Context To configure SIP accounts, perform the following steps: Steps 1.

  • Page 63: Configuring Voip Advanced Parameters

    – End of Steps – Result The SIP accounts are configured. 6.1.4 Configuring VoIP Advanced Parameters ShortDescription Perform this procedure to configure the VoIP advanced parameters. Pre-requisites The user has logged in to the Web interface of the device. SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 64 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Context To configure the VoIP advanced parameters, perform the following steps: Steps 1. On the Application tab, select VoIP, and then select Advanced, as shown in Figure Figure 52 Advanced Parameters 2. Configure the advanced parameters, as shown in...

  • Page 65: Configuring Voip Media Parameters

    To configure VoIP media parameters, perform the following steps: Steps 1. On the Application tab, select VoIP, and then select Media, as shown in Figure Figure 53 Media Parameters 2. Configure the media parameters, as shown in Figure SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 66: Configuring Fax

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 54 Media Parameter Configuration Table 27 lists the media parameters. Table 27 Media Parameters Parameter Description Codec Selection Code type Codec Priority Code priority The smaller the value is, the higher the priority is.

  • Page 67: Configuring Ddns

    3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result Fax is configured. 6.2 Configuring DDNS ShortDescription Perform this procedure to configure DDNS. Pre-requisites The user has logged in to the Web interface of the device. SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 68 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Context After DDNS is applied, the host that has the dynamic IP address can also provide the domain name service. For example, when the host obtains an IP address through xDSL dial-up or DHCP server dynamic allocation, and the host provides the domain name service, by using DDNS, the effect on the domain name access when the IP address changes is eliminated.

  • Page 69: Configuring Upnp

    IP address, announce the function, and know the functions of other devices. To configure UPnP, perform the following steps: Steps 1. On the Application tab, select UPnP, as shown in Figure 6-11 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 70 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 58 UPnP 2. Configure the UPnP parameters, as shown in Figure Figure 59 UPnP Configuration Table 29 lists the UPnP parameters. Table 29 UPnP Parameters Parameter Description Enable To enable UPnP...

  • Page 71: Dns Configuration

    Figure Figure 60 Domain Name 2. Set Domain Name. 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result The domain name is configured. 6-13 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 72: Configuring Host Name

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 6.4.2 Configuring Host Name ShortDescription Perform this procedure to configure the host name. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the host name, perform the following steps: Steps 1.

  • Page 73: Qos Configuration

    – End of Steps – Result The host name is configured. 6.5 QoS Configuration This topic includes the following: Configuring Basic QoS Parameters Configuring QoS Rule Configuring QoS Rule Type Configuring QoS Local Application Configuring QoS Queue Management 6-15 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 74: Configuring Basic Qos Parameters

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Configuring QoS Ingress Rate Limit 6.5.1 Configuring Basic QoS Parameters ShortDescription Perform this procedure to configure the basic QoS parameters. Pre-requisites The user has logged in to the Web interface of the device.
  • Page 75 To enable or disable the 802.1p remarking mode Range: disable, transparent transmission, and enable 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result The basic QoS parameters are configured. 6-17 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 76: Configuring Qos Rule

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 6.5.2 Configuring QoS Rule ShortDescription Perform this procedure to configure the QoS rule. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the QoS rule, perform the following steps: Steps 1.

  • Page 77: Configuring Qos Rule Type

    ShortDescription Perform this procedure to configure the QoS rule type. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the QoS rule type, perform the following steps: 6-19 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 78 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. On the Application tab, select QoS, and then select Rule Type, as shown in Figure Figure 68 Rule Type 2. Configure the QoS rule type parameters, as shown in Figure...

  • Page 79: Configuring Qos Local Application

    ShortDescription Perform this procedure to configure the QoS local application. Pre-requisites The user has logged in to the Web interface of the device. Context To configure the QoS local application, perform the following steps: 6-21 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 80: Configuring Qos Queue Management

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Steps 1. On the Application tab, select QoS, and then select Local Application, as shown in Figure Figure 71 Local Application 2. In the Queue drop-down list, select a queue number. Note At present, only the Tr-069 service mode is supported.

  • Page 81: Configuring Qos Ingress Rate Limit

    Weight refers to the ratio of the data flow passing through the queues to the total data flow. – End of Steps – Result QoS queue management is configured. 6.5.6 Configuring QoS Ingress Rate Limit ShortDescription Perform this procedure to configure the QoS ingress rate limit. 6-23 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 82 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Pre-requisites The user has logged in to the Web interface of the device. Context To configure the QoS ingress rate limit, perform the following steps: Steps 1. On the Application tab, select QoS, and then select Ingress Rate Limit, as shown...

  • Page 83: Configuring Sntp Client

    The user has logged in to the Web interface of the device. Context To configure the SNTP client, perform the following steps: Steps 1. On the Application tab, select SNTP, as shown in Figure 6-25 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 84 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 75 SNTP 2. Configure the SNTP parameters, as shown in Figure Figure 76 SNTP Configuration Table 34 lists the SNTP parameters. Table 34 SNTP Parameters Parameter Description Time Zone Time zone where the subscriber is located...

  • Page 85: Igmp Configuration

    1. On the Application tab, select IGMP. By default, Basic is selected, as shown in Figure Figure 77 Basic IGMP Configuration 2. IGMP Mode includes IGMP Snooping, IGMP Proxy, and Disabled. Disabled indicates to disable the IGMP mode configuration. 6-27 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 86 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Configure IGMP Snooping. From the IGMP Mode drop-down list, select IGMP Snooping, as shown in Figure Figure 78 IGMP Snooping Configuration Table 35 lists the parameters for IGMP snooping configuration. Table 35 Parameters for IGMP Snooping Configuration...

  • Page 87: Configuring Multicast Vlan

    Report Time Periodical report time of multicast messages Note ZXA10 F660 periodically reports the IGMP member report messages to the upper-layer multicast router according to the Report Time. 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration.
  • Page 88 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Pre-requisites The user has logged in to the Web interface of the device. Context To configure the multicast VLAN, perform the following steps: Steps 1. On the Application tab, select IGMP, and then select Multicast VLAN, as shown in...

  • Page 89: Configuring Multicast Mac Limit

    Snooping. IGMP Proxy does not support this function. To configure multicast MAC limit, perform the following steps: Steps 1. On the Application tab, select IGMP, and then select Multicast MAC Limit, as shown Figure 6-31 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 90 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 82 Multicast MAC Limit 2. Click the Modify icon to configure the multicast MAC limit, as shown in Figure Figure 83 Multicast MAC Limit Configuration Table 38 lists the parameters for the multicast MAC limit configuration.

  • Page 91: Configuring Mvlan Tag Strip

    1. On the Application tab, select IGMP, and then select Tag Stripe, as shown in Figure Figure 84 MVLAN Tag Strip 2. Click the Modify icon to configure MVLAN tag strip, as shown in Figure 6-33 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 92: Configuring Ftp Application

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 85 MVLAN Tag Strip Configuration Table 39 lists the parameters for MVLAN tag strip configuration. Table 39 Parameters for MVLAN Tag Strip Configuration Parameter Description Enable Tag Stripe To enable the MVLAN tag strip function 3.
  • Page 93 FTP Username FTP login user name FTP Password FTP login password 3. Click Submit to finish the configuration. Click Cancel to cancel the configuration. – End of Steps – Result FTP application is configured. 6-35 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 94 6-36 SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 95: Configuration

    The user has logged in to the Web interface of the device. Context To configure the basic TR-069 parameters, perform the following steps: Steps 1. On the Administration tab, select TR-069. By default, Basic is selected, as shown Figure SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 96 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Figure 88 Basic TR-069 Parameters 2. Configure the basic TR-069 parameters, as shown in Figure Figure 89 Basic TR-069 Parameter Configuration Table 41 lists the basic TR-069 parameters. Table 41 Basic TR-069 Parameters...

  • Page 97: Importing Tr-069 Certificate

    1. On the Administration tab, select TR-069, and then select Certificate, as shown in Figure Figure 90 TR-069 Certificate 2. Click Browse to select the certificate file. 3. Click Import Certificate to import the file. – End of Steps – SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 98: User Management

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual Result The TR-069 certificate is imported. 7.2 User Management ShortDescription Perform this procedure to manage users. Pre-requisites The user has logged in to the Web interface of the device. Context To manage users, perform the following steps: Steps 1.

  • Page 99: Device Management

    Figure Figure 92 System Management 2. Click Reboot to reboot the device. 3. Click Restore Default to restore the system to the factory default settings. – End of Steps – Result System management is complete. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 100: Software Upgrade

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 7.3.2 Software Upgrade ShortDescription Perform this procedure to upgrade the software. Pre-requisites The user has logged in to the Web interface of the device. Context Caution Generally, the software is upgraded by the ZTE CORPORATION engineers. If the user wants to upgrade the software, contact the local office of ZTE CORPORATION to obtain the latest software version.
  • Page 101 During the upgrade process, the device cannot be powered off; otherwise, it may be damaged. During the upgrade process, the system prompts a message. After the upgrade is complete, the system returns to the login interface. – End of Steps – Result The software is upgraded. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 102: Configuration Management

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 7.3.3 Configuration Management ShortDescription Perform this procedure to manage the device configuration. Pre-requisites The user has logged in to the Web interface of the device. Context To manage the device configuration, perform the following steps: Steps 1.

  • Page 103: Log Management

    Whether to enable the log server Log Level Log level, including Debug, Informational, Notice, Warning, Er- ror, Critical, Alert, and Emergency When Log Level is configured, only the logs above the specified level are saved. SJ-20110517135211-002 JTL Proprietary and Confidential...

  • Page 104: Ping Diagnosis

    ZXA10 F660 Optical Network Terminal Maintenance Management Manual 3. Click Refresh to display the latest 20 logs. 4. Click Clear Log to clear the current log records. 5. Click Submit to finish the configuration. Click Cancel to cancel the configuration.
  • Page 105 Chapter 7 Device Management Figure 100 Ping Diagnosis Result – End of Steps – Result Ping diagnosis is complete. 7-11 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 106 7-12 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 107 Why Does the Device Fail to Make a Call? Check whether the telephone cable is correctly connected to the POTS1 or POTS2 port. Then access the Web interface of the device. Click the Application tab to check the A -1 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 108 ZXA10 F660 Optical Network Terminal Maintenance Management Manual VoIP configuration. If the VoIP configuration is correct and the telephone cable is correctly connected, but the call still cannot be made, contact the service provider. A -2 SJ-20110517135211-002 JTL Proprietary and Confidential...
  • Page 109 Index Configuring Specific Address Range ..........4-15 Configuration Management ....7-8 Configuring Static Routing....4-18 Configuring Basic IGMP Configuring the SIP Accounts....6-4 Parameters........6-27 Configuring UPnP .......6-11 Configuring Basic QoS Configuring URL Filter ......5-5 Parameters........6-16 Configuring VoIP Advanced Configuring Basic TR-069 Parameters.........
  • Page 110 ZXA10 F660 Optical Network Terminal Maintenance Management Manual Safety Precautions ....... 1-1 Software Upgrade ........ 7-6 System Application Environment ..1-7 System Management ......7-5 System Requirements ......1-6 User Management........ 7-4 Viewing Associated Devices....4-12 VoIP Status Information......3-5...
  • Page 111 Glossary - Comfort Noise Generation - Direct Current DDNS - Dynamic Domain Name Server DHCP - Dynamic Host Configuration Protocol - Demilitarized Zone DNAT - Destination Network Address Translation - Domain Name Server DSCP - Differentiated Services Code Point - Digital Subscriber Line DTMF - Dual-ToneMulti-Frequency DWRR...
  • Page 112 ZXA10 F660 Maintenance Management Manual IEEE - Institute of Electrical and Electronics Engineers IGMP - Internet Group Management Protocol - Internet Protocol IPTV - Internet Protocol Television - Internet Service Provider - International Telecommunications Union - Local Area Network - Medium Access Control...
  • Page 113 Glossary - Real-time Transport Protocol - Session Initiation Protocol SNTP - Simple Network Time Protocol - Strict Priority - Soft Switch - Transfer Control Protocol TCP/IP - Transfer Control Protocol/Internet Protocol - User Datagram Protocol - UniformResource Locator - Voice Activity Detectors VLAN - Virtual Local Area Network VoIP...
