Intermediate Position 1 - Selve commeo Multi Send Operating Instruction

Explanation of functions

7.6. Intermediate position 1

The intermediate position is a position between the upper and lower end limits that can
be freely selected.
Set intermediate position 1:
Operation
>3 s
Travel to intermediate position 1:
Operation
2x
Drive
Move the drive to the upper end position with the UP
button.
Push the STOP button and then additionally push the
DOWN button. Keep both pushed.
After 3 seconds, the programming run starts.
Set the position with the DOWN and UP buttons while
keeping the STOP button pushed.
Releasing the STOP button will save the position.
Drive
Push the DOWN button twice quickly in sequence.
