Built-In Side Burners
Side Burner Models:
ESB1NG / ESB1LP
ESB2NG / ESB2LP
Owner's Manual
For more information on other great EdgeStar products on the web, go to
https://www.edgestar.com
V2.1-01242018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESB1NG and is the answer not in the manual?

Questions and answers

Summary of Contents for EdgeStar ESB1NG

  • Page 1 Built-In Side Burners Side Burner Models: ESB1NG / ESB1LP ESB2NG / ESB2LP Owner’s Manual For more information on other great EdgeStar products on the web, go to https://www.edgestar.com V2.1-01242018...
  • Page 2 Important Safety Information Improper handling can cause serious damage to the EdgeStar side burner and/or injury to the user. This side burner is designed for domestic use only. Do not use the unit for industrial or commercial use. Do not use in any enclosed areas, including buildings and garages. Any other use may invalidate the warranty.
  • Page 3 Gas and Electrical Safety  This gas side burner must be installed in accordance with all local codes. In addition, the gas side burner(s) must be installed in accord with the following codes, as applicable:  National Fuel Gas Code, ANSI Z223.1 / NFPA 54 ...
  • Page 4 General Safety  To prevent back and other types of injuries, use at least two people to move and install the side burner(s) and grilling equipment.  This appliance is not intended for use by persons, including children, with reduced physical, sensory or mental capabilities, unless they have been given supervision or instruction concerning the use of the appliance by the person(s) responsible for their safety.
  • Page 5  EdgeStar LP side burners are designed to be used with a standard 20 lb. (9.1kg) Department of Transportation (DOT) approved LP cylinder. No tanks larger than 20 lbs.
  • Page 6 NATURAL GAS SAFETY  Your natural gas side burner (models ESB1NG and ESB2NG) is designed to operate on natural gas only at a pressure regulated at 4 inches water column (WC) when equipped with the correct natural gas orifices on the valves and a natural gas regulator on the supply line.

  • Page 7: Table Of Contents

    TAINLESS TEEL SPECIFICATIONS ............................25 EDGESTAR LIMITED WARRANTY ........................26 First Time Operating Instructions Before use, make sure all packaging labels and materials are all removed from the unit. Be sure to keep track of all included parts and pieces before discarding packaging materials. It is advised that you keep the original box and packaging materials in case you are ever to move or ship the appliance in the future.

  • Page 8: Introduction

    Introduction Thank you for purchasing this EdgeStar gas side burner. We hope that this purchase will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support and exemplary products necessary to nurture that relationship.

  • Page 9: Parts Identification

    Parts Identification ESB1NG / ESB1LP (Single Gas Side Burner) Part Description Included Quantity Burner Igniting Line Stainless Steel Flexline Igniting Valve Igniting Pin LED Light Control Panel (Face Plate) Gas Control (Burner) Knob Knob Bezel Light Switch Firebox Drip Tray...
  • Page 10 ESB2NG / ESB2LP (Double Side Burner) Part Description Included Quantity Burner Igniting Line Stainless Steel Flexline Igniting Valve Igniting Pin LED Light Control Panel (Face Plate) Gas Control (Burner) Knob Knob Bezel Light Switch Firebox Drip Tray Cooking Griddle Lid Handle Gas Manifold Electrode Wire Transformer...

  • Page 11: Side Burner Dimensions

    Side Burner Dimensions ESB1NG / ESB1LP...
  • Page 12 ESB2NG / ESB2LP...

  • Page 13: Island / Cabinet Cutout Dimensions

    Island / Cabinet Cutout Dimensions  Do not store extra propane or butane tanks in proximity to your gas side burner.  All BBQ islands must be manufactured from non-combustible material(s).  Minimum clearance to combustible construction material(s) is 24” from the back and sides.

  • Page 14: Maintaining Adequate Ventilation

    Cabinet Opening Model Opening Width (W) Opening Depth (D) Opening Height (H) ESB1 Series 10-7/8” 20-1/8” 10-3/8” ESB2 Series 10-7/8” 20-1/8” 10-3/8” Maintaining Adequate Ventilation When building a gas side burner into outdoor cabinetry or an island, it is important to maintain proper ventilation.

  • Page 15: Installing The Gas Side Burner

    Unpacking the Gas Side Burner WARNING: Use two more people to move and install the gas side burner. Failure to do so can result in back or other injury. Carefully remove the packaging materials. Remove any shipping tape and glue from your gas side burner before using. Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue.

  • Page 16: Types Of Installation

    Types of Installation This manual covers an EdgeStar gas side burner series that includes models using either a Liquid Propane (LP) or a Natural Gas (NG) fuel source. Select your appropriate fuel type and follow the relevant installation instructions, as follows.

  • Page 17: Liquid Propane (Lp) Installation And Requirements

     Side burners operated with LP fuel must be installed with the supplied LP regulator.  EdgeStar LP side burners are designed to be used with a standard 20 lb. Department of Transportation (DOT) approved LP tank. No tanks larger than 20 lbs. are to be used.
  • Page 18 To Connect the LP Gas Supply: 1. Ensure the 20 lb. LP tank valve is fully closed. To do so, make sure the tank handle is turned all the way clockwise. You should not hear a hissing noise or smell propane. 2.
  • Page 19 6. Once you have confirmed that all connections are secure and there are no gas leaks, you may proceed with normal use of your side burner. All connection points must be free from gas leaks before first use of the gas side burner. 7.

  • Page 20: Natural Gas (Ng) Installation And Requirements

     Side burners operated with NG fuel must be installed with the NG regulator supplied with your EdgeStar side burner.  EdgeStar NG side burners are equipped with an NG regulator set to 4 inches water column. This regulator is for NG only.

  • Page 22: Checking For Gas Leaks

    Checking for Gas Leaks At least once every six months, and any time a tank is disconnected and reconnected, perform a leak test. Additionally, any time any components including the gas supply lines or the regulator are replaced, perform a leak test. Never use the side burner without testing for gas leaks first. WARNING: Do not test for gas leaks with an open flame.

  • Page 23: Electrical Requirements

     Do not operate any outdoor cooking gas appliance with a damaged cord, damaged plug, or after the appliance malfunctions or has been damaged in any manner. Contact EdgeStar for repair.  Do not let the cord hang over the edge of a table or touch hot surfaces.

  • Page 24: Plugging In The Lights

     Never unplug the unit by pulling on the plug. Plugging in the Lights This EdgeStar series of gas side burner includes stylish and functional backlighting for the knobs and switches. These lights require a 120V AC power supply to function. Please review the electrical requirements in this manual carefully.

  • Page 25: Included Cooking Components

    Included Cooking Components Before using the EdgeStar gas side burner for the first time, be sure to thoroughly wash [by hand] the included cooking griddle under hot water with soap. Do not wash in your dishwasher. Allow it to dry before reinstalling in the side burner.

  • Page 26: Lighting The Burner(S)

    Lighting the Burner(s) Tip: If you have never used the side burner before, or have not used the side burner for an extended period of time, it may take multiple attempts to light the burner(s). 1. Make sure you have observed all safety warnings in this manual. Follow the instructions for connecting the gas supply.
  • Page 27  Turn the gas supply off after you are done using the side burner.  If you are unable to manually light your burners after several attempts, turn off the gas and contact EdgeStar service or an authorized technician. Flare-Ups Flare-ups can occur when fats and oils drip from the contents being grilled down onto the burners.

  • Page 28: Cleaning And Maintenance

    Cleaning and Maintenance Caution: Always ensure that the gas supply is fully turned off prior to performing any cleaning and maintenance on your side burner. All burner knobs should also be in the “OFF” position. Never attempt to clean parts of the side burner while they are still hot. Caution: ...

  • Page 29: Reinstalling The Burner(S)

    2. Use a bristled brush and run it through the orifices of the burner several times. 3. Go over the exterior of the burner with a wire brush several times to loosen debris and residue. You may also wipe it with a terry cloth or damp rag without using any chemicals. For stubborn scale, you may use a scraper.

  • Page 30: Cleaning The Cooking Griddle

    Cleaning the Cooking Griddle After using the side burner, turn the burner knob(s) off and cut the gas at its source. Once the side burner and griddles have cooled down, remove the griddle and clean it with a soap and water mixture.

  • Page 31: Caring For Stainless Steel

    Moisture, high heat, salt / salt water, and chlorine in particular can cause damage. Your EdgeStar side burner is constructed using high quality stainless steel, but take extra precautions to maintain the quality aesthetic and well-being of your side burner.

  • Page 32: Specifications

    Specifications Note: Technical data and performance information are provided for reference only. Model Number ESB1** ESB2** Total Input 13,000 26,000 (Burner BTUs) Number of Burners Stainless Grade 13” 13” Width (Inches) Specifications are subject to change. Check the rating label on the gas side burner for the most accurate information.

  • Page 33: Edgestar Limited Warranty

    LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at an authorized EdgeStar repair facility. At its option, EdgeStar will repair the product with new or remanufactured parts, or exchange the defective product with a new, refurbished, or remanufactured product.
  • Page 34 Once an EdgeStar authorized representative has confirmed that your product is defective and eligible for warranty service, the product must be returned to an EdgeStar repair facility. The purchaser is solely responsible for prepaying all shipping related costs to and from the repair facility. EdgeStar is not responsible for damage resulting from shipper mishandling or improper packaging.
