5 | TECHNICAL SPECIFICATIONS

ASM10
System 2-way vented box
LF Custom 10" Woofer,
2" VC
HF 1" compression driver,
1" VC
Amplification Class-D + Class-A/B
Peak power (LF+HF) 400W
Frequency response 70Hz-20kHz
(+/-10dB)
MAX SPL 122dB
DSP 56Bit
AD/DA conversion 24Bit / 48kHz
EQ 2 Presets
Input and output MIC/LINE COMBO
connectors (XLR-F + 2 x jack
6.35mm. 1/4")
LINK output: XLR-M
Controls LEVEL,
LINE/MIC switch
ON-PEAK/SIGN LEDs
PRESET button
ASM Series
10 User manual |
ASM12 ASM15
2-way vented box 2-way vented box
Custom 12" Woofer, Custom 15" Woofer,
2.5" VC 3" VC
1" compression driver, 1" compression driver,
1.35" VC 1.35" VC
Class-D + Class-A/B Class-D + Class-A/B
600W 600W
65Hz-20kHz 55Hz-20kHz
124dB 126dB
56Bit 56Bit
24Bit / 48kHz 24Bit / 48kHz
2 Presets 2 Presets
MIC/LINE COMBO MIC/LINE COMBO
(XLR-F + 2 x jack (XLR-F + 2 x jack
6.35mm. 1/4") 6.35mm. 1/4")
LINK output: XLR-M LINK output: XLR-M
LEVEL, LEVEL,
LINE/MIC switch LINE/MIC switch
ON-PEAK/SIGN LEDs ON-PEAK/SIGN LEDs
PRESET button PRESET button
Operating mains
Fuse
Max power
consumption
Cabinet
Cabinet material
Cabinets finishing
Dimensions
(W x H x D)
Net weight
Optional accessories
10
ASM10 ASM12 ASM15
220-240V~ 220-240V~ 220-240V~
50-60Hz 50-60Hz 50-60Hz
T2A L 250V~ T2A L 250V~ T2A L 250V~
110-120V~ 110-120V~ 110-120V~
50-60Hz 50-60Hz - T4A L 50-60Hz
T4A L 250V~ 250V~ T4A L 250V~
300 W 300 W 300 W
2 recessed handles 2 recessed handles 2 recessed handles
Pole mount Pole mount Pole mount
Ø 35mm. hole Ø 35mm. hole Ø 35mm. hole
15mm plywood 15mm plywood 15mm plywood
Anti-scratch Anti-scratch Anti-scratch
paint with high paint with high paint with high
mechanical mechanical mechanical
resistance resistance resistance
380 x 333 x 480 450 x 338 x 510 495 x 405 x 610
mm mm mm
12 Kg. 19 Kg. 20.5 Kg.
CV-SM10 CV-SM12 CV-SM15
padded cover padded cover padded cover
