Paragon EC72 Series General Instructions Manual

Replacement timer
Hide thumbs
Table of Contents

Advertisement

Quick Links

http://waterheatertimer.org/Paragon-timers-and-manuals.html#EC
Replacement timer
http://waterheatertimer.org/Intermatic-ET-series-timers-and-manuals.html#ET1700
EC72, EC72D
GENERAL INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC72 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Paragon EC72 Series

Summary of Contents for Paragon EC72 Series

  • Page 1 Replacement timer http://waterheatertimer.org/Intermatic-ET-series-timers-and-manuals.html#ET1700 EC72, EC72D GENERAL INSTRUCTIONS...
  • Page 2 MAPLE CHASE COMPANY PRODUCT WARRANTY The products manufactured by Maple Chase Company and used in commer- cial, industrial or institutional applications are warranted to be free from defects in workmanship or material under normal use and service for a period of one (1) year from the date of purchase by the end user (whether separately or as a component of other products), or eighteen (18) months from the date of manu- facture of the Maple Chase Company products, whichever is less.

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ..5 PROGRAMMING CAPABILITIES ..6 SPECIFICATIONS ..7 EC72 INSTALLATION, BATTERY and WIRING ..11 EC72D INSTALLATION, BATTERY and WIRING ..14 FRONT PANEL DESCRIPTION .

  • Page 5: Introduction

    Leap Year and altering ON/OFF events on designated holidays. APPLICATIONS The EC72 Series provides ideal control for indoor and outdoor lighting, heating, ventilation and air conditioning, and motors, pumps and fans in convenience and retail stores, commercial buildings, industrial facil- ities, schools and churches.

  • Page 6: Programming Capabilities

    • Automatic Leap Year Correction • Momentary Option - any EC72 Series model can be converted to a momentary output control by clipping a jumper wire; all events become ON events of two-second duration. (See page 22.) •...

  • Page 7: Specifications

    SPECIFICATIONS ELECTRICAL Power Requirements MODEL VOLTAGE HERTZ VA REQ. EC72/24 24 Vac (+ 10 - 15%) 50/60 EC72/120 100-120 Vac 50/60 EC72/240 200-240 Vac 50/60 EC72/277 277 Vac 50/60 EC72D/12 12 Vdc — — EC72D/24 24 Vac (+ 10 - 15%) 50/60 EC72D/120 100-120 Vac...
  • Page 8 ENVIRONMENTAL The EC72 Series should be mounted indoors in an environment that is free from excessive contaminants such as oil, moisture and dirt or in an appropriate outdoor panel. For outdoor use, an EC72D can be mounted in a NEMA 3 enclosure 4010EC (X9092) which must be pur- chased separately.
  • Page 9 EC72D EC72 Figure 1. EC72 Series Dimensions...
  • Page 10 Spring Clip Figure 2. EC72 Installation...

  • Page 11: Ec72 Installation, Battery And Wiring

    INSTALLATION - EC72 NEMA 1 Case Mounting 1. Press back on spring clip at right center of metal case. See Figure 2 at left. Lift control out and set aside. 2. Remove desired knockouts to provide wiring access. 3. Mount case in a vertical position using the mounting holes provid- 4.
  • Page 12 BATTERY - EC72 Installation — Purchase a 9-volt alkaline or lithium battery (Ultralife, U9VL). Remove battery cover by pulling up right side of cover from the extru- sion that holds it. Swivel battery cover up and out of the way. Snap bat- tery into battery clip.
  • Page 13 WIRING — EC72 1. Remove the gray fish paper insulator card in order to provide access to the terminal block. Wiring access for power input and relay output is provided at bottom of terminal block. Terminals can accommodate 12 to 24 AWG wire. 2.

  • Page 14: Ec72D Installation, Battery And Wiring

    INSTALLATION — EC72D EC72D Surface Mounting 1. Remove back mounting plate by releasing the bright red spring- loaded catch. See Figure 5 below. 2. Install back mounting plate on a vertical or horizontal surface, flush side to panel or wall. Utilize the mounting holes on the back mounting plate.
  • Page 15 BATTERY — EC72D Installation - Purchase a 9-volt alkaline or lithium battery (Ultralife, U9VL). Remove battery cover by pressing sides together and pulling left or right. See Figure 6 below. Snap battery into battery clip. Mark date on battery log. Replace bat- tery cover.
  • Page 16 WIRING - EC72D 1. Loosen terminal cover screw (see Figure 7) and set terminal cover aside. The screw is captive to the control. Wiring access for power input and relay output is provided at bottom of terminal block. Terminals can accommodate 12 to 24 AWG wire. 2.
  • Page 17 Figure 7. EC72D Terminals 1. Contacts are shown in the OFF, or de-energized, state. 2. Maple Chase Company’s solid state controls utilize DRY CON- TACTS. Input power enables the control to keep time, store pro- grammed information and carry out instructions, but input power does not power the loads.
  • Page 18 Figure 8. EC72 Series Keypad and Screen...

  • Page 19: Front Panel Description

    FRONT PANEL DESCRIPTION The keypad and screens on all EC72 Series controls are identical. On the EC72, however, the screen is located above the keypad, while on the EC72D, the screen is located to the left of the keypad. Time/Date Indicator — displays hours and minutes in 24- hour format (e.g., 00:00=midnight, 12:00=noon,...

  • Page 20: General Programming Instructions

    Daily Event and uses only one of the 16 available events. See Repeat Programming on the next page. Momentary Option Any EC72 Series model can be converted to momentary output. This decision should be made prior to programming. See pages 22-23 for more information.
  • Page 21 Repeat Programming Repeat Programming simplifies programming and increases the total number of events through daily repetition of certain ONs and OFFs. For example, say that a certain event will occur at the same time every day — e.g., 8:00 AM ON. Rather than programming 8:00 AM ON Monday, 8:00 AM ON Tuesday, 8:00 AM ON Wednesday, etc., the Daily Key can be used, causing the event to be repeated each and every day of the week and using only one of the 16 available events.
  • Page 22 The Momentary Option provides a two-second momentary contact closure that is ideal for ringing school bells and church chimes or utiliz- ing latching relays. Any EC72 Series model can be converted to momentary output by clipping a jumper wire, which causes all events to become ON events of two-second duration.
  • Page 23 Figure 9A. EC72 Jumper Wire To convert the EC72D: 1. Remove the control according to directions on page 17. 2. The jumper wire, J29, is located on the back side of the control in the upper left-hand corner of the board. See Figure 10 below. Clip J29.

  • Page 24: Programming Time, Day, And Date

    TO PROGRAM TIME, DAY AND DATE Step Key Description Install battery/power. 0:00 1 displayed; colon and 1 flashing. Flashing stops. #### # Enter current time, then day of week. Enter four digits for time (e.g., 0900=9:00 AM). Use 24-hour clock format. See chart below. For day of week, 1=Sunday, 2=Monday, 3=Tuesday, 4=Wednesday, 5=Thursday, 6=Friday, 7=Saturday.
  • Page 25 To Review Date Step Key Description Current time displayed. Flashing stops. Current month and date displayed. Current year displayed. Restores normal operation. Time and day displayed. Colon flashing. C1/C2 Switching of loads occurs only in the RUN mode. If an event was scheduled to occur while you where reviewing information, the event will not have taken place if you were reviewing during the entire minute...

  • Page 26: Programming Events

    TO PROGRAM ON/OFF EVENTS Step Key Description Display goes blank except for the Channel indicator bars, which flash alternately to indicate that a channel number key must be pressed. C1/C2 Selects channel to be programmed. C1 or C2 Indicator bar energizes and E:01 (first event) is dis- played.
  • Page 27 Use the following chart to record events. Circle all days for Daily Events (Key 0). EVENTS TYPE TIME DAY OF WEEK C2 TYPE TIME DAY OF WEEK ON / OFF S M T W T F S 1 ON / OFF S M T W T F S ON / OFF S M T W T F S...
  • Page 28 TO REVIEW OR CHANGE EVENTS Step Key Description Display goes blank except for Channel indicator bars, which flash alternately to indicate that a channel num- ber key must be pressed. C1/C2 Select channel to be reviewed. Selected Channel Indicator bar will energize. The first programmed event will be displayed.

  • Page 29: Override

    NOTES ON EVENTS The weekday keys 1 - 7 and the holiday key 8 have priority over the daily key 0. If an ON/OFF event is programmed for an individual weekday, then all programmed daily events are cancelled for that day on that channel.

  • Page 30: Programming Holidays

    HOLIDAY and DAYLIGHT SAVINGS TIME Twelve single holidays (H:01 - H:12) and two holiday durations (H:13 - H:16) are provided. Fill in the chart at right before you begin. Step Key Description H:01 displayed, indicating Holiday 1. #### Enter month, then date of holiday. Press two keys for month and two for date.
  • Page 31 Use the following chart to record days that will follow the holiday schedule: HOLIDAYS DATE DESCRIPTION H:01 H:02 H:03 H:04 H:05 H:06 H:07 H:08 H:09 H:10 H:11 H:12 H:13 Duration 1 begins H:14 Duration 1 ends H:15 Duration 2 begins H:16 Duration 2 ends FALL...
  • Page 32 To Review or Change Holidays Step Key Description Date of first holiday (H:01) displayed. Press repeatedly to review single day holidays, H:01 - H:12. Press again to review H:13 - H:15, indicating the begin dates for both holiday durations. No colon will appear for H:14 and H:16, the duration end dates.

  • Page 33: Maintenance

    MAINTENANCE Cleaning — Do not use any type of cleaning agent on the liquid crystal display screen or front panel. Control Removal — Any model can be removed from its case. EC72 — See directions on page 11. EC72D — The plug-in case of the DIN model allows removal of the control without disturbing the wiring.

  • Page 34: Applications

    APPLICATIONS — LIGHTING Objective: To control indoor lighting on Channel 1 and parking lot lights on Channel 2. Sequence of Operation: Channel 1 — Relay contacts 3 and 4 close to turn indoor lights ON during building’s open hours. Relay contacts 3 and 4 open to turn indoor lights OFF during business closed hours.
  • Page 35 Figure 13. EC72D Wiring Diagram for Indoor and Outdoor Lighting...
  • Page 36 APPLICATIONS — HVAC Objective: To reduce utility costs by time-of-day scheduling for night setback/setup and damper control. Use Channel 1 for daytime/night- time thermostat, Channel 2 for damper. Sequence of Operation: Channel 1 — Before occupancy of the building, the HVAC system is started when timer switches control from night thermostat to day thermostat.
  • Page 37 Figure 15. EC72D Wiring Diagram for Nighttime Setback and Damper Control...
  • Page 38 APPLICATIONS — SCHOOL BELLS Objective: To ring school bells on a pre-programmed schedule. You must select the Momentary Option and clip the appropriate jumper wire. See pages 22-23. Sequence of Operation: At each scheduled event, the normally open contacts (3 and 4 for Channel 1, 6 and 7 for Channel 2) close for two seconds, ringing school bells.
  • Page 39 Figure 16. EC72 School Bell Wiring Diagram Figure 17. EC72D School Bell Wiring Diagram...
  • Page 40 APPLICATIONS — LATCHING RELAYS Objective: To turn lights ON and OFF in conjunction with a latching relay. User must select the Momentary Option and clip the appropri- ate jumper wire. See pages 22 - 23. Sequence of Operation: Relay contacts 6 and 7 close for two seconds to turn lights ON. Relay contacts 3 and 4 close for two seconds to turn lights OFF.
  • Page 41 Figure 19. EC72D Latching Relay Wiring Diagram...
  • Page 42 APPLICATIONS FOR MOMENTARY CONTROL ONLY The following wiring diagrams allow the Daily Function to be used and still have a day without any events, even though the Momentary Option has been selected. See page 29. To use the Daily Function on a momentary control and still obtain a day without any events, follow these steps: 1.
  • Page 43 Figure 21. EC72D School Bell Alternate Wiring Diagram...
  • Page 44 Figure 22. EC72 Latching Relay Alternate Wiring Diagram Figure 23. EC72D Latching Relay Alternate Wiring Diagram...

  • Page 45: Troubleshooting

    TROUBLESHOOTING TIPS Problem Solution Nothing happens when a • Review programmed setpoints making sure setpoint occurs to turn a the day has not been skipped. load ON or OFF. • Check input power to control. • Ensure the clock is not in a holiday period. •...

  • Page 46: Glossary

    GLOSSARY 7-Day Programming — programming that repeats a schedule every 7 days 8th Day — any of a number of designated holidays that follow a unique schedule, programmed with Key 8 instead of weekday Keys Battery Carryover — a feature that maintains time and programming during power outages but does not power the loads Channel —...

  • Page 47: Index

    INDEX Accuracy, 7 Power requirements, 7 Application, 34 - 44 Programming Capabilities 6, 20 - 21 Back mounting plate, 14 To change programming, 25, 28, 32 Battery, 8, 12, 15 To review programming, 25, 28, 32 Channel Indicators, 19 To understand programming, 20-21 Cleaning, 33 To program - Clock format, 19, 24...
  • Page 48 Maple Chase Company Paragon Electric Canada, Ltd. 5785 Kennedy Road 2820 Thatcher Road Mississauga, Ontario L4Z 2G3 Downers Grove, Illinois 60515 Made in Mexico From outside North America Customer Service 800-951-5526 630-719-5500 Technical Support 800-732-8400 ISO 9002 registered Part Number 110-703B...
