Version 4.0 October 2014

The contents of this manual are subject to change without

notice. Please refer to the Firetide website, www.firetide.com, for

current information.

HotPort, HotPoint, HotClient, HotView, HotView Pro,

MeshBridge, and AutoMesh are registered trademarks of Firetide,

Antenna & Accessory Guide

For HotPort Mesh Nodes and

HotPoint Access Points

Table of Contents

Need help?

Do you have a question about the Firetide AO-024-MIMO-8 and is the answer not in the manual?

Questions and answers

Summary of Contents for UNICOM Firetide AO-024-MIMO-8

Page 1 The contents of this manual are subject to change without notice. Please refer to the Firetide website, www.firetide.com, for current information. © 2014 Firetide, Inc. - A Divion of UNICOM Global HotPort, HotPoint, HotClient, HotView, HotView Pro, MeshBridge, and AutoMesh are registered trademarks of Firetide,...
Page 2: Table Of Contents
Antenna Selection Guide Firetide offers the following tested and approved antennas. It is the user’s responsibility to insure compliance with all applicable laws in the country of operation. Note that some high gain antennas may exceed EIRP limits in some countries. Indoor antennas have RP-SMA connectors, compatible with Firetide HotPort indoor mesh nodes and HotPoint indoor access points.
Page 3 Accessory Guide Cable Assembly CB-015-N Antenna Cable Assembly, 1.5 meter LMR-400 w/ Integrated lightning suppressor N-type con-nector CB-015-N-MIMO MIMO Antenna Cable Assembly for 5200 & 7020. 3 in 1 bundled 1.5 meter LMR-400 cables w/ Integrated lightning suppressor N-type connector CB-025-N-MIMO MIMO Antenna Cable Assembly for 5200 &...
Page 4 Waterproofing Instructions Most antenna problems are caused by coaxial cable connections that Fig. 1 loosen due to vibration, allowing moisture to penetrate the connector interface. Firetide recommends that all outdoor cable connections be weatherproofed using butyl mastic, shown in Figure 1.
Page 5 Waterproofing the Cable to Node Connections Fig. 5a Waterproofing the connection of the cable to the lighning supressor and the lightning suppressor to the Firetide node is essentially the same process as the antenna connector. Step 5 Wrap a layer of electrical tape, STICKY SIDE OUT, around the supres-sor-to-node connection, as shown in Figure 5b and 5c.
Page 6 Firetide 2.4 and 5.X GHz Dipole Staging Antenna The Firetide 2.4 and 5.X GHz Dipole staging antenna is shipped with Order Number the Firetide HotPort and HotPoint product line. These 3dBi indoor 2.4 and 5.X GHz Dipole* omnidirectional antennas assist in the network staging process and * staging antenna ships with products their easy-on-eye appearance blends smoothly with the Firetide hardware.
Page 7 Firetide 2.4 and 5.X GHz Dipole Staging Antenna continued from previous page Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 7.
Page 8: Ao-024-Mimo-8
Firetide A0-024-MIMO-8 Omnidirectional Antenna The Firetide A0-024-MIMO-8 8dBi omnidirectional antenna is Order Number designed to provide maximum performance and reliability under AO-024-MIMO-8 the toughest weather conditions. The antenna features a UV-stable, vented radome that provides ultimate protection against weather elements. This antenna can be mast or ceiling mounted. Benefits •...
Page 9 Firetide A0-024-MIMO-8 Omnidirectional Antenna continued from previous page 145 mm 145 mm 600 mm 600 mm Antenna "L" type bracket Mast (supplied by customer) Page 9. Firetide Antenna & Accessories Guide | Version 4.0 | October 2014...
Page 10: Aoi-245-Mimo-25
Firetide AOI-245-MIMO-25 Antenna Firetide AOI-245-MIMO-25 antenna is a dual-band, MIMO, Order Number ceiling mount antenna designed to provide maximum vertical AOI-245-MIMO-25 polarization. This high performance antenna reduces overhead clearance requirements and comes in an attractive enclosure. At an affordable price , this antenna is an ideal choice for building public safety, retail establishments, enterprise networks, public “hot spots”...
Page 11 Firetide AOI-245-MIMO-25 Antenna continued from previous page Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 10b.
Page 12 Firetide 4000-1111 2.4 GHz Omnidirectional Antenna This 7 dBi omnidirectional antenna is designed to provide maximum performance and reliability under the toughest Order Number weather conditions. The antenna features a UV-stable 4000-1111 radome that provides protection against weather. Typical Value Frequency Range 2.4-2.5 GHz Gain...
Page 13: Ao-050-Mimo-9
Firetide A0-050-MIMO-9 Omnidirectional Antenna The Firetide A0-050-MIMO-9 omnidirectional antenna is Order Number designed to provide maximum performance and reliability AO-050-MIMO-9 under the toughest weather conditions. The antenna features a UV-stable, vented radome that provides ultimate protection against weather elements. This antenna can be can be mast or ceiling mounted.
Page 14 Firetide A0-050-MIMO-9 Omnidirectional Antenna continued from previous page 145 mm 145 mm 600 mm 600 mm Antenna "L" type bracket Mast (supplied by customer) Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 13.
Page 15: Dbi
Firetide AO-050-N Antenna The Firetide AO-050-N antenna is a 12 dBi omnidirectional Order Number antenna designed to provide maximum performance and AO-050-N reliability under the toughest weather conditions. This antenna features a UV-stable that provides ultimate protection against weather elements. They can be mast or ceiling mounted. Features and Benefits: •...
Page 16 Firetide AO-050-N Antenna continued from previous page 20 mm Antenna Splint & Hose Clamp Mast ≤60 mm diameter 570 mm (supplied by customer) Connector Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 15.
Page 17: Dbi
Firetide AP-050-N Antenna The Firetide AP-050-N is a directional panel antenna with Order Number wide spectrum coverage that provides a cost effective AP-050-N solution for high volume deployments. With an aluminum frame and ploycarbonate radome, it is rugged and highly sun and weather resistant, with an expected service life in excess of ten years.
Page 18 Firetide AP-050-N Antenna continued from previous page Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 17.
Page 19 Firetide AP20-050-MIMO-19 Antenna AP20-050-MIMO-19 is a 19 dBi panel antenna that is best Order Number suited to 5 GHz deployments making it an ideal candidate for AP20-050-MIMO-19 the large city-wide and other video surveillance applications. This low-profile antenna features rugged design with UV- coated Aluminum alloy and withstands the challenging outdoor conditions easily.
Page 20 Firetide AP20-050-MIMO-19 Antenna continued from previous page Page 19. Firetide Antenna & Accessories Guide | Version 4.0 | October 2014...
Page 21 Firetide AP10-050-MIMO-23 Antenna AP10-050-MIMO-23 is a dual polarization MIMO antenna Order Number that is best suited to 5 GHz deployments making it an ideal candidate for the large city-wide and other video surveillance AP10-050-MIMO-23 applications. This low-profile antenna features rugged design with UV-coated Aluminum alloy and withstands the challenging outdoor conditions easily.
Page 22: Dbi
Firetide AP5-050-MIMO-28 Antenna The dual polarized AP5-050-MIMO-28 is a high precision Order Number parabolic dish antenna. The main advantage of this high gain AP5-050-MIMO-28 antenna is the amazing precision for high directivity with narrow bandwidth. This makes it ideal for point-to-point links and for WLAN data communications.
Page 23 Firetide AP5-050-MIMO-28 Antenna continued from previous page Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 22.
Page 24: Dbi
Firetide AS-050 Specifications Firetide AS-050 Specifications The Firetide AS-050-N is a directional 90-degree sector antenna Order Number with wide spectrum coverage that provides a cost effective solution AS-050-N for high volume deployments. To insure good coverage, it offers null fill in the elevations plane. With an aluminum frame and plastic radome, it is rugged and highly sun and weather resistant, with an expected service life in excess of ten years.
Page 25: As90-050-Mimo-16T
Firetide AS90-050-MIMO-16T Antenna AS90-050-MIMO-16T is a triple polarized directional Order Number 90-degree sector antenna. The triple polarization provides AS90-050-MIMO-16T highest level of efficiency with minimum interference for optimum decorrelation. The radome is made of strong corrosion-resistant material to withstand tough outdoor environment.
Page 26 Firetide AS90-050-MIMO-16T Antenna continued from previous page Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 25.
Page 27 Firetide MT-7100 Bracket Order Number MT-7100 Firetide Antenna & Accessories Guide | Version 4.0 | October 2014 Page 26.
Page 28 Firetide SP-7200-03 Mounting U-bolt Kit • M6x1.0, 40mm hex bolts Order Number • M6x1.0, 20mm hex bolts SP-7200-03 • M6 Nuts, SS • M6 Flat Washers • M6 Split Lock Washers • Mounting U-bolts, 80mm • Claw-tooth Pole Gripper Saddles •...
Page 29 7020 Universal Mounting Bracket Install Guide Planning Your Installation • Ground rods should be copper, 1.8–2.4 m (6–8 ft) long. • Install all grounding components in straight lines. If Staging Considerations bends are unavoidable, do not make sharp turns. Using the provided temporary staging antennas, set up and •...
Page 30 continued from previous page Mounting the HotPort Using the Universal Mounting Bracket Firetide’s HotPort can be mounted to a wall or onto a vertical or horizontal pole. The HotPort’s universal mounting bracket provides holes and slots for use with the provided mounting kit or for straps (not included) or other mounting methods.
Page 31 Firetide Multiple Mount • Mount Order Number • Mounting Clamp Saddle SP-MNT-01 • M8x140 Bolts, with Flat and Lock Washers • Does not include wall mounting expansion bolts or pole straps/worm gear clamps Multiple WALL MOUNTING Mount Unit (expansion screws not included) Mounting Clamp Saddle with...
Page 32 Installation Tips An antenna is one of the most critical components in any RF Selecting Antennas communications system. Its performance determines the quality In general, use the lowest-gain antenna adequate for the appli- and the continuity of data flow in both directions. cation.
Page 33 Caution! Risk of electric shock! POWER LINES CAN BE LETHAL Use approved non-conducting ladders, shoes, and other safety equipment. Make sure all equipment is in good repair. Every year, people are killed by touching overhead power lines with metal poles or objects. Don’t be one of them. If a tower or pole begins falling, don't attempt to catch it.
