- Page 1 Fire Pit Burner Kit Electronic Ignition Installation and Operating Instructions...
-
Page 2: Installation Precaution
If you cannot read or understand these installation instructions, do not attempt to install or operate this appliance. RECTANGLE LINEAR ROUND MODELS: MODELS: MODELS: SS/OB-AFPP-18EIPS-LP SS/OB-LCB-30EIPS-LP SS/OB-RSP-19EIPS-LP SS/OB-RSP-25EIPS-LP SS/OB-LCB-36EIPS-LP SS/OB-AFPP-24EIPS-LP SS/OB-LCB-48EIPS-LP SS/OB-AFPP-30EIPS-LP SS/OB-LCB-60EIPS-LP SS/OB-AFPP-36EIPS-LP SS/OB-LCB-72EIPS-LP SS/OB-AFPP-48EIPS-LP Installation Precaution provide proper ventilation can void the warranty. Warning : For outdoor use only Please retain this manual for future reference... - Page 3 Danger Carbon Monoxide Hazzard This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car, or home. Danger Warning If you smell gas: Do not store or use gasoline or other...
- Page 4 Input Rate (Btu/hr): Model No. BTU Rating Part Number LP/NG BTU Center of Flame SS-AFPP-18EIPS-LP OB-AFPP-18EIPS-LP SS-AFPP-24EIPS-LP OB-AFPP-24EIPS-LP SS-AFPP-30EIPS-LP OB-AFPP-30EIPS-LP SS-AFPP-36EIPS-LP Maximum Overhang OB-AFPP-36EIPS-LP SS-AFPP-48EIPS-LP 145K OB-AFPP-48EIPS-LP SS-LCB-30EIPS-LP OB-LCB-30EIPS-LP SS-LCB-36EIPS-LP OB-LCB-36EIPS-LP 145K SS-LCB-48EIPS-LP OB-LCB-48EIPS-LP SS-LCB-60EIPS-LP 145K OB-LCB-60EIPS-LP 145K SS-LCB-72EIPS-LP Figure 1. Clearance of Combustables...
- Page 5 Fire Pit Pan Fire Pit Pan Size and Embedded Panel Embedded Panel Burner Dimension Rectangle Burner Pan Linear Burner Pan Round Burner Pan 18” 24” 30” 36” 48” 30” 36” 48” 60” 72” 19” 25” Pan Size 20.5” 26.5” 32.5” 38.5”...
- Page 6 Components Specifications Quantity Burner Pan 18” / 24” / 30” / 36” / 48” Burner H-Burner Ignitor Box 66*30*46 Burner Baffle 146*50 Orifice 5/8-18UNF Bellows 5/8-18UNF Ignition Needle UL3573 Thermocouple M8*1.0 Safety Valve 5/8-18UNF Regulator 1/2 PSI Ignition Light Touch Control Knob Control Box Screw...
- Page 7 Components Specifications Quantity Burner Pan 30” / 36” / 48” / 60” / 72” Burner Straight Tube Burner Ignitor Box 66*30*46 Burner Baffle 146*50 Orifice 5/8-18UNF Bellows 5/8-18UNF Ignition Needle UL3573 Thermocouple M8*1.0 Safety Valve 5/8-18UNF Regulator 1/2 PSI Ignition Light Touch Control Knob Control Box...
- Page 8 Components Specifications Quantity Burner Pan 19” / 25” Burner 13” Round Ignitor Box 66*30*46 Burner Baffle 146*50 Orifice 5/8-18UNF Bellows 5/8-18UNF Ignition Needle UL3573 Thermocouple M8*1.0 Safety Valve 5/8-18UNF Regulator 1/2 PSI Ignition Light Touch Control Knob Control Box Screw 1/4”...
-
Page 9: Installation Safety Guidelines
Installation Safety Guidelines A. Installation and repair should be done by a qualified service person. The appliance should be inspected before use and at least annually by a qualified service person. More frequent cleaning may be required as necessary. It is imperative that control compartment, burners and circulating air passageways of the appliance be kept clean. -
Page 10: Quick Coupler Operation
Safe Use & Maintenance Of Propane Gas Bottles IMPORTANT FOR YOUR SAFETY READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE-GAS CYLINDER. When operating this appliance with a propane-gas cylinder, these instructions and warnings MUST be observed. FAILURE TO DO SO MAY RESULT IN A SERIOUS FIRE OR EXPLOSION. CYLINDER/CONNECTOR REQUIREMENTS The use of pliers or a wrench should not be necessary. - Page 11 Glass Crystals Installation Guidelines A. Carefully inspect the carton for shipping damage. If any parts are missing or damaged, call your dealer. Do not attempt to install the appliance unless all parts are in good condition. B. Correct installation is crucial to safe performance of your Outdoor Fire Pit. Glass Requirement Replacement parts available from your local retailer RECTANGLE...
-
Page 12: Converting To A Different Gas Type
Converting To A Different Gas Type To convert propane to natural gas or from natural to propane gas, carefully follow the steps below: SHUT OFF THE GAS SUPPLY TO THE UNIT AND ANY NEARBY ELECTRICAL SOURCES OR APPLIANCES. 1. If present, remove all decorative media from the unit. 2. - Page 13 Converting To A Different Gas Type (continued) Figure 3 Figure 4 Disconnect propane hose and regulator (do not Natural Gas Orifice and Natural Gas Air Shutter discard) (Included) Figure 5 Orifice Air shutter (Used only with natural Burner Tube (Remove to change to a different gas.
-
Page 14: What To Do If You Smell Gas
Operating The Unit - Lighting And Extinguishing For your safety, read before lighting WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. BEFORE LIGHTING, smell all around the unit area C. - Page 15 Installation Of Fire Pit Into An Approved Enclosure REQUIREMENTS 1. Only non-combustible materials should come in direct contact with any part of the Fire Pit. Underneath area should be non-combustible as well. 2. Only use ¾” gas supply line to the Fire Pit. Based on the selection of the fire pit size, the proper brass fittings should be used to ensure a proper installation.
- Page 16 Warning *Do not use this fire pit for cooking. *Do not burn any other materials than are supplied with and intended for use in this fire pit. *Do not pour water into fire pit. *The installation of this product must conform with local codes. *Do not use this fire pit if any part has been under water.
-
Page 17: Operation
Liquid Propane Gas Units * Do not attempt to disconnect the gas regulator or any gas fitting while your fire pit is in operation. * A dented or rusty liquid propane cylinder may be hazardous and should be checked by your gas supplier prior to use. * Do not use a liquid propane cylinder with a damaged valve and any other worn out parts. -
Page 18: Maintenance
Limited Warranty American Fire Glass company warranties components in fire pits against manufacturing defects that prevent safe and correct function as follows: • Electronics, Gas Valve, & Pilot Assembly: 1 yr. • Stainless Steel Pan, Fire Ring, & Valve Box: 5yrs.
