Summary of Contents for Kitables BLUETOOTH SPEAKER V.1
- Page 1 BLUETOOTH SPEAKER kit instructions Of note, there are two versions of the Bluetooth speaker (as we’ve changed out parts and suppliers) Check your parts and follow version 1 or 2 instructions.
-
Page 2: Getting Started
Bluetooth Speaker Kit Instructions V.1 Getting Started Version 1 Kit Includes: (a) Laser Cut Box USB Charging Module 1) Check your parts list. (b) 2 Speakers (g) Micro USB Cable (c) LiPo Battery (h) Switch 2) Read through the instructions. (d) Amplifier Board Wires/Heat Shrink 3) Gather your tools. - Page 3 Bluetooth Speaker Kit Instructions V.1 Start by gluing each speaker (b) to the frame. Insert the On/Off switch into the cutout that You will only need a little glue along the edge fits. If you need glue, apply a small amount of each speaker.
- Page 4 Bluetooth Speaker Kit Instructions V.1 Start Soldering Be sure to snug micro USB port as close to edge as possible – if set too deep it will Solder two red wires to each switch pin. be difficult to plug in micro USB cable for You can cover the pins with heat shrink to charging.
- Page 5 Bluetooth Speaker Kit Instructions V.1 Solder 1 red wire coming from the switch Twist together 3 black wires. Solder these to a red LiPo battery wire. Cover these wires to the black battery wires. wires with heat shrink.
- Page 6 Bluetooth Speaker Kit Instructions V.1 Solder 1 black wire from battery to the Glue box side with switch to box side Charging module labeled BAT-. Note: with charging module. The Micro USB slide heat shrink on battery wire before port should line up with the small cut out. soldering so you can shrink over joint.
- Page 7 Bluetooth Speaker Kit Instructions V.1 Insert audio cable into jack on bluetooth Solder 1 red switch wire (from other pin) adapter (green). Cut the audio cable to to the bluetooth adapter as shown. expose 3 wires (red, blue, yellow) which you will solder to the red amplifier board.
- Page 8 Bluetooth Speaker Kit Instructions V.1 Solder a 2 black wire from the battery Solder the wires from the audio cable to to the bluetooth adapter as shown. the amplifier. LN: red wire GND: yellow wire RN: blue wire Plugs into bluetooth adapter...
- Page 9 Bluetooth Speaker Kit Instructions V.1 Solder remaining red switch wire and Solder 1 blue and 1 white wire to each remaining black battery wire to the of the speaker terminals. Positive and amplifier board. Negative terminals just need to be consistent with your colors and the location on the amplifier.
-
Page 10: Wiring Diagram
Bluetooth Speaker Kit Instructions V.1 Wiring Diagram Solder the speaker wires to amplifier as outlined. Fitting all the wires from the audio cable, battery and speakers gets very tight and requires a lot of patience! Switch Lipo Bluetooth Battery Adapter R+: blue R-: white BAT+... -
Page 11: Charging Battery
Bluetooth Speaker Kit Instructions V.1 Now that your circuit is complete, test that it Once everything is working, gently stuff works (turn it on) and that it will pair with your into the box. If you feel confident about playing device. If you hear some static, check your connections, glue the box closed! your solder connections and charge your battery. - Page 12 Bluetooth Speaker Kit Instructions V.2 Getting Started Version 2 Kit Includes: (a) Laser Cut Box* (f) 5V Booster 1) Check your parts list. (b) 2 Speakers (g) Micro USB Cable 2) Read through the instructions. (c) LiPo Battery (h) Switch 3) Gather your tools.
- Page 13 Bluetooth Speaker Kit Instructions V.2 Secure Components Insert the On/Off switch into the cutout that fits. If you need glue, apply a small amount on Start by gluing each speaker (b) to the frame. edge, but be careful not to freeze the switch You will only need a little glue along the edge permanently in one position.
- Page 14 Bluetooth Speaker Kit Instructions V.2 Start Connecting Wires Be sure to snug micro USB port as close to edge as possible – if set too deep it will Strip wires so they can be easily twisted be difficult to plug in micro USB cable for together and secured to components.
- Page 15 Bluetooth Speaker Kit Instructions V.2 Attach the twisted battery wires to the Twist 1 of the available red wires to the battery charging module. Black wires red battery wire and 1 of the available connect to the BAT- terminal, Red wires black wires to the black battery wire.
- Page 16 Bluetooth Speaker Kit Instructions V.2 Attach Red wire from the battery module to Attach the free Red wire from the switch to one Switch terminal. Attach a 2 Red wire to the IN+ terminal of the Booster. Attached 1 the open Switch terminal. The switch should Black wire from the battery module to the already be inserted into the box.
- Page 17 Bluetooth Speaker Kit Instructions V.2 Attach a Red wire to the 5V terminal on Attach the Red and Black wires from the the Booster. Attach a Black wire to the Booster to the Bluetooth board. Black GND terminal on the Booster. wire to the GND terminal, Red wire to the +5V terminal.
- Page 18 Bluetooth Speaker Kit Instructions V.2 Attach the JST cable to the Bluetooth Attach the JST cable wires to the board. The 4 JST wires will connect to the Speakers. Positive and Negative are not speakers. critical on these speakers.
- Page 19 Bluetooth Speaker Kit Instructions V.2 Wiring Diagram Test your connection by turning on the switch. You will see the Booster and the Bluetooth boards light up. Lipo Battery BAT+ BAT- Charging Module Booster Bluetooth Speaker Speaker...
- Page 20 Bluetooth Speaker Kit Instructions V.2 Now that your circuit is complete, test that it Once everything is working, gently stuff works (turn it on) and that it will pair with your into the box. If you feel confident about playing device. If you hear some static, check your connections, glue the box closed! your solder connections and charge your battery.
- Page 21 Bluetooth Speaker Kit Instructions You have now completed a Kitables Kit! If you have questions, check out our FAQ at Kitables.co or email us at info@kitables.co...
