Summary of Contents for JupiterTech DEFIANT
- Page 1 US E R MA N U A L...
- Page 2 User Manual x 1 before riding. Please abide by all safety Charger x 1 Battery Lock Keys x2 measures and contact us if there are any problems. JupiterTech 5600 Airport Blvd., Suite C Tampa, FL 33634 813-609-BIKE (2453) sales@jupiterbike.com www.jupiterbike.com...
-
Page 3: Table Of Contents
T ABL E OF CONTENTS Structural Diagram - 4 Initial Setup - 5 Unfolding the Handle Stem - 6 Installing the Handle - 7 Installing the Seat Post - 8 Unfolding the Pedals - 9 Charging the Battery - 10 Removing the Battery - 11 Battery and Charger Care - 12 The LCD Display - 13... -
Page 4: Structural Diagram
STRUCTURAL DIAGRAM Brake Handle Saddle Stem Latch Lock Seat Post Stem Latch Bike Frame Latch Seat Post Clamp Bike Frame Flashlight Front Fork Chainwheel Motor Pedal Disc Break... -
Page 5: Initial Setup
INITIAL SETUP 1. Turn the bike upside down as it is easier to install wheel 2. Adjust the front fork and ensure it is facing the correct way 3. Place the front wheel on the front fork, ensuring the 4. Secure wheel with the quick brake plate is align with the brake release... -
Page 6: Unfolding The Handle Stem
UNFOLDING THE HANDLE STEM 1. Tilt stem upright to ensure it connects 2. To ensure seamless fit, press the lever seamlessly with the base down, so that the silver knob is out. 3. Push lever upward to flush silver knob, 4. -
Page 7: Installing The Handle
INSTALLING THE HANDLE 1. Lift the quick-release lock from the 2. Set aside the nut and gasket, but leave the handlebar holder and remove the lower screw screw in place. 3. Place the handlebar inside the holder, then 4. Adjust handle bar angle and position to your close the holder allowing the screw to come preference. -
Page 8: Installing The Seat Post
INSTALLING THE SEAT POST 1. Loosen the seat post clamp and insert saddle post. 4. To secure the saddle, tighten the seat post clamp as 2. Adjust saddle to the preferred pictured, and then press the seat downward firmly to height then tighten clamp. -
Page 9: Unfolding The Pedals
UNFOLDING THE PEDALS 2. Pull pedal towards you. The pedal is secure 1. To unfold pedals, push up pedal when you hear a click. 3. To fold pedals, press it inward 4. Fold pedal into a upward position... -
Page 10: Charging The Battery
CHARGING THE BATTERY Be sure to charge the battery before your first Option 1: Insert charger to charge from the ride! bike frame port Option 2: Remove battery from bike frame Option 2: Plug in charger directly into the (See next page) battery... -
Page 11: Removing The Battery
REMOVING THE BATTERY 1. Turn black knob to release the silver bar 2. Pull back silver bar 3. Fold bike to reveal battery 4. Lift handle gently to pull out battery... -
Page 12: Battery And Charger Care
BATTERY & CHARGER CARE • To help maintain the life of your battery, do not charge in extreme hot or cold temperatures. The suitable range for charging is between 0°-45°C / 32°-113°F • Always keep the battery away from acid, alkaline, water, & fire •... -
Page 13: The Lcd Display
THE LCD DISPLAY Power Button Speed Battery Current Pedal Assist ODO/Trip Battery... - Page 14 THE LCD DISPLAY Wheel Diameter Set Throttle Fault Icon Brake Icon Controller Fault Icon Light Instruction Motor Fault Icon...
-
Page 15: Turning On Your Bike
TURNING ON YOUR BIKE Once the bike is charged, hold the power button on the LCD to powr up your bike Congratulations! You are ready for your first ride! Don’t Forget! Practice common sense & safety measures when riding your bike. -
Page 16: Precautions When Riding
PRECAUTIONS WHEN RIDING • Wear the appropriate protection gear such as helmets, knee pads, and elbow pads on your rides to help prevent injury. • Inspect the bike, brakes, & battery before each ride to ensure all is in working order. •... -
Page 17: Maintenance & Storage
MAINTENANCE & STORAGE • To clean your bike, use a soft damp cloth to wipe clean. To protect internal wiring and electric components do not soak or rinse your bike with water. Wipe clean with mild detergent and a damp cloth. -
Page 18: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE MAINTENANCE PURPOSE No power assistance No Power Check if Battery is installed correctly when bike is turned on. Check if Battery needs charging Not enough mileage Battery not fully charged Check if charger is working Tire pressure low Check tire pressure Frequent brakes/starts Ride with good habits... -
Page 19: Warnings
WARNINGS To enjoy your Jupiter Bike Defiant fully, please read this section in its entirety and please take it seriously. RIDE AT YOUR OWN RISK AND USE COMMON SENSE. FAILURE TO USE COMMON SENSE AND HEED THE WARNINGS IN THIS MANUAL AND BELOW ONLY SERVES TO INCREASE THE RISK OF SERIOUS INJURY AND/OR DEATH. - Page 20 WARNING: PARENTAL AND ADULT RESPONSIBILITY & SUPERVISION IS NECESSARY: Because products, like electric bicycles, can and do present potential hazards plainly associated with their use, it is well recognized THE NEED TO EXERCISE PARENTAL RESPONSIBILITY IN SELECTING RIDING PRODUCTS APPROPRIATE TO THE AGE OF THE CHILD, OR PARENTAL SUPERVISION IN SITUATIONS IN WHICH CHILDREN OF VARIOUS AGES MAY HAVE ACCESS TO THE SAME RIDING PRODUCTS, IS IMPORTANT.
- Page 21 that the bicycle frame is in good condition with no cracks or other breaks. Check that the brakes are functioning properly, that the tires are securely fastened and rotate smoothly. The bicycle should be maintained and repaired in accordance with the manufacturer’s specifications, using only the manufacturer’s authorized replacement parts, and should not be modified from the manufacturer’s original design and configuration.
-
Page 22: Acceptable Riding Practices And Conditions
ACCEPTABLE RIDING PRACTICES & CONDITIONS Always check and obey any local laws or regulations which may effect the locations where the electric bicycle may be used. Keep safely away from cars and motor vehicle traffic at all times. Only use where allowed and with caution. Do not activate the accelerator unless you are on the bicycle, wearing safety gear and in a safe, outdoor environment suitable for riding. -
Page 23: Warranty
If you feel your Jupiter Bike Defiant is not operating properly and needs a replacement part, contact Jupiter Tech at 813-609-BIKE (2453) or email sales@jupiterbike.com for assistance. - Page 24 JupiterTech 5600 Airport Blvd., Suite C Tampa, FL 33634 813-609-BIKE (2453) sales@jupiterbike.com www.jupiterbike.com...
