- Page 1 KD-X40MRx 4K/18G HDBT Rx (40m) with L/R Audio De-Embed, IR, RS-232. Receiver Only. Operating Instructions The Experts in Digital Video Technology and Solutions ™...
-
Page 2: Table Of Contents
4K/UHD 18G signals are extended up to 40m / 131ft and 1080p up to 70m / 230ft via single CAT5e/6 cable. In addition to AV signals, KD-X40MRx extends IR and RS-232 for controlling remotely located equipment. - Page 3 Key Features Tx Options: Sold a-la-carte to integrate natively with KD-X2x1WDTx and KD-X2x1WVTx wall-plate › transmitters (sold separately). Flexible Power over HDBaseT: Rx powers Tx when integrated with KD-X2x1WDTx / KD-X2x1WVTx. › Rx is powered by Tx when integrated with KD-PS42 / KD-UPS42 Audio De-embedding: Audio of the incoming source is de-embedded at the unit’s analog L/R audio ›...
-
Page 4: Quick Setup Guide
6. BEFORE connecting power supply to power outlet, secure power into screw connector on Rx unit / presentation switch 7. AFTER all connections are made, plug-in power supply to power outlet 8. Power on input/output devices Integration Options Integration with KD-X2x1WDTx: KD-X2x1WDTx KD-X40MRx HDMI KD-X2x1WDTx KD-X40MRx HDMI HDBT HDMI... - Page 5 ® ® » DTS-HD Master Audio , and Dolby Atmos ™ ® Supports CEC pass-thru from source/display or Key Digital Presentation Switcher with » CEC Manager ™ Supported standard 4K Video Formats: Resolution Bandwidth 1 4K@24/25/30 [4:4:4] 8bit < 10.2Gbps 2 4K@24/25/30 [4:2:2] 8/10/12bit <...
-
Page 6: Introduction
» http://www.keydigital.com/category_Presentation.html for compatible Tx models. » May not be compatible with other Key Digital and non-Key Digital HDBaseT Tx. » L/R Audio Output: Provides de-embedded 2ch Analog Audio Output from the source selected at the › Wall Plate Tx / Presentation Switch. - Page 7 › Corresponds with Output 2’s IR Out port of the presentation switcher » Only the included IR sensors are compatible with KD-X40MRx. Third-party IR Sensors may not be » compatible. Note: There is no IR Out port on compatible wall plate Tx units (KD-X2x1WDTx, KD-X2x1WVTX) »...
-
Page 8: Use With Third-Party Hdbaset Tx Or Rx
› Provides power to KD-X40MRx and the connected wall plate Tx unit. » If KD-X40MRx is integrated with Presentation Switcher, then power supply connection is not » required at KD-X40MRx as power is provided from the Presentation Switcher. LED Lights: Indicate system connectivity status ›... -
Page 9: Specifications
Specifications Technical: Inputs: 1 HDBaseT, 1 Bi-Directional RS-232, 1 IR » Outputs: 1 HDMI, 1 L/R Stereo Audio, 1 Bi-Directional RS-232, 1 IR » DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL) » HDMI Video/Audio Signal: Input Video Signal: 1.2 Volts p-p »... -
Page 10: Important Product Warnings & Safety Instructions
Damage to the power supply or power plug » Exposure to rain or moisture » Power Supply Use: You MUST use the Power Supply PROVIDED with your unit or you VOID the Key Digital Warranty ® and risk damage to your unit and associated equipment. -
Page 11: Contacting Key Digital
