Fixed Thermal Imaging System
Installation Guide
Including SDS-E Slag Detection System
Installation & User Guide
Issue 5
15 January 2016
Publication Nº 804513
Language: English
© Land Instruments International, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fti-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Ametek Land Fti-E

  • Page 1 Fixed Thermal Imaging System Installation Guide Including SDS-E Slag Detection System Installation & User Guide Issue 5 15 January 2016 Publication Nº 804513 Language: English © Land Instruments International, 2016...
  • Page 2 IMPORTANT INFORMATION - PLEASE READ Health and Safety Information Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS - before using this product. If there is any instruction which you do not understand. DO NOT USE THE PRODUCT. Safety Signs WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or...
  • Page 3 Contact Us UK - Dronfield USA - Pittsburgh Land Instruments International AMETEK Land, Inc. Tel: +44 (0) 1246 417691 Tel: +1 412 826 4444 Email: land.enquiry@ametek.co.uk Email: irsales@ametek.com Web: www.landinst.com combsales@ametek.com Web: www.ametek-land.com For further details on all LAND/Ametek offices, distributors and representatives, please visit our websites.
  • Page 4 Fixed Thermal Imaging System Installation Guide...
  • Page 5: Table Of Contents

    Fig. 8 FTI-E PSU Electrical Connection Details Fig. 9 Blower Electrical Connection Details 2-10 Fig. 10 NUDAM I/O Electrical Connection Details 2-11 Fig. 11 FTI-E Remote PC Electrical Connection Details 2-12 Fig. 12 Water Connection Details 2-13 Fig. 13 Air Connection Details...
  • Page 6 Fixed Thermal Imaging System Installation Guide...
  • Page 7: Introduction

    SDS-E Slag Detection System These instructions are provided as a series of simple installation diagrams, covering the installation of the FTI-E and SDS-E thermal camera and its mountings, accessories and services. The only installation difference is the standard FTI-E enclosure is shown in Fig.
  • Page 8: Summary Specifications

    Fixed Thermal Imaging System Installation Guide 1.1 Summary Specifications FTI-E-PSU: Operating Temp Range: 0 to 50°C / 30 to 120°F Sealing: IP65 Power Requirement: 100 to 240V ac 1.0A 50/60Hz EMC: EN61326 Safety: EN61010-1 Camera Operating Temp Range: 5 to 50°C / 40 to 120°F...
  • Page 9 Installation Guide Fixed Thermal Imaging System Input/Output Signals (See NUDAM data sheets for detailed specification) Digital Input via NUDAM 6052 Isolated Digital Input Modules 7 bits isolated digital input VIL: 1V max VIH: 3.5V min (24V max) Impedance 1.2KΩ Isolation 5000V rms Relay Output via NUDAM 6063 Relay Output Module 8 isolated relay outputs...
  • Page 10: General Precautions

    Fixed Thermal Imaging System Installation Guide 1.2 General Precautions If the camera is operating in ambient temperatures in excess of 40°C / 105°F, or if the system is exposed to high levels of radiant heat, a water-cooled plate or air cooling system must be used. The air purge is highly recommended to provide a clean window on the environmental enclosure.
  • Page 11: Installation Diagrams

    Fixed Thermal Imaging System Installation diagrams This section of the Installation Guide contains a series of simple installation diagrams, covering the installation of the FTI-E and SDS-E thermal camera and its mountings, accessories and services. Section 2 Page 2 - 1...
  • Page 12 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 2...
  • Page 13 Installation Guide Fixed Thermal Imaging System Section 2 Page 2 - 3...
  • Page 14 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 4...
  • Page 15 Installation Guide Fixed Thermal Imaging System Section 2 Page 2 - 5...
  • Page 16 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 6...
  • Page 17 Installation Guide Fixed Thermal Imaging System Section 2 Page 2 - 7...
  • Page 18 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 8...
  • Page 19 Installation Guide Fixed Thermal Imaging System Section 2 Page 2 - 9...
  • Page 20 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 10...
  • Page 21 Installation Guide Fixed Thermal Imaging System Section 2 Page 2 - 11...
  • Page 22 Fixed Thermal Imaging System Installation Guide Fig. 11 FTI-E Remote PC Electrical Connection Details Section 2 Page 2 - 12...
  • Page 23 Installation Guide Fixed Thermal Imaging System WATER HOSE No DETAILS SUPPLIED BY CUSTOMER TO SUIT 9.5mm (3/8") OD BARBED HOSE FITTING CUSTOMER TO SUIT 9.5mm (3/8") OD BARBED HOSE FITTING RUGGED HOUSING ALWAYS USE FLEXIBLE PIPING TO ALLOW PAN AND TILT MOVEMENT. CONNECT END OF HOSES TO RUGGED HOUSING WATER INLET &...
  • Page 24 Fixed Thermal Imaging System Installation Guide Section 2 Page 2 - 14...
  • Page 25: A1 About The Sds-E Slag Detection System A1

    Installation Guide Fixed Thermal Imaging System Appendix A A1 About the SDS-E Slag Detection System The Land SDS-E Slag Detection System is designed to withstand the harsh environments associated with the steel industry, by combining the FTI SDS- EA Thermal Imager with a special purpose, rugged environmental housing. The thermal images of the steel and slag stream are relayed to a monitoring PC system through the dedicated Land Image Processing Software;...
  • Page 26: A1.1 Precautions A2

    Fixed Thermal Imaging System Installation Guide A1.1 Precautions The LAND Slag Detection System environmental enclosure and FTI SDS-EA thermal imager may be exposed to hostile environments, where conditions can be extremely testing. The following guidelines should be noted during the installation process:- •...
  • Page 27: A2 Slag Detection System Specifications A3

    Installation Guide Fixed Thermal Imaging System A2 Slag Detection System Specifications Observable temperature range: 400 to 2000°C/752 to 3632°F (based on blackbody temperature) Frame frequency: 30 Hz Focusing range: 4m/13.1ft to infinity Temperature resolution: 0.5°C (for 600°C blackbody) Field of view: 7.5° (horizontal) x 5.5° (vertical) Image pixels: 384 x 288 Detector:...
  • Page 28 Fixed Thermal Imaging System Installation Guide Appendix A Page 4...
  • Page 29 24 MONTHS WARRANTY The following Land Instruments International products are provided with a 24 months warranty: • ARC. • FTI-E • NIR 12 MONTHS WARRANTY All Land Instruments International products not provided with either a 36 month or 24 month warranty (see...
  • Page 30 PRODUCT WARRANTY EXCLUSIONS FROM WARRANTY It should be noted that costs associated with calibration checks which may be requested during the warranty period are not covered within the warranty. Land reserve the right to charge for service/calibration checks undertaken during the warranty period if the cause is deemed to fall outside the terms of the warranty.
