- Page 1 TOTALVIEW HD USER GUIDE...
- Page 2 Safety Vision® is a registered trademark of Safety Vision, LLC. All other products or name brands mentioned in this document are trademarks of their respective owners. For more information about Safety Vision and its products, go to www.safetyvision.com or call 800-880-8855.
-
Page 3: Table Of Contents
TOTALVIEW HD USER GUIDE CONTENTS Product Features Main Wiring Diagram Remote Control User Interface Log In Interface Password Reset Main Menu Interface System Clock AVM Option Setup Import Calibration Files Export Calibration Files Change Vehicle Image Information Hardware Installation Wiring of the Vehicle Body... -
Page 4: Product Features
TOTALVIEW HD USER GUIDE Product Features • Four (4) 190° full HD 1080p wide-angle fisheye cameras, horizontal view angle >170° (8 channel inputs maximum) • Split screen to show 360° view and rear view OR 360° view and front view as default. -
Page 5: Main Wiring Diagram
TOTALVIEW HD USER GUIDE Main Wiring Diagram... -
Page 6: Remote Control
TOTALVIEW HD USER GUIDE Remote Control 1 - POWER - Turn on / off video display on or off. 2 - 0-9 - Input numbers. 3 - CLEAR - Delete a character. 4 - Navigation Keys - Use the left, right, up, and down keys to navigate menus, move the cusor, or shift the image. -
Page 7: User Interface
TOTALVIEW HD USER GUIDE User Interface Log In Interface Input Password Enter an alphanumeric password. The default password should be changed after stitching is finished. The default password is 000000. Note: If the password is forgotten, input “root” to log in. Select factory default setting in the Information menu. -
Page 8: Main Menu Interface
TOTALVIEW HD USER GUIDE Main Menu Interface • System: basic function setting • Clock: system time setting • Storage: storage function and system log management • DVR: Under development • AVM: 360 panorama calibration and related operation • Player: Under development •... -
Page 9: System
TOTALVIEW HD USER GUIDE System • Standby Delay: time frame can be set for standby • AV: select color encoding system ◦ NTSC: 1080p / 60 frames per second (fps) ◦ PAL: 1080p / 50 fps • Full Pannel AVS: Under development •... -
Page 10: Clock
TOTALVIEW HD USER GUIDE Clock Click on the right / left arrows at the top of the screen to scroll through month and year options. Select the date by clicking today’s date on the calendar. Click the up / down arrows at the bottom of the screen to adjust the current time. -
Page 11: Avm Option Setup
TOTALVIEW HD USER GUIDE AVM Option Setup • : inport calibration files from USB flash drive to system. • : export saved calibration files and single views to USB flash drive • : change vehicle image Note: Calibration files are saved as XML files. -
Page 12: Change Vehicle Image
TOTALVIEW HD USER GUIDE Change Vehicle Image This screen allows users to select a vehicle image. Select one of the available vehicle images across the top or upload a custom vehicle image. Click the Save button to apply changes. Note: Custom vehicle images must be saved as a .PNG file to be uploaded. -
Page 13: Hardware Installation
TOTALVIEW HD USER GUIDE Hardware Installation Wiring of the Vehicle Body Wires should be run from the cameras to the control box. Cameras must be positioned in the locations shown and connected to its correct cable (e.g. camera in position 2 connected to the CAM2 cable on the control box). -
Page 14: Calibration Mats
TOTALVIEW HD USER GUIDE Calibration Mats Use the provided adhesive tape to mark a rectangle around the vehicle. Everything outside of the rectangle will be part of the captured images. 2. Measure the length and width of the rectangle. These measurements will be used later during software calibration. -
Page 15: Software Calibration
TOTALVIEW HD USER GUIDE Software Calibration The TotalView AHD system is configured through proprietary software that must be installed on a USB flash drive and accessed with a Windows PC. Use the following procedure to calibrate the cameras through the software: Enter the password and click the login icon. - Page 16 TOTALVIEW HD USER GUIDE 6. In Windows, open the Calibration Tool and click the File tab on the top menu. Then select the Directory exported to the USB flash drive. After the directory has been imported, click on the Manual Calibrate tab on the top menu.
- Page 17 TOTALVIEW HD USER GUIDE Save the modified setup to the USB flash drive. 10. Import the modified setup from the USB flash drive into the control box. If the import is successful the system will automatically restart. 11. The final result should look similar...
-
Page 18: Appendix A: Specifications
TOTALVIEW HD USER GUIDE Appendix A: Specifications IMAGE DEVICE VIDEO OUTPUT 1/2.9” SONY CMOS (IMX323) 1.0Vp-p, 75Ω SCANNING SYSTEM GAMMA CONSUMPTION Progressive 0.45 SYNC. SYSTEM AUTOMATIC ADJUSTMENTS Internal AGC, BLC, white balance FRAME RATE SIGNAL-TO-NOISE RATIO PAL: NTSC: Better than 52dB... -
Page 19: Appendix B: Dimensions
TOTALVIEW HD USER GUIDE Appendix B: Dimensions... -
Page 20: Fcc Compliance Statement
TOTALVIEW HD USER GUIDE FCC Compliance Statement Note This device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide... - Page 21 CORPORATE HEADQUARTERS 6100 W. Sam Houston Pkwy. N. Houston, TX 77041-5113 Main: 713.896.6600 Toll Free: 800.880.8855 Fax: 713.896.6640 www.safetyvision.com...
