importvet SV-2 User Manual

Wifi ultrasound scanner for reproductive diagnosis
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SV-2
WiFi ultrasound scanner
for reproductive diagnosis
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for importvet SV-2

  • Page 1 SV-2 WiFi ultrasound scanner for reproductive diagnosis User manual...
  • Page 2 Unlike traditional veterinary ultrasound scanners with a cable connected to the probe, the SV-2 is wireless and has no cable. The SV-2 probe has a built-in ultrasound image processor, the power supply and the wireless signal module to connect to the main unit.
  • Page 3 Scanning: 80° sector-based Probe: 3.5 MHz transducer Depth: 1 00 - 190 mm Display Mode: Mode B Scales of grey: 256 levels Battery life: 5 hours Size: 140 mm x 45 mm x 40 mm Weight: 200 g SV-2: Wi-Fi Probe...

  • Page 4: Installing The App

    For your protection, please read these safety instructions before starting the probe. 2.1 Unpacking The SV-2 probe is carefully packed to avoid damage during transport. Before opening the box, note any visible damage to its exterior during transport. The items must be checked to ensure everything has been received.

  • Page 5: Connecting The Probe

    When the probe is waiting for a WiFi connection, go to settings on the mobile device and search for the probe SSID. The SSID is, for example,"SV-2 GMBFLA001”. Connect the SSID using the password, which is the same as the serial number printed on the bottom of the probe.

  • Page 6: Ultrasound Scanning

    To switch from one image to another, swipe left or right in the middle of the screen. The WiFi connection status indicates the WiFi SSID of the probe connected. Click on the animal information for a pop-up window to be displayed. Enter the information required in this window: SV-2: Wi-Fi Probe...

  • Page 7: Saving Images

    Data can be re-edited or deleted by swiping the desired data to the left (within the "View data" window). Not available on the mobile version. Important note: ID is required to save data. Up to 500 IDs can be saved. If more are saved the first will be overwritten. SV-2: Wi-Fi Probe...
  • Page 8 When you open the CSV file, you are given the option of opening and sharing the file in other apps such as Excel or Numbers. Provided the data is saved, it can be edited to modify the diagnosis, add comments or delete the record. SV-2: Wi-Fi Probe...

  • Page 9: Exporting Files

    SmartVus documents. Select the file to be exported to the PC and click on “save to...” to export it. Once the export process is complete, check the data on your PC. The exported file only contains data, not images. SV-2: Wi-Fi Probe...

  • Page 10: Maintenance

    Where the temperature of the probe or of the mobile device drops, it should be heated up before use. A last recommendation regarding the battery charge: If the probe and the tablet are not to be used for a long period, they should be stored at full charge. SV-2: Wi-Fi Probe...

  • Page 11: Ec Declaration Of Conformity

    Ronda de la Font Grossa, 22 complies with the requirements of 08540-Centelles, the following Directive. Barcelona (Spain) SV-2 Wi-Fi ultrasound probe for reproductive diagnosis It is in accordance with: Having been submitted to the following standards, Article 3.1b of Radio Equipment Directive...
