Indicator Area Icons
Meaning
Icon
The Signal Strength indicator uses bars to show the strength
of the radio signal. The number of bars increases (up to a
maximum of four) as the signal strength increases.
Note
available.
When no bars are shown, no connection is possible for one
of the following reasons:
Once a connection is established, this icon is replaced by the
Transmit/Receive icon.
The Transmit/Receive indicator lets you know that a
Sprint PCS Vision data connection is active.
Section 2A: Sprint PCS Connection Manager Software
: This icon is displayed only when data services are
No antenna is attached.
You are outside of the Nationwide Sprint PCS
Network service area.
The signal strength is too weak.
A network or account probelm is preventing the
Sprint PCS Connection Card from obtaining service.
37
