SnowEx UTV V-Plow Series Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TrynEx International, LLC, 531 Ajax Drive, Madison Heights, MI 48071-2429 • www.snowexproducts.com
UTV V-Plow
Blade Assembly 77765
Center Assembly 77865
Installation Instructions
CAUTION
Read this document before installing the
snowplow.
CAUTION
See your SnowEx
outlet/website for specifi c
®
vehicle application recommendations before
installation. The Power Match selection
system has specifi c vehicle and snowplow
requirements.
A DIVISION OF DOUGLAS DYNAMICS, LLC
April 1, 2019
Lit. No. 78522, Rev. 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTV V-Plow Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SnowEx UTV V-Plow Series

Summary of Contents for SnowEx UTV V-Plow Series

  • Page 1 Blade Assembly 77765 Center Assembly 77865 Installation Instructions CAUTION Read this document before installing the snowplow. CAUTION See your SnowEx outlet/website for specifi c ® vehicle application recommendations before installation. The Power Match selection system has specifi c vehicle and snowplow requirements.

  • Page 3: Safety Definitions

    SAFETY SAFETY DEFINITIONS WARNING/CAUTION AND INSTRUCTION LABELS WARNING Become familiar with and inform users about the Indicates a potentially hazardous situation warning/caution, serial number and instruction labels that, if not avoided, could result in death or on the back of the blade. serious personal injury.

  • Page 4: Safety Precautions

    SAFETY SAFETY PRECAUTIONS HYDRAULIC SAFETY Improper installation and operation could cause WARNING personal injury and/or equipment and property damage. Hydraulic fl uid under pressure can cause skin Read and understand labels and the Owner's Manual injection injury. If you are injured by hydraulic before installing, operating, or making adjustments.
  • Page 5 SAFETY FIRE AND EXPLOSION NOISE Airborne noise emission during use is 95 dB(A) for the WARNING snowplow operator. Gasoline is highly fl ammable and gasoline vapor is explosive. Never smoke while VIBRATION working on vehicle. Keep all open fl ames away from gasoline tank and lines.

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS UNPACKING T-FRAME TO BLADE ASSEMBLY 1. Set aside the blade guides and parts bag. The 1. Remove the blade wings from the crate. Remove vehicle electrical harnesses are located in the the four shipping straps, then replace the cutting mount box.
  • Page 7 INSTALLATION INSTRUCTIONS 6. Determine whether to use the inside or outside 9. Install the blade guides using 7/16" lock washers angle ram holes, depending on the width of and 7/16" nuts for each guide. the UTV. If the UTV width exceeds 60", attach the angle rams to the outer blade holes.

  • Page 8: Hydraulic Unit

    INSTALLATION INSTRUCTIONS HYDRAULIC UNIT WARNING To prevent accidental movement of the blade, WARNING always turn the control OFF whenever the Keep 8' clear of the blade when it is being snowplow is not in use. The power indicator raised, lowered, or angled. Do not stand light will turn OFF.

  • Page 9: Blade Drop Speed Adjustment

    INSTALLATION INSTRUCTIONS BLADE DROP SPEED ADJUSTMENT FINAL INSPECTION AND ADJUSTMENT WARNING WARNING Keep 8' clear of the blade when it is being Keep 8' clear of the blade when it is being raised, lowered, or angled. Do not stand raised, lowered, or angled. Do not stand between vehicle and blade or directly in front between vehicle and blade or directly in front of the blade.
  • Page 10 OPERATIONAL TEST AND FINAL ADJUSTMENTS Adjusting the Center Cutting Edges Lubricating the Pivot Pin Hinge The center cutting edge gap setter is located on the Using a rubber-tipped seal-off coupler fi tting, apply a T-frame below the pivot pin hinge. good quality multipurpose grease at the fi...
  • Page 11 OPERATIONAL TEST AND FINAL ADJUSTMENTS PLUG COVERS OWNER'S MANUAL PACKET If the completed snowplow will be delivered CAUTION immediately, the Owner's Manual should be reviewed Plug covers shall be used whenever with and given to the purchaser according to the snowplow is disconnected.
  • Page 12 Do not exceed vehicle ratings with a snowplow. TrynEx International offers a limited warranty for all snowplows and accessories. See separately printed page for this important information. The following are registered ( ® trademarks of Douglas Dynamics, LLC: SnowEx ® Printed in U.S.A.
