MK3 User Manual - English
MK3 Parts
Power/Volume
SOS Message
LED Flash
Touch Pen
(Detachable)
Operation and Battery Display
MK3 Status
Power on
Power off
Bluetooth search mode
Device connected
Play music
Voice call/Radio reception
Battery low
Charging
Battery full
www.r2gear.co.kr
Operation
The blue status indicator blinks.
The blue status indicator is turned off.
The blue status indicator blinks twice every 5 seconds.
The blue status indicator blinks once every 5 seconds.
The blue status indicator blinks rapidly.
The blue status indicator blinks rapidly.
The "battery low" voice message sounds.
The red status indicator is turned on.
The red status indicator is turned off.
Call/Play
Recharging/
Earphone Cap
Status Indicator
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MK3 and is the answer not in the manual?

Questions and answers

Summary of Contents for R2GEAR MK3

  • Page 1 MK3 User Manual - English MK3 Parts Power/Volume Call/Play Recharging/ Earphone Cap Status Indicator SOS Message LED Flash Touch Pen (Detachable) Operation and Battery Display MK3 Status Operation Power on The blue status indicator blinks. Power off The blue status indicator is turned off.

  • Page 2: Voice Call

    To hang up the call, press the Call/Play button during the call. (Press and hold the Call/Play button during the MK3 call and the call will be switched to the smart phone. P ress and hold it again and the call will be switched to the MK3.) 2.
  • Page 3 2. When the blue status indicator blinks and the voice message, 'Ready to pair,’ sounds, release the PTT button. 3. MK3 will enter the Android pairing mode. 4. Press the Search button in the Bluetooth Settings of your smart phone.
  • Page 4 1. Search "Zello" in the Playstore and press the "Install" button. 2. Download "Zello" or update it to the latest version. 3. Execute "Zello". 4. Create a "Zello" account. 5. Enter the account information. Registering Zello PPT (Wireless Transmission) Button (for Android) www.r2gear.co.kr...
  • Page 5 5. Press the wireless transmission button. (Some smart phones may require several touches in order to register.) 6. The wireless transmission button is registered in Zello. 7. During radio transmission, press the PTT button to send your voice and release it when the transmission is finished. www.r2gear.co.kr...
  • Page 6 4. Check the checkbox for the “Apply audio mode only when a message is sent or played” option. [Caution] If this option is not checked, the music may not play properly for some smart phone models during the transmission of the radio. 5. Select Legacy Bluetooth mode. 6. Set the Legacy Bluetooth mode to Auto. www.r2gear.co.kr...
  • Page 7 2. Enter the information of the contact (Zello user ID, e-mail address, and phone number) and press the Search button. 3. Press the 'Add to the Contact' button. 4. Wait for the approval of the counterpart. 5. If the counterpart approves, the status changes to Available, (App. launch screen may be revised due to its version update.) www.r2gear.co.kr...
  • Page 8 2. When the blue status indicator blinks and the voice messages 'Ready to pair’ and 'iOS Zello Support' sound s sequentially, release the PTT button. 3. MK3 will enter the iOS pairing mode. 4. Search the device by turning on the Bluetooth of the iPhone.
  • Page 9 Installing Zello (for iPhone) 1. Search "Zello" in the APP store and press the "Install" button. 2. Download "Zello" or update it to the latest version. 3. Execute "Zello". 4. Create a "Zello" account. 5. Enter the account information. www.r2gear.co.kr...
  • Page 10 2. Select Options. 3. Select 'Push-to-talk buttons'. 4. Select 'Wireless Zello button'. 5. Press the 'Wireless button service' button and select MK3(iOS) after it is searched. - Some smart phones may require several touches in order to register. 6. MK3(iOS) is registered.
  • Page 11 4. Select the 'Mix with other audio' option and press 'Off'. [Caution] If you turn on the 'Mix with other audio' option, the playing quality of the music will be lowered to th e quality of the radio transceiver. www.r2gear.co.kr...
  • Page 12 2. Press 'Search for Zello contact' and search for the contact. 3. Select the contact that is searched. 4. Wait for the approval of the counterpart. 5. If the counterpart approves, the status changes to Available, (App. launch screen may be revised due to its version update.) www.r2gear.co.kr...
  • Page 13 A SMS text with location information is sent to the SOS message recipient. The recipient can press the URL address to view the location of the MK3 user. When you send a SOS message, you will be charged for the tr ansmission by the mobile service carrier.

  • Page 14: Major Specifications

    10 hours when playing consecutively at the maximum volume. Usage Duration 15 hours when playing consecutively at the ordinary volume. LED Flash 150 lumen Warranty and Product Authentication Warranty period: The warranty period of this product is one year from the date of purchase. www.r2gear.co.kr...
