Eastern Energy 840063 Instruction Manual

Vibration meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VIBRATION METER
840063
Instruction Manual
www.eastern-energy.net
Email: info@ete.co.th

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 840063 and is the answer not in the manual?

Questions and answers

Related Manuals for Eastern Energy 840063

Summary of Contents for Eastern Energy 840063

  • Page 1 VIBRATION METER 840063 Instruction Manual www.eastern-energy.net Email: info@ete.co.th...

  • Page 2: Table Of Contents

    CONTENTS Title Page Introduction..............Panel Description ............III. Operating Instructions A. General Measurement Procedures ......B. Peak ................. C. Data Hold..............D. Datra Record ............E. Automatic Shut Off........... F. RS232 PC Serial Interface........G. Battery Replacement..........H. Optional Accessories ..........I.

  • Page 3: Ii. Panel Description

    II. PANEL DESCRIPTION (fig. A) 1. DISPLAY 2. POWER BUTTON 9. RS232 OUTPUT TERMINAL 3. HOLD BUTTON 10. BNC SOCKET 4. RMS/PEAK SELECTOR 11. BNC PLUG 5. RECORD BUTTON 12. MINI PLUG 6. RECALL BUTTON 13. INPUT SOCKET 7. ACC/VEL SELECTOR 14.
  • Page 4 6 a. If the surface material of the object you are testing is a non-magnetic material, hold the VIBRATION SENSOR and touch the tip to the object (above). b. If the surface material is magnetic, connect the VIBRATION SENSOR to the MAGNETIC BASE (left) and touch it to the object's surface (below).

  • Page 5: C. Data Hold

    B. PEAK VALUE Switch the RMS/PEAK SELECTOR (A4) to the "PEAK" position. Peak value = 1.414 RMS value. C. DATA HOLD 1. Press the HOLD BUTTON (A3) during measurement to freeze the displayed value. "D.H" is shown on the LCD. 2.

  • Page 6: G. Battery Replacement

    Each digit indicates the following status: End Word D1 to D4 Upper Display reading, D1=LSD, D4=MSD D5 to D8 All "?" (?, ?, ?, ?) Decimal Point(DP), position from right to the left ;0 = No DP, 1 = 1 DP, 2 = 2 DP, 3 = 3 DP D10 to D14 All Zeros (0, 0, 0, 0, 0) Start Word...

  • Page 7: J. Iso 2954 Sensitivity Relative Table

    GROUP G: Large machines on heavy foundations. Good 0 ~ 1.80 mm/s Acceptable 1.81 ~ 4.50 mm/s Still permissible 4.51 ~ 11.2 mm/s Dangerous > 11.2 mm/s GROUP T: Largest machines and turbo machines with special foundations. Good 0 ~ 2.80 mm/s Acceptable 2.81 ~ 7.10 mm/s Still permissible...

  • Page 8: V. Warranty

    SPECIFICATIONS (continued) Frequency 10 Hz~ 1 KHz, sensitivity relative during the frequency range meets ISO 2954 (see pg 6). Weight Meter with battery: 10 oz (230 g). Probe with magnetic base: 2 oz (50 g). Dimension Meter: 17" × 3" × 1 ½" (80 × 75 × 35 mm) Probe cord: 49"...
