Installation and Operating Instructions
Premier Technologies
USB 1100 Series
Important
Before using the Premier Information On Hold Unit,
please read these operating instructions carefully.
Introduction
The USB 1100 is a digital message unit designed for
continuous audio playback. Audio is stored on a
removable USB flash drive and plugged into the USB
hub on the unit. The loading of the audio is easily
done by "dragging and dropping" mp3 file(s) without
the use for special software. Audio files can now be
emailed to clients without the need to mail or ship
physical media.
Dealer Service
A network of authorized Premier Technologies,
dealers can provide service backed by Premier's
technical staff. For the name of your local dealer or
for technical assistance for Premier Technologies,
contact:
Specifications
Memory Type:
Digitizing Rate:
Recording Methods:
Recording Times:
Program Options:
Source Bandwidth:
Output Modes:
Size:
Weight:
Power:
Connectors:
USB Flash Drive
Per mp3 audio file
Drag & Drop on to flash
drive
Selectable per flash
drive
1 of 6 messages or up
to 1023 audio files in
rotation
Per mp3 audio file
600 ohm and 8 ohm
W x L x H = 4"x5"x1"
3Lbs(Boxed)
12V DC AC Adapter
included
RCA to mini & RCA to
RCA (both provided)
Advertisement
Table of Contents
Related Manuals for PREMIER TECHNOLOGIES USB 1100 Series
Summary of Contents for PREMIER TECHNOLOGIES USB 1100 Series
- Page 1 1023 audio files in rotation Dealer Service Source Bandwidth: Per mp3 audio file A network of authorized Premier Technologies, dealers can provide service backed by Premier’s Output Modes: 600 ohm and 8 ohm technical staff. For the name of your local dealer or...
- Page 2 Power LED- indicates power to the unit and blinks the status of the unit. Green – The number of blinks indicate the current mode of play. • 1-6 blinks – One of the possible stored audio files playing from the USB drive •...
- Page 3 Loading Audio Files to the USB Flash Drive 1) Remove the USB Flash Drive from the unit. (The unit may remain powered up.) 2) Insert the USB Flash Drive into your computer. • NOTE: pmode.dat will be one of the files appearing on your computer from the USB drive. This file stores your play mode.
- Page 4 Warranty Upon receipt, Premier Technologies, Inc. will repair or replace, at its option, for a period of three years from the date of purchase, any USB 1100 that proves defective in materials or workmanship. Premier Technologies, Inc. is not liable for indirect, incidental, or consequential damages in connection with the use of this product.
