- Page 1 Assembly Instructions Compatible with: HQ Little Foot™ Frame (HG01405) 01/28/19...
-
Page 2: Table Of Contents
Protect the work surface and drawer by covering the work surface with a protective covering such as a large thick towel. • Do not tighten screws until instructed to do so at the end of the drawer assembly process. Page 2 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions... -
Page 3: Hg01400-02 Drawer Side
Section 1: Removing Drawer Slides from Drawer Sides  IMPORTANT: The drawer slides are ITEM PART # DESCRIPTION lubricated to help them slide smoothly. HG01400-02 DRAWER SIDE Take care while handling the sides and HG01400-10 DRAWER SLIDE-SINGLE ACTION slides, so as to not transfer the lubricant to other surfaces or clothing. -
Page 4: Drawer Rear
M4 serrated flanged nut on the two screws. Â IMPORTANT: Bent end of drawer slide goes to the front, open end of drawer slide goes to the rear. Page 4 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions... -
Page 5: Drawer Bottom Board
Section 3: Drawer Bottom and Front Assembly Step 1: Locate the drawer front (item 1) and the ITEM PART # DESCRIPTION drawer bottom board (item 2). HQ01405-06 DRAWER FRONT HG01405-05 DRAWER BOTTOM BOARD Step 2: Place the drawer bottom board down HG01400-19 SCREW-PHP W 3.5MM X 15MM ZN (PRE-INSTALLED) into the drawer sides and drawer rear. -
Page 6: Drawer Front
Step 7: Align and insert the four screws through the drawer bottom into the drawer rear. Step 8: Just start the screws for now, using the 2.5mm hex driver (provided). Page 6 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions... - Page 7 Section 3: Drawer Bottom and Front Assembly - continued Step 9: Align and insert the two corner screws ITEM PART # DESCRIPTION (item 1) through the drawer bottom and HG01400-16 SCREW-M4 X 12MM SKB ZN into the drawer side at the front and rear. NOTE: Do not insert screws into the center two holes on the drawer bottom and sides at this time.
-
Page 8: Hg01405-07 Brace Drawer Bottom
Fold each tape end out to the side, about 1 inch at 45°. Page 8 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions... - Page 9 Section 5: Tightening Drawer Screws Step 1: Set the drawer down on its bottom, so you Step 5: Repeat Step 4 for the front drawer can easily see the screws in the drawer bottom screws. bottom. Step 6: Tighten the two screws with nuts, firmly Step 2: Push the side of the drawer in towards holding the drawer side to the drawer back, the drawer bottom to get it as straight and...
- Page 10 (provided). on the drawer brace. Drawer Front Tighten the two brace screws on each side of the drawer. Screws on inside of drawer shown above. Drawer Back Page 10 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions...
-
Page 11: Drawer Slide-Single Action
Section 7: Drawer Slides to Bracket Assembly NOTE: The drawer can be mounted to ITEM PART # DESCRIPTION open either from the front or the rear of HG01400-01 BRACKET SHORT (Normal depth frames) the frame. HG01400-10 DRAWER SLIDE- SINGLE ACTION HG01400-18 SCREW-M4 X 6MM SKB ZN Step 1: Determine the direction of the drawer... -
Page 12: Qm10959 Screw-M8 X 20 Flgd Skb Zn
Step 3: Center the bracket left to right on the screws and fully tighten the screws with the 5mm L hex tool (item 2) provided. Page 12 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions... - Page 13 Section 9: Right Bracket to Frame Assembly Step 1: Align the right bracket to the underside of ITEM PART # DESCRIPTION the frame. QM10959 SCREW-M8 X 20 FLGD SKB ZN Step 2: Insert two large M8 X 20 flanged screws (item 1) through the bracket and up into the threaded holes on the bottom of the table top.
- Page 14 If it does bind, loosen the two screws that were tightened in step 7, and repeat step 7 to adjust tightness until drawer operates smoothly. Page 14 My Secret Drawer for HQ Little Foot Frame - Assembly Instructions...
-
Page 15: Screw-Php W 3.5 X 15Mm Zn
Section 11: Drawer Side Face Assembly  IMPORTANT: The drawer side faces cover ITEM PART # DESCRIPTION the drawer mounting bracket. Because of HG01400-08 DRAWER SIDE FACE this they are installed last, after alignment HG 01400-19 SCREW-PHP W 3.5 X 15MM ZN adjustments are made. - Page 16 Section 12: Side Face Alignment Step 1: Align the side drawer face to have about 1/8" gap between it and the large drawer front. Fully tighten the three wood screws with a #2 Phillips screwdriver (not provided). Step 2: Repeat Step 1 on the other side face. www.HandiQuilter.com 1-877-MY-QUILT (697-8458)
