Manual
for
Shipantennas
AV 14N
AV 15N
AV 16N
The ship antennas AV 14 to 16N are designed to receive radio and TV
transmissions into I, II, II, IV, and V band.
AV 15 and 16N models can also receive signal from the LMK band.
Due to the special design to receive signals from all directions and its stable
construction against the seawater, these antennas are the best solution for ships.
The antenna is full filled with foam and the mounting construction is made with
glass fibre and stainless steel screws.
In order to guarantee a high watertightness, the antenna is connected with a
coaxial cable that can not be changed.
The antenna have an special preamplifier with a low noise factor, that is feeded
by a main amplifier (for example LBS22-12P).
The amplifier allows to supply 2 lines.
There are two operating voltages: 220 / 110 VAC or 24 / 12 VDC.
1
© FTEmaximal
Advertisement
Table of Contents
Summary of Contents for FTE Maximal AV 15N
- Page 1 Manual Shipantennas AV 14N AV 15N AV 16N The ship antennas AV 14 to 16N are designed to receive radio and TV transmissions into I, II, II, IV, and V band. AV 15 and 16N models can also receive signal from the LMK band.
-
Page 2: Table Of Contents
Index Seite Safety Instructions Important notes for your safety Parts included Is your kit complete? Technical features Specifications Accessories What accessories do you need? Mounting The correct place for mount Mount the antenna on the top of a mast It depends on the combination Coaxial cable from antenna Connect the amplifier ©... -
Page 3: Important Notes For Your Safety
Important notes for your safety Important Notes The antenna must be installed according to the instructions manual and taking all necessary cautions. If these conditions are not followed the manufacturers warranty will be limited or void. Please take all necessary safety steps when working with equipment that is connected to an electric power source. -
Page 4: Parts Included
Parts included Is your Kit complete? Please check your box to ensure that you have all necessary parts: ☺ Antenna with 20m of coaxial cable ☺ Amplifier: AV 14N / 15N = LBS 22-12P ☺ Amplifier: AV 16N = LBS 30-12P ☺... -
Page 5: Technical Features
BI / FM / BIII / BIV / BV Gain (dB): Output level (dBµV): 2x109 Noise (dB): Reception angle: 360° AV 15N Band: LMK / BI / FM / BIII / BIV / BV Gain LMK (dB): Gain VHF / UHF (dB): Output level (dBµV): 2x109... -
Page 6: Accessories
Accessories What accessories are needed? To mount an antenna system you may need these accessories: ☺ Line amplifier: LBA 42R11 ☺ Splitter series TER: 2, 3, 4, 6 or 8 outputs ☺ Tab series AT: 1, 2, 4, 6, or 8 outputs Available attenuations: 8, 10, 12, 15, 20 or 25dB ☺... -
Page 7: Mounting
Mounting The correct place for mount The antenna have to be mounted on the top of the mast, because it improves the signal reception and minimizes reflections from the ship. To reduce interferences generated by a ship radio, mount the antenna as far as you can from it. - Page 8 Mounting 1. Pass the coaxial cable trough the mast. 2. Place the antenna over the top of the mast. 3. Fix the 3 Allen screws with the included Allen key. 4. Hold on the screws with a spanner or similar. ©...
-
Page 9: It Depends On The Combination
It depends on the combination Coaxial cable from antenna Connect the coaxial cable of the antenna to the amplifier. The minimum diameter of this cable must be 7mm. You can not use normal staples to fix the cable to the wall, if they press it. You can cut the coaxial cable to make it shorter, but remember that it is fixed inside the antenna. -
Page 10: Connect The Amplifier
It depends on the combination Connecting the amplifier CAUTION ! Connect the amplifier to the power source, when you have made all the connections and selected the correct feeding voltage. You have 2 possibilities for feeding the amplifier: 1. You can feed the amplifier with the built-in power supply. - Page 11 It depends on the combination Connecting the amplifier to the antenna The coaxial cable coming from the antenna will be connected through the connector IN. The distribution network will be connected trough OUT outputs. Both output are equivalents. © FTEmaximal...
