Summary of Contents for Steriline RA-V4
- Page 1 ROTARY WASHING MACHINE MECHANICAL & MAINTENANCE MANUAL OTARY ASHING ACHINE ACHINE RA-V4 ACHINE ODEL 15499LV ERIAL 2016 Intarcia - USA - USTOMER Via Tentorio 30, 22100 -COMO- ITALY TERILINE Ph. +39.031592064...
-
Page 3: Table Of Contents
T E P O N T R O L ................. 15 T A R T ROTARY WASHING MACHINE MODEL RA-V4 ..........16 ..............16 A S H E R D E S C R I P T I O N ................ 17 A S H I N G C Y C L E 3.2.1... - Page 4 SPARE PARTS ..................... 65 ........65 O M M E R C I A L O M PO N E N T S P A R E A R T S 15499LVMA01-1 - Pg.4 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual...
- Page 5 9.2.8.3 External nozzles ........................ 75 9.2.9 Drying station ......................76 ............... 77 N D I C A T I O N F O R R D E R ATTACHMENTS ....................78 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.5 manual...
-
Page 7: Performances
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL PERFORMANCES The Rotary Washing Machine model RA-V4 is designed to handle glass vials having the following dimensions: Diameter Height Output Container type Format Mark [mm] [mm] [v/h] 15ml 26,75 57,00 1500 The washer has pincers to treat vials. -
Page 8: Installation
Describe damages as accurately as possible. By means of the forwarding documents, check the presence of all parts. In the event that anything is missing, report this to Steriline S.r.l. within 5 working days after receipt. 2.1.1 Technical data Also see Control System Manual (Ref. 15499QE3MA01). -
Page 9: Internal Transport
Read carefully the instructions and the signs on the equipment shipping box/crate. (NOTE: Do not expose the equipment to significant shocks or vibrations.) CENTER OF FRAGILE BALANCE KEEP DRY OFF BALANCE SLING HERE THIS END UP DO NOT USE HOOK 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.9 manual... -
Page 10: Crated Machine
Using a fork lift, raise the machine as little as possible and tilt the forklift beam to support the machine against it. Secure the machine against the forklift beam by means of a safety strap for safe transport. 15499LVMA01-1 - Pg.10 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 11: R E M O V E P A C K A G I N G Pallet
Use a 10 mm wrench to remove the box panels that are bolted together. After uncrating the equipment, compare the actual contents of the box with the packing list or forwarding documents. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.11 manual... -
Page 12: S T O R A G E Environment
Machines, shipped in seaworthy packaging, should be stored in a dry (unheated) place since protection against condense was provided during packaging. When machines must be kept in store unexpectedly for a longer period of time, consult Steriline s.r.l. for specific measures. -
Page 13: Ositioning
Verify that each feet supports the frame of the machine! Important Verify by means of a spirit level that the machine is positioned horizontally! Important 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.13 manual... -
Page 14: Utilities Connections
2.6.2 Electrical connection The electric connection is made between the electrical cabinet and the electrical box on the side of the machine. For detailed information refer to the Control System Manual 15499QE3MA01. 15499LVMA01-1 - Pg.14 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 15: Step Control
Before starting the first setting up of the machine, control the following items: • all the utilities are correctly connected and the fluids pressures are correctly set • the filters are correctly installed • run the machine with the washing cycle operating 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.15 manual... -
Page 16: Rotary Washing Machine Model Ra-V4
ANUAL ROTARY WASHING MACHINE MODEL RA-V4 The RA-V4 washing machine is designed to perform the chemical, particulate and bacteriological cleaning of glass vials by means of series of injections of water for injection (W.F.I.) and compressed air (C.A.) on the internal and external surfaces of the vials. -
Page 17: Washing Cycle
Injection of W.F.I. Station 5: Injection of C.A. Station 6: Injection of W.F.I. Station 7: Injection of C.A. / Blowing of C.A. over the vials Station 8: Unloading of vials from the pincers 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.17 manual... -
Page 18: Pre-Flushing
Pressure transmitter for internal water spraying flow control PT55 Pneumatic membrane valve KVA50 (KJA50 actuated) for drying the pipes W.F.I. manual sampling valve KVD50 Pipe fittings are tri-clamp type and designed respecting the 3D rule. 15499LVMA01-1 - Pg.18 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 19: P R O T E C T I O N H O O D Draining
3.4.2 Drying Membrane valves feed compressed sterile air into the RW and WFI pipelines in order to dry them (refer above to valves listed as KVAnn. The valves are automatically actuated (KJAnn). 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.19... -
Page 20: Format Change
In case of future implementation of different vial sizes, the Format Change Parts listed in chapter 4.1 must be equipped and the Washer Adjustable Parts listed in Important chapter 4.2 must be regulated accordingly. 15499LVMA01-1 - Pg.20 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 21: F Ormat Change Part
– Pincers jaws – Unloading station guide – Outfeed guides All size change parts are marked to be identified. For the Mechanical size change refer to the Size Change Table (ref. 15499LVSP19). 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.21 manual... -
Page 22: F O R M A T C H A N G E P A R T S Infeed Guides
The infeed guide drives the vials one by one towards the washer loading station and it is univocally marked with the vials format to be identified. The picture below shows where the operator has to unscrew and fasten the handles to replace the infeed guide: 15499LVMA01-1 - Pg.22 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 23: Loading Cylinder Contrast
The loading cylinder is univocally marked with the vials format to be identified. The picture below shows where the operator has to unscrew and fasten the handles to remove the loading cylinder contrast: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.23... -
Page 24: Loading Cylinder Guide
The loading cylinder guide is univocally marked with the vials format to be identified. The picture below shows where the operator has to unscrew and fasten the handles to remove the loading cylinder guide: 15499LVMA01-1 - Pg.24 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 25: Loading Position Guide
4.1.4 Loading position guide The loading position guide is univocally marked with the vials format to be identified. The picture below shows the guide to be raised to remove it from its position: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.25... -
Page 26: Pincers Jaws
The pincers jaws are identified with the vials format name. The picture below shows where the operator has to unscrew and fasten the handles to remove the pincers jaws: 15499LVMA01-1 - Pg.26 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 27: Unloading Station Guides
Both guides have to be changed according to the glassware size to be performed. The picture below shows the guides, raise the guides to remove them from their position: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.27... -
Page 28: Outfeed Guides
The left and right guides drive the vials through tunnel conveyor belt. The pictures below show where the operator has to unscrew and fasten the handles to replace the outfeed guides: 15499LVMA01-1 - Pg.28 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 29: Needles
The needles are identified with the vials format name. The refer for the needles’ position is the grain: The picture below shows where the operator has to unscrew and fasten the handles to remove the needles: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.29 manual... - Page 30 On the washing machine the parts to be adjusted are: – Infeed minimum load photocell – Inlet lifting side guide cylinder – External water spraying nozzles – External air blowing nozzles – Tower/Needles height 15499LVMA01-1 - Pg.30 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual...
-
Page 31: A D J U S T A B L E P A R T S Infeed Minimum Load
At the machine infeed, the minimum load photocell has to be manually adjusted. To adjust the photocell position the operator has to unscrew and fasten the handles indicated in the following picture. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.31... -
Page 32: Inlet Lifting Side Guide Cylinder
The cylinder position has to be adjusted according to the vials size to be performed. The picture below shows where the operator has to unscrew and fasten the handles to adjust the bar position or to remove the bars: 15499LVMA01-1 - Pg.32 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 33: External Water Spraying Nozzles Station 3
The external spraying water nozzles position has to be changed according to the glassware size to improve the external vials washing. The picture below shows where the operator has to unscrew and fasten the handles to adjust the external spraying water nozzles position: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.33 manual... -
Page 34: External Air Blowing Nozzles Station 7
For external blowing air nozzles height refer to the Size Change Table (Document no. 15499LVSP19). The picture below shows where the operator has to unscrew and fasten the handles to adjust the external blowing air nozzles position: 15499LVMA01-1 - Pg.34 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 35: Tower/Needles Height
The correct value for the vials performed are stored in the respective recipe (Ref to the Size Change Table 15499LVSP19). The picture below shows where the operator has to work to modify the turret and needles height: 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.35... -
Page 36: General Instruction
Do not store or take any food in the vicinity of the plant Do not smoke LEANING PRIOR TO START Before starting up the machine, it must be thoroughly cleaned to meet pharmaceutical aseptic standards. 15499LVMA01-1 - Pg.36 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 37: Size Change Parts Cleaning
The autoclave has an acceptable range from the set point of the sterilization temperature: take care that the sterilization Important temperature plus this range does not exceed the melting temperature indicated above! 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.37 manual... -
Page 38: General
Avoid using compressed air; that way that no contamination is blown into guides, etc. In the event that compressed air is used, ensure that nobody can be Important injured by splinters of glass lying around (i.e. if there are broken vials). 15499LVMA01-1 - Pg.38 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 39: Batteries
Before you throw away devices which cannot be repaired, please remove batteries. 5.5.2 Lubricants Lubricants which cannot be used any more should not be thrown into the dustbin or waste water. Please bring these to the special waste disposal points. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.39 manual... -
Page 40: Instructions For Use Of Lubricants
Use skin protecting media when working and afterwards apply protective cream. Lubricants normally contain contaminating ingredients. Therefore they should not be allowed to get into the ground, water or drain channels. 15499LVMA01-1 - Pg.40 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 41: Alves
Remove the below red indicated clamp and then the below green indicated labor cover. Detach the below profibus cable and the C.A. tube. Remove the turret cover and then act on the SMC valves placed inside the turret. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.41... -
Page 42: Generall
If it is not possible. Please avoid that the different oil get mixed. Not additional devices, installed on the machine, are filled by lubricant. Not additional devices require lubrication during the machine life. 15499LVMA01-1 - Pg.42 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 43: Recommended Lubricants
Bought assemblies from other suppliers (for example motors, indexer etc.) have to be maintained according to their regulations. You will find the corresponding operating instructions or data sheets in a separate file (Ref. 15499LVMA10). 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.43 manual... -
Page 44: Oil Lubrication
INTERNAL REDUCTION GEAR OMALA S4 WE320 Shell INTERNAL INTERMITTER TIVELA S320 6.3.2 Grease Lubrication PPLICATION ANUFACTURER YPE OF GREASE INTERMITTER Molikote Longterm W2 PPLICATION ANUFACTURER YPE OF GREASE PINCER Klüber Klüberpaste UH1 96-402 15499LVMA01-1 - Pg.44 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 45: Inspection
The inspection protocol following hereafter can be used to document inspections carried out by the customer’s maintenance staff. The parts of the machines to be inspected are listed in the following chapters. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.45... - Page 46 OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL Inspection protocol ACHINE TYPE ACHINE ODEL ERIAL Inspection carried out on ......according to general inspection plan. Remarks Inspected by Company/Dept. Date Signature 15499LVMA01-1 - Pg.46 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual...
-
Page 47: Pneumatic Cylinder
Quarterly Corrosion Quarterly Damage Quarterly Damage Quarterly Deformation Quarterly Fixing device Quarterly Functioning Quarterly Noise (smoothness of running) Quarterly Pollution Quarterly Pressure Quarterly Striae / scratches Quarterly Temperature Quarterly Wear Quarterly 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.47 manual... -
Page 48: Pneumatic Valves
ANUAL 7.2.2 Pneumatic valves State to be checked Inspection interval Adjustment Quarterly Completeness Quarterly Consistency Quarterly Damage Quarterly Fixing device Quarterly Functioning Quarterly Pollution Quarterly Pressure Quarterly Rupture Quarterly Temperature Quarterly 15499LVMA01-1 - Pg.48 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 49: Gear
Half-yearly Torque transmission Half-yearly Volume and state Half-yearly Balance error Yearly Corrosion Yearly Cracks Yearly Damage Yearly Fixing device Yearly Non-smooth running Yearly Pollution Yearly Slippage Yearly Vibrations Yearly Wear Yearly 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.49 manual... -
Page 50: Chain
State to be checked Inspection interval Adjustment Quarterly Cracks Quarterly Damage Quarterly Extension Quarterly Functioning Quarterly Noise (smoothness of running) Quarterly Non-smooth running Quarterly Vibrations Quarterly Wear Quarterly Corrosion Yearly Pollution Yearly 15499LVMA01-1 - Pg.50 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 51: Chain Wheel
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 7.2.5 Chain wheel State to be checked Inspection interval Corrosion Yearly Deformation Yearly Pollution Yearly 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.51 manual... -
Page 52: Chain Joint
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 7.2.6 Chain joint State to be checked Inspection interval Completeness Quarterly Deformation Quarterly Extension Quarterly Rupture Quarterly Corrosion Yearly Pollution Yearly 15499LVMA01-1 - Pg.52 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 53: Ball Bearing
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 7.2.7 Ball bearing State to be checked Inspection interval Balance error Yearly Function Yearly Noise (smoothness of running) Yearly Non-smooth running Yearly 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.53 manual... -
Page 54: Pillow Block
7.2.8 Pillow block State to be checked Inspection interval Cracks Half-yearly Noise (smoothness of running) Half-yearly Play Half-yearly Rupture Half-yearly Corrosion Yearly Damage Yearly Fixing device Yearly Pollution Yearly Wear Yearly 15499LVMA01-1 - Pg.54 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 55: Motors
ACHINE & M ECHANICAL AINTENANCE ANUAL 7.2.9 Motors State to be checked Inspection interval Noise (smoothness of running) Half-yearly Temperature Half-yearly Balance error Yearly Fixing device Yearly Pollution Yearly Vibrations Yearly 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.55 manual... -
Page 56: Conveyor Belt
7.2.10 Conveyor belt State to be controlled Inspection interval Pollution Daily Adjustment Half-yearly Completeness Half-yearly Cracks Half-yearly Damage Half-yearly Deformation Half-yearly Functioning Half-yearly Noise (smoothness of running) Half-yearly Rupture Half-yearly Wear Half-yearly 15499LVMA01-1 - Pg.56 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 57: Emergency Stop Device
15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.57 manual... -
Page 58: Maintenance
When using cleansing agents, it has to make sure that components made of metal, rubber or plastic material are not attacked. Caution: Do not wash down the machine with a water hose ! 15499LVMA01-1 - Pg.58 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 59: Weekly
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 8.1.2 Weekly Group Maintenance Sensors Remove dust from sensors with a soft and dry cloth 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.59 manual... -
Page 60: Monthly
Cleaning the filter of the electrical cabinet ventilator Electrical cabinet - remove the covering outside - remove the filter mat and clean it dry or clean it in soap water then dry the mat 15499LVMA01-1 - Pg.60 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 61: Quarterly
Grease the roller chain(s). ------------------------------------- Lubricants Adhesive lubricants, for example - Castrol (Spheerol AP 2) - Mobil (Mobiltac A / Mobiltac B / Mobiltac E) - Shell (Alvania grease R 2) 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.61 manual... -
Page 62: Half-Yearly
Boxes located in the Electrical Cabinet. Conveyor belt Check the tension of the conveyor belt. If the belt is too loose, increase their tension by means of the tension adjustment system. 15499LVMA01-1 - Pg.62 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 63: Other Maintenance Hints
Parts by sub-suppliers: The following listing is not by all means complete! Please absolutely read as well the corresponding descriptions of the manufacturers in the Other Suppliers Technical Data included in separated file. 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.63 manual... - Page 64 Pay particular attention to: - unusual noises - leakage or falling oil level - over-elevated temperatures - loose securing elements Should problems occur, switch the machine or plant off immediately and rectify the fault. 15499LVMA01-1 - Pg.64 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual...
-
Page 65: Spare Parts
OMMERCIAL OMPONENTS PARE ARTS The most important commercial components are listed in the components list: Washer Components List: RA-V4 (Ref.: 15499LVSP14) ECHANICAL OMPONENTS PARE ARTS To identify the individual mechanical components refer to picture and table listed in the chapters below. -
Page 66: Manual
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.1 Infeed guide Part-no Description Quantity 49817 Infeed guide for vials size F0 No. 01 Material: Polystone 15499LVMA01-1 - Pg.66 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 67: Loading Cylinder Contrast
9.2.2 Loading cylinder contrast Part-no Description Quantity 34586 Loading cylinder contrast for vials size F0 No. 01 Material: Polystone 22198 M5 White Hand screw Lenght 32mm for vials size F0 No. 01 Material: Polystone 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.67 manual... -
Page 68: Loading Cylinder Guide
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.3 Loading cylinder guide Part-no Description Quantity 49815 Loading cylinder guide for vials size F0 No. 01 Material: Polystone 15499LVMA01-1 - Pg.68 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 69: Loading Position Guide
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.4 Loading position guide Part-no Description Quantity 49818 Loading position guide for vials size F0 No. 01 Material: Polystone 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.69 manual... -
Page 70: Pincers
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.5 Pincers Part-no Description Quantity 1006144 Pincers for vials size F0 No. 16 Material: Pom C 15499LVMA01-1 - Pg.70 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 71: Unloading Station Guides
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.6 Unloading station guides Part-no Description Quantity 49819 Unloading station guides for vials size F0 No. 01 Set Material: Polystone 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.71 manual... -
Page 72: Outfeed Guides
OTARY ASHING ACHINE & M ECHANICAL AINTENANCE ANUAL 9.2.7 Outfeed guides Part-no Description Quantity 1006133 Outfeed guides for vials size F0 No. 01 Set Material: Polystone 15499LVMA01-1 - Pg.72 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 73: Washing Station
49742 Spraying/blowing needles main distributor for vials size F0 No. 02 Material: Stainless steel 49841 Internal spraying/blowing needles distributor with top entry for No. 06 vials size F0 Material: Stainless steel 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.73 manual... -
Page 74: Needles
Internal spraying needles for water, for vials size F0 No. 09 Ltot=70 Øe=3mm Øi=2mm. Material: Stainless steel 18825 Internal blowing needles for air, for vials size F0 No. 09 Ltot=70 Øe=2,5mm Øi=1,5mm. Material: Stainless steel 15499LVMA01-1 - Pg.74 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 75: External Nozzles
Description Quantity 5311 External spraying nozzles for vials size F0 No. 03 Material: Stainless steel 61604 External spraying nozzles distributor dim.170x47mm - th.20mm No. 01 for vials size F0 Material: Polystone 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.75 manual... -
Page 76: Drying Station
ANUAL 9.2.9 Drying station Part-no Description Quantity 22118 External blowing nozzles for vials size F0. No. 01 Composed by no. 09 needles Ltot=46mm Øe=2,5mm Øi=1,5mm, part no. 17621 Material: Stainless steel 15499LVMA01-1 - Pg.76 mechanical maintenance 1.0 (23.01.2017) RA-V4 manual... -
Page 77: Indication For Order
Serial Number Please refer the cover page Year Please refer the cover page Part No. Please refer to RA-V4 Rotary Washing Machine Components List and Chapter 9.2 Tag. No. Please refer to RA-V4 Rotary Washing Machine Components List and P&ID drawings... -
Page 78: Attachments
• ROTARY WASHING MACHINE PRESSURE REDUCERS PARAMETERS SETTING (Ref. 15499LVSP26) • ROTARY WASHING MACHINE CE - CONFORMITY DECLARATION (Ref. MOD0023) ROTARY WASHING MACHINE OTHER SUPPLIERS TECHNICAL DATA • (Separate folder Ref. 15499LVMA10) 15499LVMA01-1 - RA-V4 1.0 (23.01.2017) mechanical maintenance Pg.78 manual...
