CONTENTS Feature (SK-P500 AI SERIES) Warning & Caution Warning Caution Configuration Accessories Wall mount (How to install 1) Wail mount (How to install 2) Ceiling mount (How to install 1) Ceiling mount (How to install 2) Function (SK-P500 AI SERIES) -
Page 3: Feature (Sk-P500 Ai Series)
FEATURE (SK-P500 AI) 1. Long v is ib le r a n g e a t night. (50m Max. indoors, 40m Max. outdoors) 2. You can select the level of LED ON/OFF and f i lt e r change according to Lux as follow. - Page 4 DSP of SONY. 16. You can adjust the level of IR LED according to the circumstances, 17. A heater enables the camera to keep the proper operation at low temperature. -Heater ON/OFF temperature. 1st Heater 2nd Heater *ON/OFF point of heater is subject to environment. 18.
-
Page 5: Warning & Caution
WARNING & CAUTION - Follow the instructions - Please follow below instructions for safe use. Information Read this user guide c a r e f u l l y before any in s t a lla tio n for safe o pe r a t io n of product. -
Page 6: Warning
WARNING - Please study the instruction manual be fore your applications and keep it for your fut ure reference. - Do not flash LED light directly on the eyes when LED’s are on. - Do not install the camera on a unstable surface. -
Page 7: Caution
CAUTION - Do not adhere dangerous articles to the camera - Do not leave the unit along an unstable stand or table. - DC power cable or Video cable should be always loose. Do not keep the cables tight or twisted. - Use the camera unit within given temperature and e l e c t r i c i t y limit. - Page 8 1) When power connector or video connector is broken. 2) When body is broken and dropped. 3) When it is not operating though it is set correctly by the manual. If you meet any strange cases please call the shop where you purchased.
-
Page 9: Configuration
CONFIGURATION... -
Page 10: Accessories
ACCESSORIES... -
Page 11: Wall Mount (How To Install 1)
WALL MOUNT (How to install 1) 1. Make a hole of 030mm in diameter for passing cable. 2. Using the mount hole plate, drill four holes on the wall. 3. Insert the anchors. 4. Fix the screws. - Page 12 WALL MOUNT (How to install 2) 1. Adjust horizontal angle. 1) Loosen a bolt to adjust horizontal angle of the camera. 2) Use the WRENCH to tighten a bolt after adjusting the camera.
-
Page 13: Ceiling Mount (How To Install 1)
CEILING MOUNT (How to install 1) 1. Make a hole of 030mm in diameter for passing cable. 2. Using the mount hole plate, drill four holes on the ceiling. 3. Insert 1he anchors. 4. Fix the screws. -
Page 14: Ceiling Mount (How To Install 2)
CEILING MOUNT (How to install 2) 1. Adjust horizontal angle. 1) Loosen a bolt to adjust horizontal angle of the camera. 2) Use the WRENCH to tighten a bolt after adjusting the camera. * Twist a bolt counterclockwise once or twice. * Adjust horizontal angle. - Page 15 CEILING MOUNT (How to install 2) 2. Adjust vertical angle 1) Loosen a bolt to adjust vertical angle of the camera, 2) Use the WRENCH to tighten a bolt after adjusting the camera. *Twist a bolt counterclockwise once or twice. *Adjust vertical angle.
-
Page 16: Function (Sk-P500 Ai Series)
FUNCTION (SK-P500 AI) - Page 17 FUNCTION(SK-P500 AI) • Camera function setting Factory Setting 1. 12V DC Input * Display for factory set will last for 5 sec * How to set OSD menu - ENTER: Move to next menu - LEFT: Move to left - RIGHT: Move to right 2.
-
Page 18: Dimension (Wall Mount)
DIMENSION (Wall mount) -
Page 19: Dimension (Ceiling Mount)
DIMENSION (Ceiling mount) -
Page 20: Specification (Sk-P500 Ai Series)
SPECIFICATION (SK-P500 AI SERIES) MODEL NO SK-P500 AI SK-P500 XAI Type Day & Night Color Camera (With IR Illuminator) Image Sensor 1/3" COLOR SONY SUPER HAD CCD 1/3" COLOR SONY EX-view HAD CCD 768 (H) x 494(V) PIXEL (NTSC) Effective Pixel 752(H) x 582(V) PIXEL (PAL) 6.35(H) x 7.4(V) (NTSC) -
Page 21: Warranty Card
WARRANTY CARD * This product will be under warranty for one year after the date of purchase * The history of after-sale service... - Page 22 Memo...
- Page 23 Memo...
- Page 24 VEOS LTD ROSITZA STR. 13, SOFIA, BULGARIA TEL + 359 2 987 26 65 FAX +0359 2 987 26 84 E-MAIL: veos-bg@datacom.bg URL: www.veos.bg...
