WELLBEING SERIES
Installation & Maintenance Instructions
WALL TOP ASSEMBLY
DUAL MIXER /
SEQUENTIAL BASIN MIXER
I00077_Oct 17
Call 1300 369 273
www.enware.com.au
Enware Australia Pty Limited
9 Endeavour Rd Caringbah NSW 2229 Australia
Ph: +61 2 8556 4000 Fax: +61 2 8556 4055
NOTE: THIS DOCUMENT IS TO BE LEFT ONSITE WITH FACILITY MANAGER AFTER INSTALLATION
SEQUENTIAL SHOWER MIXER
BASIN / SINK SET
Advertisement
Table of Contents
Related Manuals for enware WELLBEING Series
Summary of Contents for enware WELLBEING Series
- Page 1 NOTE: THIS DOCUMENT IS TO BE LEFT ONSITE WITH FACILITY MANAGER AFTER INSTALLATION I00077_Oct 17 Call 1300 369 273 www.enware.com.au Enware Australia Pty Limited 9 Endeavour Rd Caringbah NSW 2229 Australia Ph: +61 2 8556 4000 Fax: +61 2 8556 4055...
-
Page 3: Technical Data
5 °C – 85 °C * For use with potable water only. compliance before installation *Enware products are to be installed in Before Proceeding With Installation accordance with the Plumbing Code of Australia • Ensure all operating & dimensional and AS/NZS3500. -
Page 4: Installation
Wall Depth Adjustment RECESS BODY MAX 18 mm MIN 0 mm G5/8" (BSP) * For deeper wall recess use extended SBA (Max. 33 mm) OPEN OPEN CLOSED CLOSED LTC anti-clockwise to close | RTC clockwise to close Call 1300 369 273 www.enware.com.au... - Page 5 MAX 18Nm MAX 30Nm www.enware.com.au Call 1300 369 273...
- Page 6 SEQUENTIAL SHOWER MIXER installation WBSHSQ65 G1/2" (BSP) FEMALE OUTLET 25 ADJ. 105 max. Ø75 FULL WARM FULL COLD CLOSED Call 1300 369 273 www.enware.com.au...
- Page 7 NOGGING POSITION MIN 50mm MAX 75mm 1000mm FROM FLOOR fix shower into position OFF POSITION www.enware.com.au Call 1300 369 273...
- Page 8 DUAL MIXER SEQUENTIAL BASIN MIXER installation WBDMCD65-165 | WBDSQ65-165 Ø55 Ø55 Ø55 Ø55 CLOSED CLOSED FULL COLD FULL WARM OPEN 165 Spout 165 220 Spout 220 Call 1300 369 273 www.enware.com.au...
- Page 9 Cut tap hole on bench, with clearance around tap hole for spacer stabilizer BENCHTOP CUTOUT Cut tap hole on bench, with clearance around tap hole for spacer stabilizer spacer stabilizer must be used for bench thickness less than 10mm SPACER STABILIZER www.enware.com.au Call 1300 369 273...
- Page 10 OPEN 150 - 300 CLOSED CLOSED (CUT TO SUIT ON SITE) G1/2" (BSP) WITH OLIVE COMPRESSION FITTING cut holes to suit outlet and handle positions Ø22 Ø33 1 x spout 2 x body cutout cutout Call 1300 369 273 www.enware.com.au...
- Page 11 THREAD SEALANT www.enware.com.au Call 1300 369 273...
- Page 12 SBA Locknut Spline Adaptor Octagon Insert Handle Base Dome Handle 65mm Insert O-Ring Indicator –Red Washer – S/S Friction Bush Washer – Nylon Indicator – Blue Screw M5x20 S/S Indicator - Yellow SBA Spindle Q/Turn 80mm Call 1300 369 273 www.enware.com.au...
- Page 13 Washer – S/S Sequential Mixer Cartridge - 180° Screw M5 x 35 S/S Cartridge Retaining Nut Handle 65mm Insert Spline Adaptor Octagon Insert Indicator – Grey Handle Base Dress Ring – Shower Washer - Nylon Colour Indicators www.enware.com.au Call 1300 369 273...
-
Page 14: Dual Mixer
Washer – Nylon Indicator - Yellow Screw – M5x20 S/S Hose 350mm Red Spline Adaptor Octagon Insert Fixing Nut M6x42 SBA Spindle Q/Turn 55mm LTC Mixer Plastic Spacer Stabilizer Dress Ring – Hob Mixer Base Call 1300 369 273 www.enware.com.au... - Page 15 Cartridge Retaining Nut Indicator – Grey Spline Adaptor Octagon Insert Screw M5x35 Colour Indicators Mixer Body Fixing Bolt M6x80 Handle Base Hose 350mmm Red Washer – Nylon Fixing Nut M6x42 Washer – S/S Mixer Plastic Spacer Stabilizer www.enware.com.au Call 1300 369 273...
- Page 16 Grub Screw M5x12 Handle Base Friction Bush Handle 65mm Insert SBA Spindle Q/Turn 55mm Indicator – Red SBA Locknut Indicator – Blue Red Fibre Washer Indicator – Yellow Spline Adaptor Octagon Insert Basin / Sink Tee Kit Call 1300 369 273 www.enware.com.au...
-
Page 17: Troubleshooting
Tap bodies are set too far into Use extended recess spindle thread of SBA the wall (SBA only) Wall flange does not screw Tap bodies are set too far out Use a trouble dome or flange down onto wall surface extender www.enware.com.au Call 1300 369 273... - Page 18 Call 1300 369 273 www.enware.com.au...
-
Page 19: Service And Maintenance
Spout aerator should be checked periodically for Enware Product should be cleaned with a soft damp debris. Use Aerator Key to unscrew spout aerator. If cloth using only mild liquid detergent or soap and aerator doesn’t come out completely, turn tap on to water. -
Page 20: Spare Parts
SPARE PARTS PART ENWARE PRODUCT CODE Handle Assembly WB65 (Includes Blue, Red, Yellow colour indicators) Handle Colour Indicator Pack WBIND (Blue, Red, Yellow) Colour Indicator Pack WBSQIND (For Sequential Mixer) Grey handle indicator, 4 colour indicators for body Wall Top Assembly... - Page 21 SPARE PARTS PART ENWARE PRODUCT CODE Dress Ring – Hob Mount Spout WBBFLAN Dress Ring – Hob Mixer Base WBMIXFLAN Flange – Sequential Shower Mixer WBSQSHFLAN With colour indicators – Blue, Red, Yellow, Grey Flange – Wall Spout WBWFLAN Spout 165mm...
-
Page 22: Making A Claim
PRODUCT WARRANTY FOR AUSTRALIA Effective 1 September 2014 exceptions Enware Australia Pty Limited (ACN 003 988 314) (“we” or “us”) warrants that this product (also This warranty does not apply in respect of any referred to as “our goods”) will be free from all... - Page 23 Call 1300 369 273...
