MX86 QR Code Scanner User Manual

Beijing Microlight Internet Technology Co., Ltd.

July 5, 2017

Table of Contents

Need help?

Do you have a question about the MX86 and is the answer not in the manual?

Questions and answers

Summary of Contents for Microlight MX86

Page 1 MX86 QR Code Scanner User Manual Beijing Microlight Internet Technology Co., Ltd. July 5, 2017...
Page 2: Disclaimer
Disclaimer Before using the product, please read carefully all the contents of this MX86 Product User Manual (hereinafter referred to as “Manual”) to ensure the safe and effective use of the product. Do not disassemble the product or tear off the seal on the product.
Page 3: Table Of Contents
Table of Contents Disclaimer..........................2 Copyright Notice........................6 Preface............................7 Product Introduction......................7 Product Features........................7 Strong reading ability....................7  Paper code reading ability ..................7  High speed reading ....................8  Easy to use ........................ 8  Precautions..........................8 Chapter Ⅰ...
Page 4 RS485interface......................13  TTL interface......................14  Wiegand Interface ....................14  WIFI Interface......................14  Ethernet Interface ....................15  Chapter Ⅱ Wiring instructions....................16 Pin definitions........................16 USB/WIFI/Ethernet Wiring....................18 RS232 WiringRS232 connection..................19 Wiegand/TTL/RS485/WIFI Wiring..................21 Chapter III Product Configuration..................22 Run Configuration Tool.......................
Page 5: Copyright Notice
Copyright Notice All information contained in this manual is protected by copyright, and Beijing Microlight Internet Technology Co., Ltd. reserves all rights. Without the written permission of our company, any unit or individual shall bear legal liability for taking any form of excerpt, coping any or all of the contents of this document or selling or using the product bundled with other products in any way or for any reason.
Page 6: Preface
Preface Product Introduction Thanks for using the MX86 series of scanners provided by Microlight Internet Ltd. This product can realize QR code identification and RF card reading. Please read the user manual carefully before use, you will appreciate its perfect function and simple operation method.
Page 7: High Speed Reading
 H i g h s p e e d r e a d i n g Different mobile phone LCD screens generally have different contrast, color, and degree of reflection, which can be read as long as the code system is within the reading window. ...
Page 8: Chapter Ⅰ Product Parameters
Chapter Ⅰ Product Parameters Apparent parameters Figure 1-1 Vertical Vie www.vguang.cn...
Page 9: Reading Parameters
Figure 1-2 Side View Reading Parameters Reading Parameters of MX86 series QR code QR code: QR Code, Data Matrix, PDF417, etc. One-dimensional code：EAN-8,EAN-13,ISBN-10,ISBN-13, Identification code UPC-E,UPCA,CODE39,CODE93.CODE128 etc; All prints such as mobile phones, screens, and paper Decoding support 0mm-100mm Reading depth of field ≥5mil...
Page 10: Electrical Parameters
Reading parameters of MX86 series NFC Identification card Mifare_UltraLight、Mifare_One(S50)、 type Mifare_One(S70)、Mifare_Pro(X)、Mifare_DESFire RF operating 13.56MHZ frequency Effective operating <5cm distance 15 /s Reading rate Table 1-2 NFC reading parameters Note: The RF antenna is related to the environment. If there is metal around the product, the quality of swiping card will be affected.
Page 11: Interface Parameters
Table 1-3 Device Parameters Continued I n t e r f a c e p a r a m e t e r s  USB Parameters MX86 series USB interface parameters Wiring type USB Type-A to 5PIN 2.0mm terminal Support interface USB2.0 backward compatible, slave device...
Page 12: Rs232 Interface
 RS232 interface MX86 series RS232 interface parameters Wiring type DB9 to 6PIN 2.0mm terminal Support interface point-to-point Baud rate 300 bps to 460800bps, default 115200bps Interface voltage ±6V ±15kV Human Body Mode Protection standard ±15kV IEC61000-4-2 Air Discharge Mode ±8kV IEC61000-4-2 Contact Discharge Mode...
Page 13: Ttl Interface
Interface voltage 4.3V Protection standard ±15 kV HBM protection Table 1-8 Wiegand interface parameters  WIFI Interface MX86 series WIFI interface parameters 6PIN 2.0mm to 6PIN 2.0mm terminal USB Wiring type Type-A to 5PIN 2.0mm terminal Support interface TCP/HTTP Theoretical...
Page 14: Ethernet Interface
 Ethernet Interface MX86 series Ethernet interface parameters Wiring type USB Type-A to 5PIN 2.0mm terminal Support interface RJ45 Theoretical bandwidth 10/100Mbps adaptive Ethernet interface Protection standard 1.5KV electromagnetic isolation Network protocol Cache Send: 6K bytes, Receive: 4K bytes Connection...
Page 15: Chapter Ⅱ Wiring Instructions
Chapter Ⅱ Wiring instructions Pin definition MX86 outputs 5pin interfaces: Figure 2-1 5pin socket PIN# Signal Name Description GND_EARTH Shield ground, connect to USB shield Power ground DATA+ Data+ DATA- Data- USB power supply VUSB Output Table 2-1 5pin socket wire sequence...
Page 16 MX86 external output 6Pin interfaces: Figure 2-2 6pin socket PIN# Signal Name Description Serial logic level input INPUT Wiegand data 0 DATA0 OUTPUT OPEN OUTPUT Access control output Serial logic level output OUTPUT Wiegand data 1 DATA1 OUTPUT Power ground...
Page 17: Usb/Wifi/Ethernet Wiring
USB/WIFI/Ethernet Wiring Figure 2-3 USB interface cable Figure 2-4 2.0mm 5Pin plug Shielded USB-A wire 5Pin plug DATA+ DATA- VUSB Table 2-3 USB interface cables sequence www.vguang.cn...
Page 18: Rs232 Wiringrs232 Connection
RS232 wiring Figure 2-5 RS232 interface cable Figure 2-6 2.0mm 6Pin plug www.vguang.cn...
Page 19 2.0mm interface Empty pin Empty pin 232-TX 232-TX Table 2-4 RS232 interface cables sequence www.vguang.cn...
Page 20: Wiegand/Ttl/Rs485/Wifi Wiring
Wiegand/TTL/RS485/WIFI Wiring Figure 2-7 Wiegand/TTL/RS485/WIFI cable Figure 2-8 2.0mm 6Pin plug Pin No. Color Signal description Pin No. Color Signal description Purple RX/ DATA0/OPEN Yellow Brown RS485-A TX/ DATA1 Black Blue RS485-B Table 2-5 Wiegand/TTL/RS485/WIFI interface cables sequence www.vguang.cn...
Page 21: Chapter Iii Product Configuration
Chapter III Product Configuration Run Configuration Tool Run configuration tool: Double-click the MX86 configuration tool application. （1） Figure 3-1 Configuration tool icon Figure 3-2 Configuration tool interface Device Connection: Click the [Connect Device] button and the message ＂Device connection （2）...
Page 22 Figure 3-3 Normal mode Under development mode, can be configured as USB, serial protocol, communication protocols methods etc. choose according to your needs. Figure 3-4 Development mode (2) General configuration: Figure 3-5 General configuration options www.vguang.cn...
Page 23 Code selection: Changing the code system is available, the QR code (QR code) is checked by default. The  rest of the code system can be selected according to your needs. Output settings: Scan code prefix and suffix can be set; ...
Page 24 Wi-Fi output mode: Can be configured into four output methods, namely TCP, HTTP, TCP protocol and  HTTP protocol, in the protocol mode, the data transmission format will be in accordance with the Microlight wifi transmission protocol; Network transmission behavior: You can configure the feedback of transmission success and failure after ...
Page 25 Wired output mode: Can be configured into four output methods, namely TCP, HTTP, TCP protocol and  HTTP protocol, in the protocol mode, the data transmission format will be in accordance with the Microlight wifi transmission protocol; Network transmission behavior: You can configure the feedback of transmission success and failure after ...
Page 26: Chapter Ⅳ Common Faults And Troubleshooting Methods
Chapter Ⅳ Common Faults and Troubleshooting Methods After the Wiegand output is configured, the scan code has no output. When at Wiegand 34 output, the scanner’s QR code output only supports 6-10 characters output, so if the QR code information is less than 6 bits, complement 0 to the front bit to get 6 bits to generate output. In addition, the Wiegand output only supports pure digital output.
Page 27: Contact Information
Contact Information Company Name: Beijing Microlight Internet Technology Co., Ltd. Company Address: Room 4509~4522, China Meteorological Science and Technology Park, No.2, Zhenxing Road, Changping District, Beijing After-sales service: 010-56215600 Business Contact: South China+ Hong Kong, Macau, Taiwan+ Overseas Area: 18910502626...
Page 28: Version Information
Version Info. Date Version Change description First version 2017.07.05 1.00 Some changes were made on the basis of the first 2017.07.06 1.01 version The position of some content were adjusted and 2017.07.06 1.02 part of the data was changed Improvement and modifications 2017.07.27 1.03 Adding the content of default configuration...
