Fluke JackRapid Series Technical Data

JackRapid
Introducing the new JackRapid,
jack termination tool – the industry's
most innovative and time-saving
termination tool. This patented tool
seats and terminates all wires simul-
taneously, with one squeeze of
the ergonomic handle. Get accurate
terminations and clean, consistent
cuts every time.
Technical Data
Termination Tool
™
Reduces installation time
• Easy-to-use tool seats and cuts all
wires at once
• Increases productivity – install jacks
8 times faster
Accurate, clean and consistent
cuts and terminations
• Consistent terminations every time –
no more wasted jacks
• Built-in bed helps hold jack in place
Eliminates user fatigue
• Ergonomic handle
• Convenient, built-in stripper
Future proof
• Replaceable blade heads for use with multiple vendor jack types
Wall-friendly
• Unique design easily accommodates close-to-wall installations

Ordering Information

Item Model Name
3093687 JR-LEV-1
3093756 JR-LEV-1-H
3093808 JR-SYS-UNI-1
3093813 JR-SYS-UNI-1-H
3093693 JR-LEV-2
3093763 JR-LEV-2-H
3093700 JR-SYS-2
3093824 JR-SYS-2-H
3093721 JR-ORT-2
3093774 JR-ORT-2-H
3057463 JR-ERGOHANDLE
See how to terminate jacks 8 times faster
Description
JR-LEV-1, JackRapid Termination Tool
(for Leviton 41106, 41108, 5G108)
JR-LEV-1-H, JackRapid replacement blade head
(for Leviton 41106, 41108, 5G108)
JR-SYS-UNI-1, JackRapid Termination Tool
(for Systimax MPS100E, C5, M1BH and Uniprise UNJ600/500/300)
JR-SYS-UNI-1-H, JackRapid replacement blade head
(for Systimax MPS100E, C5, M1BH and Uniprise UNJ600/500/300)
JR-LEV-2, JackRapid Termination Tool
(for Leviton 61110, 5G110, 6110G)
JR-LEV-2-H, JackRapid replacement blade head
(for Leviton 61110, 5G110, 6110G)
JR-SYS-2, JackRapid Termination Tool
(for Systimax MGS400, MGS500, MFP420, MFP520)
JR-SYS-2-H, JackRapid replacement blade head
(for Systimax MGS400, MGS500, MFP420, MFP520)
JR-ORT-2, JackRapid Termination Tool
(for Ortronics TJ5E00, TJ600, TJ610)
JR-ORT-2-H, JackRapid replacement blade head
(for Ortronics TJ5E00, TJ600, TJ610)
JackRapid Ergonomic Handle
