DSE STORM 2000 User Manual

Rgb led strobe
Hide thumbs

Advertisement

Quick Links

Download this manual
STORM 2000 RGB LED STROBE
USER MANUAL
Please read the instructions carefully before use.

Advertisement

loading
Need help?

Need help?

Do you have a question about the STORM 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for DSE STORM 2000

  • Page 1 STORM 2000 RGB LED STROBE USER MANUAL Please read the instructions carefully before use.

  • Page 2: Table Of Contents

    6. Fixture Cleaning STATEMENT FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE INSTALLING AND POWERING YOUR STORM 2000 RGB LED STROBE. This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this manual.
  • Page 3 The power plug has to be accessible after installing the fixture. Do not overload wall outlets and extension cords as this can result in fire or electric shock. DO NOT allow anything to rest on the power cord. DO NOT locate this fixture where the cord may be damaged by persons walking on it.
  • Page 4 The fixture becomes very hot during operation. Allow the fixture to cool approximately 20 minutes prior to manipulate with it. Operate the fixture only after having familiarized with its functions. DO NOT permit operation by persons not qualified for operating the fixture. Most damages are the result of unprofessional operation.

  • Page 5: Technical Specifications

    2. Technical Specifications FEATURES • Super bright output via 1260 RGBW LEDs • Intense built-in strobe programs + random strobe • 2-segment pixel modes can safely be used as wash (about 400W) • Built-in over heat protection temperature sensor to extend the lamp life •...
  • Page 6 Master Dimmer (0-100%) Red segment Intensity (0-100%) Green segment Intensity (0-100%) Blue segment Intensity (0-100%) White segment Intensity (0-100%) Flash duration (0-full on) Strobe rate (0-30Hz) Built-In Effects Red1/Segment 1 Intensity (0-100%) Green1/Segment 2 Intensity (0-100%) Blue1/Segment 3 Intensity (0-100%) White1/Segment 4 Intensity (0-100%) Red2/Segment 5 Intensity (0-100%) Green2/Segment 6 Intensity (0-100%)

  • Page 7: How To Control The Unit

    3. How to Control the Unit Before replacing a fuse, disconnect power cord, always replace with the same type and rating of fuse. FUSE REPLACEMENT CAUTION! The Storm1000 utilizes a high-output switch-mode power supply with an internal fuse. Under normal operating conditions, the fuse should not require replacement.
  • Page 8 Cables must have a male XLR connector on one end and a female XLR Connector on the other end. A word on Termination: DMX is a resilient communication protocol, however errors still occasionally occur. Termination reduces signal errors, and therefore best practices include use of terminator in all circumstances.
  • Page 9 SETTING UP DMX CONTROL STEP 1: Connect the male connector of the DMX cable to the female connector (output) on the controller. STEP 2: Connect the female connector of the DMX cable to the first fixture’s male connector (input). Note: It doesn’t matter which fixture address is the first one connected. We recommend connecting the fixtures in terms of their proximity to the controller, rather than connecting the lowest fixture number first,and so on.
  • Page 10 first fixture in the chain be initialized for this purpose via either settings in the control panel or DIP-switches. Secondarily, the fixtures that follow may also require as lave setting. Check the “Operating Adjustments” section in this manual for complete instructions for this type of setup and configuration. FIRST FIXTURE IN CHAIN DMX OUT DMX IN...
  • Page 11 by using the control panel on the front of the fixture. There are 4 control buttons below the LCD display which allow you to navigate through the various control panel menu. LED STROBE ENTER DOWN BUTTON FUNCTION <ESC> Used to access the menu or return to a previous menu option <DOWN>...
  • Page 12 Mode 3 Auto Mode 3 Mode 4 Auto Mode 4 Mode 5 Auto Mode 5 Mode 6 Auto Mode 6 SPEED 000-031 Auto Run Speed TEST LED All on All On + Individual LED Segment Testing Red on Green on Blue on White on Red 1 on...
  • Page 13 Key Unlock Menu buttons are not locked. Load Default Load Default Resets all values to default DMX Mode: Allows the unit to be controlled by any universal DMX controller. Set the Starting DMX Address: The default mode for the fixture is DMX, so the first menu item that you can edit is the starting DMX address.
  • Page 14 Auto Program Speed: 1.) Press the <UP/DOWN> buttons until you reach Speed. 2.) Push the <ENTER> button. 3.) Use the <UP/DOWN> buttons to select from 000-031. 4.) Press the <ENTER> button to confirm. Additional Features: Never thought you would ever see so many nifty neato features in a strobe light did you? Temperature: IMPORTANT - Brightness will decrease when the LED temperature rises over...
  • Page 15 and press the <ENTER> button. Temp Unit CS 1.) Press the <UP/DOWN> buttons until you reach Config. 2.) Push the <ENTER> button, and navigate to Temp Unit CS 3.) Using the <UP/DOWN> buttons to select Celsius degree or Fahrenheit degree. Test Mode: 1.) Press the <UP/DOWN>...
  • Page 16 000 <--> 255 Red segment Intensity (0-100%) 000 <--> 255 Green segment Intensity (0-100%) 000 <--> 255 Blue segment Intensity (0-100%) 000 <--> 255 White segment Intensity(0-100%) 000 <--> 255 Flash duration (0-full on) 000 <--> 255 Strobe rate (0-30Hz) Built-In Programs 000 <-->...
  • Page 17 DMX Values In-Depth (3-Channel Mode) VALUE FUNCTION 000 <--> 255 Dimmer (0% <--> 100%) 000 <--> 255 Flash Duration (0% <--> 100%) 000 <--> 255 Strobe Rate (0-30Hz) DMX Values In-Depth (1-Channel Mode) VALUE FUNCTION 000 <--> 255 Dimmer (0% <--> 100%) DMX Values In-Depth (4-Channel Pixel Mode) VALUE FUNCTION...

  • Page 18: Shape

    4. Shape FIGURE 1: The Storm1000 Pin-Up Picture 1260 pcs Bright LED Locking Knobs Durable Cast Aluminum Housing Mounting Bracket FIGURE 2: The Rear Connections Fans Cooling Natural Convection Heat Sink Cooling 3/5-Pin DMX512 In AC Power In AC Power Out 3/5-Pin DMX512 Out Easy-To-Use 4-Button LCD Control Panel Stand Plate...

  • Page 19: Troubleshooting

    5. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and fan. 1. Check the connection of power and main fuse. 2. Measure the main voltage on the main connector. 3.

  • Page 20: Fixture Cleaning

    defects ERRATICALLY Install a Terminator. Reset fixture(s). Verify proper mode of operation. Is the fixture in FIXTURE MOVING “Auto” mode? ON ITS OWN 6. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
