- Page 1 User Manual Excel G-Nexx...
-
Page 2: Table Of Contents
4.5 Going up or down stairs 4.5.1 Going up a flight of stairs 4.5.2 Going down a flight of stairs 5. Specifications 6. Components of the Excel G-Nexx 6.1 The push handles 6.2 The armrests 6.3 The backrest 6.4 The brake 6.5 The legrests... - Page 3 User Manual | Excel G-Nexx 6.7 The frame 6.7.1. Adjusting the frame width 6.7.2. Adjusting the seat width 6.7.3. Adjusting the seat depth 6.7.4. Adjusting the seat height 6.7.5. Adjusting the wheelbase 6.8 The anti-tip wheels 6.9 The tilt-in-space function 6.10 The wheels...
-
Page 4: General Introduction
User Manual| Excel G-Nexx General introduction Before you are going to use your new Excel G-Nexx, you and your attendant must fully read and understand this user manual. Also, as you have this user manual, you agree to the conditions mentioned within. - Page 5 User Manual | Excel G-Nexx Enter the information of your authorised dealer below: Company: …………………………………………………………………………………………………………………………………… Address: …………………………………………………………………………………………………………………………………… Phone number: …………………………………………………………………………………………………………………………………… Fax number: …………………………………………………………………………………………………………………………………… E-mail address: …………………………………………………………………………………………………………………………………… Website: …………………………………………………………………………………………………………………………………… © 2015 Excel, part of Van Os Medical B.V. Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com...
-
Page 6: Identification
User Manual| Excel G-Nexx Identification Your wheelchair is equipped with a unique serial number. You will find this number on the frame of your wheelchair. Below, you can see an example of the frame label, where you can find the identification number. -
Page 7: General Information
These handles can be adjusted in height. Additionally, the armrests can be folded backwards. The legrests of the Excel G-Nexx swing away to the side and can be removed fully. To help fold the wheelchair, the footplates can be flipped up with the help of the included allen key. -
Page 8: Safety Regulations
User Manual| Excel G-Nexx Safety regulations Van Os Medical B.V. specifically disclaims responsibility for personal injury or property damage, which may occur during any use when the recommendations and warnings described in this user manual are not followed. The G-Nexx is a very safe and stable product if used correctly. It is possible however if you use the product incorrectly and do not follow the safety guidelines set out in this manual that dangerous situations could occur. - Page 9 Warning The implementation of changes to the Excel G-Nexx wheelchair, which are structural changes, is at all times at the expense of the warranty. © 2015 Excel, part of Van Os Medical B.V.
-
Page 10: User Instructions
User Manual| Excel G-Nexx User instructions It is very important that you teach yourself the correct user instructions. Therefore, you need to know all the components of the wheelchair as described in this user manual. Always check with an expert about developing safe methods regarding your physical abilities to use your wheelchair. -
Page 11: Bending And/Or Reaching To The Side
User Manual | Excel G-Nexx 4.2.2 Bending and/or reaching to the side If you want to get something that is next to you or your wheelchair, please follow the steps below. • Make sure you are as close as possible to the object with your wheelchair. Use the rear wheels of the wheelchair as a target;... -
Page 12: Going Down A Kerb Or Threshold
User Manual| Excel G-Nexx 4.3.2 Going down a kerb or threshold If you want to go down a kerb or threshold yourself, you should always do this backwards. When you do this forward, there is a risk of falling out of your wheelchair. However, you should practice with an occupational therapist before you go down a kerb or threshold with your wheelchair yourself. -
Page 13: Going Up Or Down Stairs
User Manual | Excel G-Nexx and will also cause friction. To avoid a friction burn on your hands, we recommend wearing gloves. Do not use the wheel brakes whilst going down the incline. These brakes are only suitable for use when stationary. It is also advisable to avoid suddenly changing the direction when negotiating an incline. -
Page 14: Specifications
User Manual| Excel G-Nexx Specifications Below, you will find the specifications of the Excel G-Nexx. Technical specifications of the Excel G-Nexx Total length 119 cm (incl. footrests) Total width 63 ↔ 85 cm (stepless) Total height 103 cm Total weight... -
Page 15: Components Of The Excel G-Nexx
The push handles The push handles of the Excel G-Nexx are covered with an extra soft, ergonomical layer (photo 1). This provides your attendant with a good grip on the handles. This makes pushing the wheelchair more comfortable and safer. -
Page 16: The Backrest
EXCEL G-NEXX | Photo 5 EXCEL G-NEXX | Photo 6 The backrest The backrest of the Excel G-Nexx (photo 7) is adjustable in angle from 0 to 30 degrees. To adjust the backrest angle, follow the step below: • On photo 7 you can see the grub screws on the backrest angle adjustment mechanism of the Excel G-Nexx. -
Page 17: The Legrests
The legrests The legrests of the Excel G-Nexx are equipped with convenient adjustment options. The legrests can be adjusted in angle and length. Additionally, the legrests swing away to the side and can even be removed fully. To swing away and remove the legrests, follow the steps below;... -
Page 18: The Footplates
You can now adjust the legrest to the desired angle (photo 16); • When the desired angle is achieved, tighten the black starknob to lock the legrest in position. EXCEL G-NEXX | Photo 15 EXCEL G-NEXX | Photo 16 EXCEL G-NEXX | Photo 17 The footplates Attached to the legrests are the footplates. -
Page 19: Adjusting The Height Of The Footplates
Tighten the grub screw to lock the footplate into place. EXCEL G-NEXX | Photo 21 Frame Upon developing the Excel G-Nexx frame, we have incorporated many adjustment options, easily adjustable with the help of an allen key. 6.7.1 Frame width adjustment The width of the frame can be adjusted on the front and back. -
Page 20: Adjusting The Seat Width
• The width can now be adjusted steplessly; • Tighten the screws to lock into place at the desired seat width. EXCEL G-NEXX | Photo 24 EXCEL G-NEXX | Photo 23 6.7.3 Seat depth adjustment The seat depth can be adjusted on the front and back of the frame. To do this, follow the steps below: •... -
Page 21: Adjusting The Seat Height
User Manual | Excel G-Nexx 6.7.4 Seat height adjustment The seat height can be adjusted on the front and back of the frame. To do this, please follow the steps below: • Loosen the grub screws on the side of the frame (allen key size 5);... -
Page 22: The Anti-Tip Wheels
User Manual| Excel G-Nexx Anti-tip wheels The Excel G-Nexx is equipped with two anti-tip wheels; one on each side of the wheelchair. These prevent the wheelchair from tipping, for example when negotiating an obstacle. EXCEL G-NEXX | Photo 27 Tilt in space The Excel G-Nexx is a tilt-in-space wheelchair. -
Page 23: The Wheels
The rear wheels The rear wheels of the Excel G-Nexx have 12½” PU tyres. These tyres are puncture proof and do not need to be inflated. The rear wheels can be removed easily with the help of the Quick Release system. By pressing the black button, you can take off the wheel. -
Page 24: The Seat
The seat The seat of the wheelchair is fitted with comfortable padding. The Excel G-Nexx has a thick layer of memory foam on both the seat and the backrest, to prevent pressure ulcers. This keeps you comfortable for long periods of time in the chair. -
Page 25: Maintenance
User Manual | Excel G-Nexx Maintenance Your G-Nexx wheelchair needs periodical maintenance. This is necessary for the upkeep of the moving components. A badly maintained wheelchair will give you technical problems, make it harder to steer and it won’t be covered by the warranty. Preventative maintenance is very important. We advise your wheelchair is checked by a qualified Van Os Medical dealer at least once a year. -
Page 26: Rear Wheels
User Manual| Excel G-Nexx The rear wheels You can also check the rear wheels yourself. Proper adjustment of the rear wheels increases stability. Also, it makes the chair easier to manoeuvre. Use the steps below to check the rear wheels on the following: •... -
Page 27: Cleaning Your Wheelchair
User Manual | Excel G-Nexx Cleaning of the wheelchair Cleaning your wheelchair is important and should be done regularly. You can get your wheelchair best cleaned as described below. • Clean the upholstery, chassis and plastic components on the wheelchair regularly with a mild soap and water. -
Page 28: Service Checklist
User Manual| Excel G-Nexx Service checklist To maximize the lifetime of your wheelchair, we recommend you get your wheelchair checked at least once a year, by an authorised Van Os Medical dealer. The form below can be used for this check. The intensity of the wheelchairs use can vary greatly from person to person. -
Page 29: Problem Analysis And Solutions
User Manual | Excel G-Nexx Problem analysis and solutions Problems may arise when using your Excel wheelchair. The potential problems that may occur are described below. You will also find the solutions. If you have problems with your Excel wheelchair that cannot be found in the table below, we recommend you to contact an authorised Van Os Medical dealer. -
Page 30: Warranty
User Manual| Excel G-Nexx Warranty Your user manual is also the warranty form. Enter the relevant data on page five and keep this user manual safe. Warranty application On your wheelchair is a factory warranty label. It could also be possible that your dealer offers an additional warranty. - Page 31 User Manual | Excel G-Nexx Under normal circumstances no responsibility is accepted when the wheelchair needs replacement or repairs as a direct result from: • Not maintaining the wheelchair and parts according to the recommendations of the manufacturer, or not using the specific original parts;...
- Page 32 User Manual| Excel G-Nexx Declaration of Conformity Product identification Manually propelled wheelchair Product group: Excel Brand: G-Nexx Model: VOS.TCF.EC.0740 Number: Manufacturer Name Van Os Medical B.V. Address Koperslagerij 3 4651 SK Steenbergen Country The Netherlands Means of Conformity The product is in conformity with Directive 93/42/EEC based on the use of a Technical construction file in accordance with Article 9 (Class I products) of the Directive.
- Page 33 Van Os Medical B.V. Koperslagerij 3 4651 SK, Steenbergen (NB) Nederland T: +31 (0) 167 57 30 20 F: +31 (0) 167 57 33 81 E: info@vanosmedical.nl W: www.vanosmedical.nl © 2015 Excel, part of Van Os Medical B.V. Koperslagerij 3 | 4651 SK Steenbergen | The Netherlands | T: +31 (0)167-573020 | E: info@vanosmedical.nl | W: www.vanosmedical.com...
