Manson Engineering Industrial SDC-2010 Operation Manual

Thank you for buying this ENERGY CONSERVATION PRODUCT.
Why waste batteries when you can get free electricity from your vehicle ?
PLASTIC SLEEVE
2A FUSE
(CONCEALED)
METAL CONTACTS
WITH
CIGARETTE SOCKET
WARNING
INCORRECT OUTPUT VOLTAGE AND OR POLARITY MAY DAMAGE YOUR PORTABLE
Do Not use this adapter if you are not sure of the polarity and voltage of the DC input of your portable.
Do Not use this adapter for the portable that requires a continuous current input higher than 1500mA
Do Not cover the adapter during operation as ventilation is essential for proper operation.
Do Not use the adapter while starting the vehicle.
It is advisable not to use the car power adapter for extensive period when the engine is turned off. Depending on the power
consumption of your portable and the capacity of your car battery , it may drain your battery flat .
Before using this adapter, make sure you read this operation manual in full and keep it in a safe place for
future reference.

OPERATION PROCEDURE

Preparation

1.Take out the batteries and switch off your portable.
2. Selecting the right voltage for your portable
Use a small screw driver to set the head of the recess arrow to point to your chosen voltage.
3. Finding out whether your portable is center POSITIVE or center NEGATIVE .
Most portables have the following markings on or near the Input Socket showing voltage and polarity.
When the center is linked to a + sign , it is then center POSITIVE
When the center is linked to a – sign , it is then center NEGATIVE
S
S
OPERATION MANUAL
1. Adjust Voltage
OUTPUT VOLTAGE
SELECTOR
POWER ON LED
PARTS OF THE CAR POWER ADAPTER
D C – 2 0 1 0
D C – 2 0 1 0
2. Set Polarity
For negative center
For positive center
