Summary of Contents for Downee Leaf
- Page 1 All business No bullsh*t TELESCOPIC GATE PACK MANUAL...
-
Page 2: Troubleshooting
INDEX PAGE LEAF DESIGN ....LEAF SPECS ....LEAF ONE FABRICATION .. - Page 3 Telescopic gates are designed to be used with Recessed Wheels, but can be adapted for Bottom Mount Wheels. TRACK Telescopic uses two lengths of track, one for each gate. Leaf 1 needs a track only half the driveway width. Leaf 2’s track runs the entire driveway width. PEDESTRIAN GATE Telescopic are often fitted in small yards without room for a pedestrian gate.
- Page 4 Rule of thumb: Leaves are half the width of the entrance (in- side post to post) plus, depending on entrance length add 300/600mm. Note: Leaf One needs an extra 300mm for the rack. Details below. LEAF LENGTHS Leaf One = entrance width A, halve it, add C (300mm...
- Page 5 LEAF ONE FABRICATION GATE 1 (facing towards the street) THIS SIDE FACES STREET C = 300 / 600* D = 50 / 70* H = 55 *11 & 15m Kits have two inline Motor rollers Tail Vertical welds to avoid holes...
-
Page 6: Hardware Parts
LEAF ONE HARDWARE PARTS All of the Telescopic parts used on Leaf One are shown here. INLINE ROLLER PULLEY HARDWARE CABLE CLAMP (top) CABLE ANCHOR (bottom) PULLEY COVER... -
Page 7: Hardware Install
LEAF ONE HARDWARE INSTALL MOUNTING PULLEY HARDWARE Insert the pulley hardware into the gate. Nip up the bolts finger-tight. NOTE Cable anchor to bottom 13mm Cable Loop Lock Pull the cable taut and tighten 4m/8m Kit 4m/8m Kit cable clamps (Thread facing down). - Page 8 11m/15m Kit LEAF ONE HARDWARE INSTALL (CONTINUED) Loosen the cable tensioner bolts both ends to slacken the cable. 10mm Cable Clamp Slide the Cable Clamp and Anchor to the ends as shown. Hold the top Cable Clamp against the pulley and tension the cable.
- Page 9 LEAF ONE HARDWARE INSTALL (CONTINUED) Remove freeplay from the cable with 10mm tensioner bolts on both ends. It’s okay for it to have some tension. 10mm Check both pulley clamps sit against the pulleys. Tighten 13mm pulley & 17mm wheel bolts both ends.
- Page 10 LEAF TWO FABRICATION Fig. 1 THIS SIDE FACES YARD QUICK COUPLER POSITION Using 100x50 bottom channel? The Quick Coupler may need a fabricated mount (see Fig. 1). Match the Quick Coupler (yellow) height to the Cable Clamp (blue). 40mm 4m & 8m PACK NOTE 11m &...
-
Page 11: Installation
Tracks in place. Keep a constant gap between Tracks (below) 11m/15m Kit IMPORTANT 50mm Slide Leaf 1 into the Top Guide on the short track. Keep a 50mm gap between leaves. 4m/8m 11m/1 Block the wheels to stop... - Page 12 LEAF ONE INSTALLATION (CONTINUED) With Leaf One open, bolt the Cable Anchor between the tracks to the concrete pad using Blue Tip bolts (6.5mm). Note the different mount points for each kit (below). 4m/8m Kit 11m/15m Kit BOTTOM MOUNT WHEELS Telescopic Gates are designed to be used with recessed wheels.
- Page 13 Connect and lock the Quick Coupler to Cable Anchor. Mount the channel (not supplied) for Inline Roller to Leaf Two. Welded an- gle is quick and easy but can’t be adjusted. Consid- er using a U-Channel and screwing it in place.
- Page 14 PULLEY HARDWARE TEMPLATE (ACTUAL SIZE)
- Page 15 PULLEY HARDWARE TEMPLATE (ACTUAL SIZE)
