Summary of Contents for ESi Ergo VICTORY 2VT-C36-30 Series
- Page 1 VICTORY Model 2VT-C36-24-___ Model 2VT-C36-30-___ Model 2VT-C48-24-___ 2 LEG ELECTRIC TABLE BASE Model 2VT-C48-30-___ _ _ _ = SLV, BLK or WHT 2VT Rev A 1/17 ASSEMBLY AND OPERATION...
-
Page 2: Table Of Contents
VICTORY 2 LEG ELECTRIC TABLE BASE PARTS AND TOOLS PLEASE REVIEW these instructions before beginning the assembly procedures. Check that all the parts shown below were provided with your order. Contact your supplier if any materials are missing. Do not discard the packaging until satisfied that the product operates to your satisfaction. - Page 3 ASSEMBLY VICTORY 2 LEG ELECTRIC TABLE BASE STEP 1 Cross Channel With the table top facing down on a soft, clean surface, arrange the cross channels and top supports as shown. Mounting Tab • Positioning does not need to be exact at this time. Support •...
-
Page 4: Control Unit
VICTORY 2 LEG ELECTRIC TABLE BASE ASSEMBLY STEP 6 Align Rear of Feet with Rear of Table Adjust the position of the frame before screwing it to the table. • The top supports on each side should be approximately 1" (25mm) from the ends of the table. - Page 5 ASSEMBLY VICTORY 2 LEG ELECTRIC TABLE BASE STEP 11 Make connections to the control unit and motors. • Connect the cable from the digital keypad. • Connect the motor cables to the control unit and Keypad to each of the motors on the table legs. Cable •...
- Page 6 VICTORY 2 LEG ELECTRIC TABLE BASE OPERATION Setting Memory Table DOWN Button Buttons Height Button Button CAUTION: The “zero setting” procedure must be completed before operating the table. See Step 12 on page 5. GENERAL OPERATION Table movement stops when you Move the table up or down by pressing UP s or DOWN t until release the UP s or DOWN t button.
- Page 7 OPERATION VICTORY 2 LEG ELECTRIC TABLE BASE MOVING THE WORK SURFACE TO A SAVED POSITION If you release the memory button Use this function to move the work surface to one of the saved before the saved position is reached, positions.
- Page 8 800.833.3746 esiergo.com © 2017 ESI Ergonomic Solutions. All rights reserved. 2VT Rev A 1/17...
