BSL10LST
Installation Instructions
Self-Testing Emergency LED Driver
CLASS 2 OUTPUT
! IMPORTANT SAFEGUARDS !
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. To prevent voltage from being present on output leads prior to installation, unit engage connector must be
open. Do not join unit engage connector until installation is complete and AC power is supplied to the
emergency driver.
2. This product is for use with an emergency LED lighting load and supplies nominaly 10.0 W of power, with
a voltage of 15-54 VDC in emergency mode for a minimum of 90 minutes, in compliance with NFPA-101 and
NEC 700.12.
3. Make sure all connections are in accordance with the National Electrical Code or Canadian Electrical Code and
any local regulations.
4. To reduce the risk of electric shock, disconnect both normal and emergency power supplies and unit engage
connector of the emergency driver before servicing.
5. This emergency driver is intended to be mounted and enclosed within a luminaire and is suitable for both
factory or field installation. For field installation, please see the instructions on page 2.
6. This product is suitable for use in damp locations where the ambient temperature is 0ºC minimum, +55ºC
maximum. Product is also suitable for installation in sealed and gasketed fixtures. Product is not suitable
for heated air outlets and wet or hazardous locations. Maximum allowable case temp is 63ºC. See Page 4
for Tcase measurement location.
7. An unswitched AC power source is required (120-277 VAC, 50/60 Hz).
8. Do not install near gas or electric heaters.
9. Do not attempt to service the battery. A sealed, no-maintenance battery is used that is not field replaceable.
Contact the manufacturer for information on service.
10. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
11. Do not use this product for other than intended use.
12. Servicing should be performed by qualified service personnel.
13. Equipment should be mounted in locations and at heights where it will not be subjected to tampering by
unauthorized personnel.
14. For Canadian application the output terminals should be in compliance with the accessibility requirement of
the Canadian Electric Code.
15. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference that may
cause undesired operation.
16. This product must be grounded. See the wiring diagrams for details.
THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY.
236 Mt. Pleasant Rd. • Collierville, TN USA 38017-2752 • Tech Support 888-263-4638 • Fax 901-853-5009 • www.bodine.com
SAVE THESE INSTRUCTIONS
THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.
Bodine © 2018 Signify Holding. All rights reserved.
442294606602
WHEN USING ELECTRICAL EQUIPMENT, BASIC
SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:
Li - ion
02/07/19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSL10LST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bodine BSL10LST

  • Page 1 THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM-ION BATTERY. THE BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. 02/07/19 Bodine © 2018 Signify Holding. All rights reserved. 236 Mt. Pleasant Rd. • Collierville, TN USA 38017-2752 • Tech Support 888-263-4638 • Fax 901-853-5009 • www.bodine.com 442294606602...
  • Page 2 INSTALLATION CAUTION: DO NOT JOIN UNIT ENGAGE CONNECTOR UNTIL INSTALLATION IS COMPLETE AND AC POWER IS SUPPLIED TO THE EMERGENCY DRIVER. NOTE: Make sure the necessary branch circuit wiring is available. An unswitched source of power is required. The emergency driver must be fed from the same branch circuit as the AC driver. This product is suitable for field installation with suitable LED loads including LED luminaires, DC voltage driven LED replacements for fluorescent lamps and others.
  • Page 3 Fixture or STEP #2 INSTALLING THE 2W-ITS ON FIXTURE SURFACE Test/Monitor Plate > Mount the supplied 2W-ITS (2-wire illuminated test switch) in a location that is 2 Wire Illuminated visible and accessible by maintenance personnel. The 2W-ITS mounts through a Test Switch Hex Nut ½”...
  • Page 4 TROUBLESHOOTING GUIDE STATUS INDICATOR PROBLEM CORRECTIVE ACTION LIGHT Light on not flashing None None, Unit is Operating Correctly. Charge battery. If after an hour failure is Flashing 2 times every 5 seconds Battery Error still indicated, see action below. Ensure input wiring is correct and verify voltage is Flashing 3 times every 5 seconds Charging Error correct and stable.
