Kiev-19M
The camera you have bought may slightly differ in appearance from the pictures presented in this
booklet, since in manufacture the appearance and performance of the cameras are continuously
improved.
1. General directions
1.1. Purpose of Camera and its Features
The КИЕВ-19М (KIEV-19M) camera is a miniature reflex camera of system TTL with semiautomatic
setting of exposure. It is intended for amateur photographing.
The camera is designed for using the 35 mm photographic film in the standard magazines (36
pictures sizing 24×36 mm in loading of 1.65 m of film).
The KIEV-19M camera is released with the MC HELIOS-81H lens (diaphragm setting range 16,
focusing distance 50 mm, relative aperture 1:2). The lens is provided with special multilayer anti-
reflection coating of which the marking (MC) is indicative. The multilayer anti-reflection coating
improves the quality of an image and increases its contrast grade on account of increasing the integral
transparency and decreasing the light dispersion by the lens.
The lens joint is of a bayonet type, the thread for a light filter is M52×0.75.
The design of the camera envisages the use of the change lenses which are specially released for the
KIEV-19 and KIEV-20 cameras The list of change lenses is given in Table 1.
Description
MC MIR-20H
MC MIR-24H
MC CALEYNAR-5H
TELEAR H
MC GRANIT-11H
The metal curtain shutter ensures the speeds in the range from 1/500 to 1/2 s and "B".
The curtain travel occurs along the short side of the picture from bottom to top.
The viewfinder is of a reflecting brilliant type.
The Fresnel lens and the condenser lens in the finder ensure the increasing brightness of an image
and thus the opportunity of shooting under conditions of weak lighting.
The field of vision of the finder occupies 93% of picture area.
Kiev-19M
Instructions for Use.
Relative
aperture
lenght, mm
1 : 3,5
1 :
2,0
1 : 2,8
1 : 3,5
1 : 4,5
– 1 –
T a b l e 1
Angle of
Focal
field of
vision, ...°
020
94,0
035
63,0
100
24,5
200
12,0
80–200
30–12
Instructions for Use
Advertisement
Related Manuals for Kiev Camera 19M
Summary of Contents for Kiev Camera 19M
- Page 1 1. General directions 1.1. Purpose of Camera and its Features The КИЕВ-19М (KIEV-19M) camera is a miniature reflex camera of system TTL with semiautomatic setting of exposure. It is intended for amateur photographing. The camera is designed for using the 35 mm photographic film in the standard magazines (36 pictures sizing 24×36 mm in loading of 1.65 m of film).
-
Page 2: Delivery Set
The camera design comprises the ergonomic attachment. 1.2. Camera Care The KIEV-19M camera is a modern opto-mechanical instrument fitted with electronics. Handle the camera with care, keep it clean, protect it from jolts, impacts, dust, moisture and sharp temperature variations. In shooting in the frosty weather (below minus 10°C), do not leave the camera outdoors, carry it under your outdoor clothing and take it out only for the time of shooting. - Page 3 Kiev-19M Instructions for Use 3. Design 1. lens; 07. film sensitivity scale fixing button; 2. eye for strap attachment; 08. film sensitivity scale; 3. depth-of field preview lever; 09. rewinding head; 4. shutter cocking lever; 10. exposure setting index; 5. button for switching on exposure meter and 11.
- Page 4 Kiev-19M Instructions for Use 20. film transport mechanism release; 22. tripod nut 1/4″; 21. power source recess cover; 23. viewfinder eyepiece protective glass; 25. frame for arrangement of information on film 24. camera back; to be used; – 4 –...
- Page 5 Kiev-19M Instructions for Use 26. magazine recess; 28. take-up spool; 27. rewinding head dog; 29. measuring shaft tooth; 30. strap; 31. strap fixing screw. 4. Camera Operation Procedure 4.1. Installation of Power Source To install the power source open cover 21 by moving it in the direction of the arrow. Observing the polarity install the power source above the fixed in the recess tape.
- Page 6 Kiev-19M Instructions for Use 4.2. Camera Loading The camera can be loaded with the 35 mm unperforated film of any type in standard magazines. If you fit the film in the magazine by yourself thread it thoroughly in the spool to avoid its loosening during transportation.
- Page 7 Kiev-19M Instructions for Use 4.3. Preparing the Camera for Shooting Cock the shutter twice by lever 4 pressing on release button 5 after each cocking. At the next cocking of the shutter the digit “1” of the picture counter is set opposite the index. If the camera has been loaded correctly during the cocking of the shutter rewinding head 9 rotates.
- Page 8 Kiev-19M Instructions for Use The light indication of the exposure meter is arranged from the left-hand side of the field of vision of the viewfinder: upper signal СВЕТА МНОГО (MUCH LIGHT), lower signal – СВЕТА МАЛО (LITTLE LIGHT). The simultaneous lighting of two signals is a normal condition for shooting НОРМА...
- Page 9 Kiev-19M Instructions for Use 4.5. Camera Unloading After having exposed 36 pictures unload the camera by rewinding the film into the magazine. For this do as follows: by pressing button 20 arranged on the lower cover of the camera switch off the measuring shaft;...
-
Page 10: Acceptance Certificate
For convenient holding the camera without the case it is possible to install ergonomic attachment 30 which is fixed on the camera body by screw 31. 5. Acceptance Certificate It is hereby certified that KIEV-19M camera, Serial No. with lens No. meets the requirements of the engineering documentation and is found fit for service.
