TABLE OF CONTENTS WARNINGS AND IMPORTANT INFORMATION ������������������������������������������������������������������������������������� 2 INTRODUCTION ���������������������������������������������������������������������������������������������������������������������������������������������������������� 4 SPECIAL NOTE FOR PARENTS ��������������������������������������������������������������������������������������������������������������������������� 4 SPECIAL NOTE FOR E-BIKES ������������������������������������������������������������������������������������������������������������������������������ 5 ASSEMBLY OF THE NEW BICYCLE ����������������������������������������������������������������������������������������������������������������� 7 GENERAL RIDING INFORMATION ������������������������������������������������������������������������������������������������������������������ 7 PRE-RIDE CHECK ����������������������������������������������������������������������������������������������������������������������������������������������������� 13 ADJUSTMENTS ���������������������������������������������������������������������������������������������������������������������������������������������������������...
Page 3
ing heavy objects on racks, especially on the front, will significantly change the steering characteristics of your bike� It is advised to take some time to get used to the bike with a loaded rack by riding it first on a side road or empty parking lot before going on the street�...
Congratulations on your purchase of one of the most stylish bicycles in the world� At Creme, we are all very passionate about what we do, and seeing happy customers is the biggest reward that we can get for working hard� So we do everything in our power to make this happen, but even then, a bicycle that is not properly set up or maintained, will be a disappointment�...
WARNING: If you intend to put a child seat on your bicycle, you will need to completely enclose any coil springs under the saddle with a suitable covering to prevent the pinch- ing or trapping of the child passenger’s fingers� SPECIAL NOTE FOR E-BIKES Electric bikes, also known as e-bikes or pedelecs are bicycles equipped with an electric pedal assist drive system�...
TECHNICAL INFORMATION Make yourself familiar with the names of all the main parts of the bike by studying the di- agram below� Your actual model and the accessories (e�g� battery, lighting, fenders, rack, kickstand) may be different to what is shown, depending on the type of bike you own� 1�...
ASSEMBLY OF THE NEW BICYCLE This should always be carried out by the dealer where you purchased your bicycle� If you buy a bicycle that is disassembled, or only partially assembled, the warranty will be void� Assembly should be done in your presence, in order to make the necessary adjustments correctly, such as saddle height, handlebar angle and stem height�...
Page 8
some time getting used to any new bike� If you are a beginner, you should really commit to mastering the skill of bike handling� Check out the response of your new bicycle as well as the comfort in safe conditions, for example in an empty car park or side road� Watch out for the brakes - they can be powerful and activating them too aggressively can result in a crash�...
WARNING: When your bicycle is on a bike stand or it’s upside down, never put your finger or any other part of your body between the chain and the chain- ring when the wheel is spinning. This is especially important on bicycles with no derailleurs, because the chain is very tight.
Page 10
IMPORTANT NOTICE: The drive system on some e-bike models is turned ON and OFF using a key� Keys may also operate accessories and locks, if equipped� Keys are identified by the serial number� Please record the key serial number for future use and key replace- ment�...
Page 11
WARNING: Disc brakes can heat up extremely when their application is pro- longed. Don’t touch a disc brake until it has had plenty of time to cool. Remem- ber that brake pads in all brake types will wear out, which will ultimately reduce their efficiency.
Page 12
to lock up, slightly release pressure to keep it rotating� You should learn how much brake pressure is needed for each wheel at different speeds and on different surfaces� Reduc- ing the bicycle’s speed by applying one or both brakes will transfer the weight to the front wheel as the rider’s body continues at the speed at which it was going�...
Difficulties with shifting may indicate a mechanical adjustment problem, in which case you should contact your dealer for help� WARNING: If the derailleur does not shift smoothly, you should not shift fur- ther, as it may be out of adjustment and the chain could jam, causing you to lose control and fall.
Frame and fork structure Clean the frame and fork and examine them CAREFULLY for any signs of cracks, corro- sion, dents, paint peeling or other defects� If anything suspicious is found, contact your local bicycle dealer for a proper inspection� These are important safety checks and very important to help prevent accidents, injury and shortened product lifespan�...
ately� If your bicycle has hydraulic disc brakes, check if brake fluid is not leaking, especially in the areas where the cables connect to the calliper or brake lever� WARNING: Damaged cables can seriously impede braking efficiency and cause you to loose control and crash. Steering system The steering system includes: handle bar, stem, headset and fork�...
Page 16
with every bicycle. Check wheel axle to fork connection - this is critical for your safety. If you have axle nuts they should be tightened according to the manufacturer’s specifica- tion. If you have a quick release make sure that it is set to the CLOSED position, and that there is a significant amount of resistance when pushing the lever and that it is set to the CLOSED position (FIG.1).
Page 17
release is not properly fastened. The force from the disc brake can eject the wheel from the fork. Please refer to the diagram below in order to identify these terms: Please refer to the diagram below in order to identify these terms: Standard Reversed Standard safety...
Page 18
mediately. Reference bolt tightening torque values (please always refer to the manufacturer’s instruction manual first, the values shown below do not apply to ALL types of components that may be mounted on the bicycle): Bolt type: Tightening torque (N-m): Stem steer tube bolt Stem handlebar bolts Front hub axle bolts (for 10mm axle hubs)
Adjusting handlebar height and angle Handlebar height and angle. Quill stem Threadless stem Your bike is equipped either with a “threadless” stem, which clamps on to the top part of Your bike is equipped either with a “threadless” stem, which clamps on to the top part the steerer tube, or with a “quill”...
Page 20
Repeat until you find the best position. The tightening torque of the seat binder should be around 12Nm. WARNING: Never extend the seat post above the minimum insertion mark that can be found on the lower part of the seat post! Adjusting saddle height Adjusting the rail saddle position.
MAINTENANCE AND PERIODICAL CHECKS Take care of your bicycle, and you will enjoy it for a longer time� Also take some time to periodically inspect the bicycle in more detail - this is important for your safety� Here is some basic information� Caring for steel frames Steel frames are prone to corrosion if not taken care of properly�...
Cleaning your bicycle Good maintenance will increase the life of your bike and its components� Clean and maintain your bike regularly� WARNING: Corrosion can damage components of your bike which are impor- tant for safety so that they are no longer secure. These components may then brake during riding and thus result in serious falls.
Page 23
CREME WARRANTY 1� Creme Cycles sp� z o�o� sp� k� (hereinafter referred to as CREME) warrants all its new bicycles against defects in materials and workmanship as stated below: - mechanical structure of frames & forks: for the lifetime of the original owner, - mechanical structure of all other components: for a period of 2 years, - paint and decals: for a period of 1 year�...
Page 24
An original owner agrees that CREME’S liability under this warranty under no circumstances shall be greater than the original purchase price� In no event shall CREME be liable for inci- dental or consequential damages� All other remedies, obligations, liabilities, rights,...
Page 25
Failing to do so can result in a serious accident caused by the rack blocking the front wheel! This front carrier is designed only for Creme Caferacer Bikes and cannot be used with any other bicycle�...
Page 26
FRONT RACK MOUNTING PROCEDURE. STEP 1: Identify all the components of the front rack� 1 stay 1 2 stay 2 3 main tray 4 lamp 5 nuts 6 front bolts 7 safety strip STEP 2: Remove the 4 bolts that come threaded into the side of the front fork�...
Page 27
STEP 3: Assemble the front rack as shown on the photographs� The bolts connecting the side stays with the main tray should be tightnened using two tools with a torque of 7 Nm� STEP 4: Apply Loctite (or other thread locking compound) to 2 bolts and fasten the bot- tom legs of the rack to the fork like so: Do not tighten the bolts yet !
Page 28
STEP 5: Dismount the front caliper brake from the fork crown, slide the fender mount off the bolt, then slide the safety strip onto the caliper bolt, like on the attached photo� STEP 6: Wrap the strip around the rack, and return to the caliper bolt� Then slide the fender mount back onto the caliper bolt�...
Page 29
STEP 8: Align the rack so that you can mount the two top bolts� Before you thread them into the fork, make sure they are coated with Loctite (or other thread locking compound)� In this position, the safety strip should be slack, not very tight� STEP 9: Tighten the 4 mounting bolts that secure the rack to the fork (indicated by the ar- rows) with a force of 7 Nm�...
Page 30
PROOF OF PURCHASE – WARRANTY CARD Dealer’s stamp Bike, model: ������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Frame serial number: ���������������������������������������������������������������������������������������������������������������������������������������������������� Fork serial number (if any): ��������������������������������������������������������������������������������������������������������������������������������������� Price: ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Date of purchase: ������������������������������������������������������������������������������������������������������������������������������������������������������������ I certify that I am acquainted with the actual specification of the bicycle (this can be slightly different than that published by the distributor)�...
Page 32
Hereby we confirm above products compliance with the European directive of EU Machinery Directive 2006/42/EC & CE. Below standards were tested and passed: EMC Directive 2014/30/EC PN-EN ISO 12100:2011-03 PN-EN 15194:2017-12 The original document is located in the headquarters, Creme Cycles, Potokowa 20D, 80-283 Gdansk...
