Summary of Contents for Bluesound A860

  • Page 1 A860 Multi-Channel Amplifier Owner’s Manual...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS • Read instructions - All the safety and operating instructions should be read • Damage Requiring Service - Unplug this product from the wall outlet and refer before the product is operated. servicing to qualified service personnel under the following conditions: •...
  • Page 3: Notes On Environmental Protection

    To ensure compliance, operations at closer than this distance is not recommended. IF IN DOUBT CONSULT A COMPETENT ELECTRICIAN. Bluesound Professional is a trademark of Bluesound International. Bluesound International is a division of Lenbrook Industries Limited. ©Bluesound, All Rights Reserved...
  • Page 4: Getting Started

    SPEAKER terminal blocks to corresponding ZONE (ZONE 1- 4) speaker terminals of A860. • Connect corresponding end of the AC power cord to A860’s AC mains input and the AC power cord’s plug connected to mains power outlet.
  • Page 5: Identification Of Controls

    ATTENTION! Please ensure that the A860 is powered off or unplugged from the mains power outlet before making any connections. It is also advisable to power down or unplug all associated components while making or breaking any signal or AC power connections.
  • Page 6: Power Switch

    “+” terminal • The A860 is equipped with separate GAIN controls for each Zone. Single external speaker • Before switching ON the A860 for the first time, make sure all ✔ “-” terminal GAIN controls are set to minimum (MIN) level position.
  • Page 7: Trigger In/Out

    0V when it is at standby mode or powered OFF. • At ON setting and with the +12V TRIGGER IN of the A860 connected to compatible external equipment that is equipped with a +12V TRIGGER output, the A860 can be switched remotely from standby mode to operating mode and vice-versa.
  • Page 8: Troubleshooting

    • Rear panel POWER switch not at ON setting • Set the rear panel POWER switch to ON setting A860 always at standby mode • TRIGGER OFF/ON/AUTO switch set to • Slide the TRIGGER OFF/ON/AUTO switch “AUTO” position to “OFF”...
  • Page 9: Overall Specifications

    483 x 105 x 323 mm x 12 inches Shipping weight 7.1 kg (15.7 lbs) * - Gross dimension includes feet and extended rear panel terminals Specifications are subject to change without notice. Check out www.bluesoundprofessional.com for updated documentation or latest information about A860.
  • Page 10 A DIVISION OF LENBROOK INDUSTRIES LIMITED All rights reserved. Bluesound International, Bluesound Professional, Bluesound, the stylized wordmark and “B” logotype and all other Bluesound product names and taglines are trademarks or registered trademarks of Bluesound International, a division of Lenbrook Industries Limited.
