Crestron UC-P110-S Quick Start

UC-PHONE-S-PLUS/UC-PHONE-T-PLUS
Desk Phones for Skype® for Business & Microsoft Teams™ Software
The UC-PHONE-S-PLUS (sold as the UC-P110-S) and the UC-PHONE-T-PLUS (sold as UC-P110-T)
are desktop phones that bring the Skype® for Business (UC-PHONE-S-PLUS) or Microsoft Teams™
(UC-PHONE-T-PLUS) experience to a desk phone.
With the exception of software, the UC-PHONE-S-PLUS and UC-PHONE-T-PLUS have similar
features.

Check the Box

Item
UC-PHONE-S-PLUS and UC-PHONE-T-PLUS
Cable, Ethernet, CAT5e, 6.6 ft (2 m)
Cord, Handset
Handset
Phone
Stand

Assemble the Device

Attach the stand and adjust the angle of the touch screen as shown below.
Ｄ Ｃ ５ Ｖ
Ｐ Ｃ Ｉ ｎ ｔ ｅ ｒ ｎ ｅ ｔ
Make the necessary connections as called out in the following diagram.
Qty
1
1
1
1
1
1
NOTES:
NOTE:
use, the Microsoft Azure administrator must grant the desired tenant permission to log in with an
O365 account. For details, refer to the UC-P100-S & UC-P110-S Crestron Flex VoIP Desk Phones
for Skype for Business Administrator Guide (Doc. 8412) at www.crestron.com/manuals.
After the device is connected to the network and supplied with power, it automatically begins the
initialization process. After startup, the phone must be configured and provisioned for operation.
For details, refer to the UC-P100-S & UC-P110-S Crestron Flex VoIP Desk Phones for Skype for
Business Supplemental Guide (Doc. 8412) or the UC-P100-T & UC-P110-T Crestron Flex VoIP Desk
Phones for Microsoft Teams™ Supplemental Guide (Doc. 8413) at www.crestron.com/manuals.

Connect the Device

To USB headset
(not included)
PC (optional):
To PC LAN port
Ｄ Ｃ ５ Ｖ
Ｐ Ｃ
Ｉ ｎ ｔ ｅ ｒ ｎ ｅ ｔ
Internet:
To 802.3af compliant From 5 VDC power supply
PoE injector or switch via (not included)
included Ethernet cable
• For a list of USB headsets that are compatible with the UC-PHONE-S-PLUS (Skype for
Business) visit https://partnersolutions.skypeforbusiness.com/solutionscatalog/personal-
peripherals-pcs.
• For a list of USB headsets that are compatible with the UC-PHONE-T-PLUS (Microsoft
Teams), visit https://products.office.com/en-us/microsoft-teams/across-devices/devices/
category?devicetype=36.

Configure, Provision, and Use the Device

(For Skype for Business phones with a user that will log in with an O365 account): Before
To analog headset
(not included)
DC5V
To handset via included
handset cord
